The Logger Tape File Dialog.
More...
|
| virtual void | showLoggerTapeInfo () |
| | Slot to toggle showing the dialog preview widget panel, depending on whether the dialog's "Show more logger information" button has been clicked. More...
|
| |
|
| virtual void | fileSelectionChanged (const QString &file) |
| | Slot to take the new file selection from the dialog's file list widget and display the file's meta data in the preview widget panel. More...
|
| |
| virtual void | fileNameTextChanged (const QString &text) |
| | Slot to check for typed filename. More...
|
| |
| virtual void | onFolderSelectionChanged (int index) |
| | If the selection in the folder combox box is changed, need to clear the preview display. More...
|
| |
| virtual void | onNavigateButtonClicked () |
| | If the back, forward or to parent button is clicked, need to clear the preview display. More...
|
| |
|
| virtual bool | eventFilter (QObject *obj, QEvent *event) |
| | Make sure the Open button is not enabled when an invalid file selection has been made. More...
|
| |
| virtual void | accept () |
| | Only accept key press or double-click action on a file selection if the Open button is currently enabled. More...
|
| |
| virtual void | addDisplayControlButtons () |
| | Add buttons that control display of configuration panels. More...
|
| |
The Logger Tape File Dialog.
| MAKLogger::DtLoggerTapeDialog::DtLoggerTapeDialog |
( |
QWidget * |
parent, |
|
|
QString |
directory, |
|
|
QString |
caption, |
|
|
AcceptMode |
mode, |
|
|
Qt::WindowFlags |
f = Qt::Dialog|Qt::CustomizeWindowHint|Qt::WindowTitleHint|Qt::WindowSystemMenuHint |
|
) |
| |
| virtual MAKLogger::DtLoggerTapeDialog::~DtLoggerTapeDialog |
( |
| ) |
|
|
virtual |
| virtual void MAKLogger::DtLoggerTapeDialog::accept |
( |
| ) |
|
|
protectedvirtual |
Only accept key press or double-click action on a file selection if the Open button is currently enabled.
| virtual void MAKLogger::DtLoggerTapeDialog::addDisplayControlButtons |
( |
| ) |
|
|
protectedvirtual |
Add buttons that control display of configuration panels.
| virtual bool MAKLogger::DtLoggerTapeDialog::descriptionChanged |
( |
| ) |
|
|
virtual |
Get whether the description was changed in the dialog preview widget panel.
| virtual QString MAKLogger::DtLoggerTapeDialog::descriptionText |
( |
| ) |
|
|
virtual |
Get the current description text from the dialog preview widget panel.
| virtual bool MAKLogger::DtLoggerTapeDialog::eventFilter |
( |
QObject * |
obj, |
|
|
QEvent * |
event |
|
) |
| |
|
protectedvirtual |
Make sure the Open button is not enabled when an invalid file selection has been made.
| virtual void MAKLogger::DtLoggerTapeDialog::fileNameTextChanged |
( |
const QString & |
text | ) |
|
|
protectedvirtualslot |
Slot to check for typed filename.
If the file exists, the preview widget panel will be invoked to display the file information. If the file is valid, meaning it is a logger tape file, and it was created for the same protocol as the current application run, the Open button will be enabled, otherwise disabled.
| virtual void MAKLogger::DtLoggerTapeDialog::fileSelectionChanged |
( |
const QString & |
file | ) |
|
|
protectedvirtualslot |
Slot to take the new file selection from the dialog's file list widget and display the file's meta data in the preview widget panel.
If the file is valid, meaning it is a logger tape file, and it was created for the same protocol as the current application run, the Open button will be enabled, otherwise disabled.
