DtLgcyLgrPbFilePdu Class Reference

Instances of DtLgcyLgrPbFilePdu are used for switching to play-mode and defining which file to read from when sending traffic into the simulation. More...

Inheritance diagram for DtLgcyLgrPbFilePdu:

Collaboration diagram for DtLgcyLgrPbFilePdu:

Public Member Functions
	DtLgcyLgrPbFilePdu (DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER)
	(default) constructor More...
	DtLgcyLgrPbFilePdu (const DtNetLgcyLgrControlPdu *initial, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER)
	constructor (construct from network representation) More...
	DtLgcyLgrPbFilePdu (DtGlobalObjectDesignator &sender, DtGlobalObjectDesignator &receiver, const char *name, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER)
	constructor (construct and prepare for send) More...
virtual	~DtLgcyLgrPbFilePdu ()
	destructor More...
	DtLgcyLgrPbFilePdu (const DtLgcyLgrPbFilePdu &src)
	copy constructor More...
DtLgcyLgrPbFilePdu &	operator= (const DtLgcyLgrPbFilePdu &src)
	assignment operator More...
virtual const char *	filename () const
	Get/set file to open for playback. (Path relative to logger.) More...
virtual void	setFilename (const char *path)
virtual DtLgcyLgrStringParams *	params () const
	Return correctly cast parameters pointer; see legacyLgrControlP.h. More...
virtual void	printData () const
	Diagnostic output. More...
Public Member Functions inherited from DtLgcyLgrControlPdu
	DtLgcyLgrControlPdu (DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER)
	(default) constructor More...
	DtLgcyLgrControlPdu (const DtNetLgcyLgrControlPdu *initial, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER, DtPduFactory *pduFactory=0)
	constructor (constructs from network representation) More...
virtual	~DtLgcyLgrControlPdu ()
	destructor More...
	DtLgcyLgrControlPdu (const DtLgcyLgrControlPdu &src)
	copy constructor More...
DtLgcyLgrControlPdu &	operator= (const DtLgcyLgrControlPdu &src)
	assignment operator More...
const DtGlobalObjectDesignator &	receiverId () const
	Get/set Object Identifier of intended recipient (logger). More...
virtual void	setReceiverId (const DtGlobalObjectDesignator &id)
virtual const DtGlobalObjectDesignator &	senderId () const
	Get/set Object Identifier of sender, if applicable. More...
virtual void	setSenderId (const DtGlobalObjectDesignator &id)
DtLgrCommand	lgrCommand () const
	Get message-type for proper casting to a subclass. More...
DtNetLgcyLgrControlParams *	defaultParams () const
	Data place holder. More...

Private Attributes
DtFilename	myFilename
	Parameter. More...

Additional Inherited Members
Static Public Member Functions inherited from DtLgcyLgrControlPdu
static DtPdu *	create (const DtNetPacket *initial, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER, DtPduFactory *pduFactory=0)
	Create a PDU representation from a network packet. More...
static DtLgcyLgrControlPdu *	create (DtLgrCommand command)
	Create a PDU from DtLgrCommand. More...
static void	addCallback (DtExerciseConn *conn, DtLgcyLgrControlInteractionCb cb, void *usr)
	DIS – install/remove handler to call when receiving a LC packet. More...
static void	removeCallback (DtExerciseConn *conn, DtLgcyLgrControlInteractionCb cb, void *usr)
static const char *	lgrModeEnum2string (DtLgcyLgrMode md)
	The name (as a string) of a 'DtLgcyLgrMode'-type enum (from value) More...
static const char *	lgrFilePosEnum2string (DtLgcyLgrFilePosition pos)
	The name (as a string) of a 'DtLgcyLgrFilePosition'-type enum (from value) More...
static const char *	lgrStateFlag2string (DtLgcyLgrCtrlFlagStates flg)
	The name (as a string) of a 'DtLgcyLgrCtrlFlagStates'-type enum (from value) More...
Protected Member Functions inherited from DtLgcyLgrControlPdu
DtPduKind	internalGetPduKind () const
	Identity for use by toolkit. More...
void	setLgrCommand (DtLgrCommand com)
	Set is done by constructing the proper subclass. More...

Detailed Description

Instances of DtLgcyLgrPbFilePdu are used for switching to play-mode and defining which file to read from when sending traffic into the simulation.

Constructor & Destructor Documentation

DtLgcyLgrPbFilePdu::DtLgcyLgrPbFilePdu

(

DtBufferPtr

buffer = DtUSE_INTERNAL_BUFFER

)

(default) constructor

DtLgcyLgrPbFilePdu::DtLgcyLgrPbFilePdu	(	const DtNetLgcyLgrControlPdu *	initial,
		DtBufferPtr	buffer = DtUSE_INTERNAL_BUFFER
	)

constructor (construct from network representation)

DtLgcyLgrPbFilePdu::DtLgcyLgrPbFilePdu	(	DtGlobalObjectDesignator &	sender,
		DtGlobalObjectDesignator &	receiver,
		const char *	name,
		DtBufferPtr	buffer = DtUSE_INTERNAL_BUFFER
	)

constructor (construct and prepare for send)

virtual DtLgcyLgrPbFilePdu::~DtLgcyLgrPbFilePdu ( )

virtual

destructor

DtLgcyLgrPbFilePdu::DtLgcyLgrPbFilePdu

(

const DtLgcyLgrPbFilePdu &

src

)

copy constructor

Member Function Documentation

virtual const char* DtLgcyLgrPbFilePdu::filename ( ) const

virtual

Get/set file to open for playback. (Path relative to logger.)

DtLgcyLgrPbFilePdu& DtLgcyLgrPbFilePdu::operator=

(

const DtLgcyLgrPbFilePdu &

src

)

assignment operator

virtual DtLgcyLgrStringParams* DtLgcyLgrPbFilePdu::params ( ) const

virtual

Return correctly cast parameters pointer; see legacyLgrControlP.h.

virtual void DtLgcyLgrPbFilePdu::printData ( ) const

virtual

Diagnostic output.

Reimplemented from DtLgcyLgrControlPdu.

virtual void DtLgcyLgrPbFilePdu::setFilename ( const char *  path )

virtual

Member Data Documentation

DtFilename DtLgcyLgrPbFilePdu::myFilename

private

Parameter.

---

The documentation for this class was generated from the following file:

• legacyLcPlayFile.h