Get the media play pipeline info.
| virtual bool MAKLogger::DtLoggerTapeDialog::getRecordStreamPipeline |
( |
DtString & |
streamPipeline | ) |
const |
|
virtual |
Get the play to / record from stream pipelines Return true if there were any pipelines to collect.
| virtual void MAKLogger::DtLoggerTapeDialog::onFolderSelectionChanged |
( |
int |
index | ) |
|
|
protectedvirtualslot |
If the selection in the folder combox box is changed, need to clear the preview display.
| virtual void MAKLogger::DtLoggerTapeDialog::onNavigateButtonClicked |
( |
| ) |
|
|
protectedvirtualslot |
If the back, forward or to parent button is clicked, need to clear the preview display.
| virtual void MAKLogger::DtLoggerTapeDialog::setAppProtocol |
( |
const QString & |
protocol, |
|
|
bool |
display = false |
|
) |
| |
|
virtual |
Set the protocol string for the current application run.
Passed on to the dialog's preview widget panel. Set the display param as true in order to cause the protocol string to also be used for initial display. Used when there is no saved file to read from.
| virtual void MAKLogger::DtLoggerTapeDialog::setDescriptionText |
( |
const QString & |
description | ) |
|
|
virtual |
Set the description text where a description already exists but is not saved.
| virtual void MAKLogger::DtLoggerTapeDialog::setEnablePreviewButton |
( |
bool |
enable | ) |
|
|
virtual |
Set whether the Preview/Edit button is enabled or not.
| virtual void MAKLogger::DtLoggerTapeDialog::setFileWithPath |
( |
const QString |
fileWithPath | ) |
|
|
virtual |
Set the currently opened file.
Used by the Save/SaveAs dialog. This causes the meta data information to appear in the preview widget on opening the dialog.
Set the media play in window and to stream pipeline configurations.
| virtual void MAKLogger::DtLoggerTapeDialog::setMediaRecordConfiguration |
( |
const DtString & |
configuration, |
|
|
int |
port |
|
) |
| |
|
virtual |
Set the media record from stream configuration.
| virtual void MAKLogger::DtLoggerTapeDialog::setNeedUpgradeForDescription |
( |
bool |
current, |
|
|
int |
loadedVersion |
|
) |
| |
|
virtual |
Set whether the file format is current.
On false, if the loaded file version requires an upgrade for writing a description, this will disable the Preview/Edit button and add a tooltip stating that it is necessary to upgrade the logger file in order to add a description.
| virtual void MAKLogger::DtLoggerTapeDialog::setRecordStream |
( |
bool |
value | ) |
|
|
virtual |
set if we record by default.
| virtual void MAKLogger::DtLoggerTapeDialog::setShowDescriptionOnly |
( |
| ) |
|
|
virtual |
Set whether this file dialog will only show the description meta data widget.
Used for all file dialogs except the Open File and Logger Information dialogs.
| virtual void MAKLogger::DtLoggerTapeDialog::setShowEditPanel |
( |
| ) |
|
|
virtual |
Set to toggle into edit mode if not already there.
| virtual void MAKLogger::DtLoggerTapeDialog::setShowPreviewButton |
( |
bool |
show | ) |
|
|
virtual |
Set whether the Preview/Edit button should be shown in the meta data widget panel.
Shown for all file dialogs except for the Open File dialog.
| virtual void MAKLogger::DtLoggerTapeDialog::showLoggerTapeInfo |
( |
| ) |
|
|
virtualslot |
Slot to toggle showing the dialog preview widget panel, depending on whether the dialog's "Show more logger information" button has been clicked.
| QSize MAKLogger::DtLoggerTapeDialog::myDialogSize |
|
protected |
| QToolButton* MAKLogger::DtLoggerTapeDialog::myInfoButton |
|
protected |
| QListView* MAKLogger::DtLoggerTapeDialog::myListView |
|
protected |
| QListWidget* MAKLogger::DtLoggerTapeDialog::myListWidget |
|
protected |
| QPushButton* MAKLogger::DtLoggerTapeDialog::myOpenButton |
|
protected |
| int MAKLogger::DtLoggerTapeDialog::myPreviewPanelWidth |
|
protected |
The documentation for this class was generated from the following file:
Inheritance diagram for MAKLogger::DtLoggerTapeDialog:
