VR-Forces 4.10 Class Documentation
|
All Classes Namespaces Files Functions Variables Typedefs Enumerations Enumerator Properties Friends Macros Groups Pages
|
VR-Forces 4.10 Class Documentation
|
These classes will define simple map data entry. More...
Classes | |
| struct | TableItem |
Public Types | |
| typedef std::vector< TableItem > | Table |
 Public Types inherited from makVrf::DtTaskSetVariableWidgetInterface | |
| enum | CreationFlags { NormalMode = 0x00000000, QtDesignerMode = 0x00000001 } |
Public Member Functions | |
| DtSimpleMapDataWidget (makVrv::DtDe &de, QWidget *parent, const Qt::WindowFlags &flags=0, const CreationFlags &cflags=NormalMode) | |
| virtual | ~DtSimpleMapDataWidget () |
| virtual void | setLabel (const std::string &) |
| Display label. More... | |
| virtual void | setDefaultValue (const std::string &) |
| Default value to set in control. More... | |
| virtual void | setLabel (const QString &) |
| QString version for property. More... | |
| virtual QString | label () const |
| virtual void | clear () |
| virtual void | removeItem (int) |
| Public Member Functions inherited from makVrf::DtTaskSetVariableWidget | |
| DtTaskSetVariableWidget (makVrv::DtDe &de, QWidget *parent, const Qt::WindowFlags &flags=0, const CreationFlags &cflags=NormalMode) | |
| virtual | ~DtTaskSetVariableWidget () |
| virtual void | setToolTip (const QString &) |
| Sets the tool tip. More... | |
| virtual void | setVariableData (const std::string &) |
| Calls QString version. More... | |
| virtual void | setVariableData (const QString &) |
| QString version calls std::string version. More... | |
| virtual QString | variableData () const |
| virtual void | setupFrom (const std::vector< makVrv::DtSimEntry * > &data) |
| Sets up widget with currently selected item. No-op. More... | |
| virtual void | setIsInternal (bool) |
| Whether or not value is internal. Internal values will not be shown to the user on the scripted task dialog. More... | |
| virtual bool | isInternal () const |
| virtual void | setTopLineVisible (bool) |
| Hides top line. More... | |
| virtual bool | topLineVisible () const |
| virtual void | createTopLine () |
| Creates top line. More... | |
| virtual void | setIndent (int) |
| Sets the indent level for the contents of this widget, except for the title line. More... | |
| virtual int | indent () const |
| virtual bool | isValid () const |
| Indicates the current selection is valid. More... | |
| virtual void | setTopLabelChecked (bool) |
| Sets the top label to be checked/unchecked and calls topLabelChecked if the check box is visible. More... | |
| virtual bool | topLabelChecked () const |
| virtual void | setRange (double, double) |
| Sets the range of the item. This widget (by default) does not support that. More... | |
| virtual void | setRange (const DtRange &) |
| virtual void | setRangeTop (double) |
| virtual void | setRangeTop (int) |
| virtual double | rangeTop () const |
| virtual void | setRangeBottom (double) |
| virtual void | setRangeBottom (int) |
| virtual double | rangeBottom () const |
| virtual const DtRange & | getRange () const |
| virtual void | setTopLabelIsCheckable (bool) |
| Sets whether or not the top label is checkable. More... | |
| virtual bool | topLabelIsCheckable () const |
| virtual void | getDefaultSpecificTitles (QString &defaultTitle, QString &specificTitle) const |
| virtual void | setDefaultSpecificTitles (const QString &defaultTitle, const QString &specificTitle) |
| virtual void | setupDefaultSpecificFromVariableData (const DtString &var) |
| Format is allowdefault=[defaultTitle],[specificTitle]. More... | |
| virtual std::string | variableDataFromUiDesigner (const QDomElement &, const DtScriptedTaskVariableLayoutConverter &) const |
| Given the Ui designer properties create a string that will represent the variable data for those properties. More... | |
| virtual std::string | scriptedTaskVariableName () const |
| In most cases this is the objectName of the object, however, in some cases (as in radio button) this could be a name that is shared amongst like objects, so, that is returned instead. More... | |
| virtual void | setSelection (const std::set< makVrv::DtUniqueID > &selection) |
| The selection set can be used to determine the diplay units to show. More... | |
| virtual void | setSelection (const std::vector< makVrv::DtSimEntry * > &data) |
| virtual const std::set < makVrv::DtUniqueID > & | selection () const |
| Public Member Functions inherited from makVrf::DtTaskSetVariableWidgetInterface | |
| DtTaskSetVariableWidgetInterface () | |
| virtual | ~DtTaskSetVariableWidgetInterface () |
| virtual void | widgetInitializedForDialog (DtScriptedTaskDialog *, const std::vector< makVrv::DtSimEntry * > &data) |
| Called when the widget is initialized from a scripted task dialog. Default implementation is to do nothing. More... | |
| virtual DtReaderWriter * | createBoundVariable (const std::string &variableName)=0 |
| Creates the reader/writer variable that will be used as part of the task statement. More... | |
| virtual void | setupFromBoundVariable (const DtReaderWriter *variableName)=0 |
| Sets up the widget from the given reader/writer variables. More... | |
| virtual DtTaskSetVariableWidgetExtensionInterface * | parameterContents (QWidget *parent, const Qt::WindowFlags &flags=0) const |
| If there are any, returns contents for this variable for variable extension. Default is no extension. More... | |
| virtual bool | guiElementOnly () const |
| Returns true if this is a GUI element only. Default is false. More... | |
Public Attributes | |
| QLabel * | myLabel |
| QScrollArea * | myScrollArea |
| QWidget * | myScrollAreaCanvas |
| QGridLayout * | myGridLayout |
| QPushButton * | myAdd |
| QHBoxLayout * | myButtonLayout |
| Table | myTable |
| Public Attributes inherited from makVrf::DtTaskSetVariableWidget | |
| boost::signals2::signal< void(bool)> | signal_topLevelCheckStateChanged |
| int | myIndent |
| QVBoxLayout * | myVariableWidgetLayout |
| QHBoxLayout * | mySpacedLayout |
| QVBoxLayout * | myVariableContentLayout |
| When creating subclasses of this item, use the variable content layout to add your content. More... | |
| QWidget * | myTopLine |
| QLabel * | myTopLabel |
| QWidget * | myChoiceCanvas |
| QRadioButton * | myUseDefault |
| QRadioButton * | myUseSpecific |
| QSpacerItem * | myTopSeparator |
| QHBoxLayout * | myTopLineLayout |
| QSpacerItem * | mySpacerItem |
Protected Slots | |
| virtual void | onAddItem ()=0 |
| virtual void | onRemoveItem () |
| Protected Slots inherited from makVrf::DtTaskSetVariableWidget | |
| virtual void | topLabelCheckStateChanged () |
Protected Member Functions | |
| virtual int | currentRowFor (QObject *sender) const |
| virtual DtString | uniqueKey (const DtString &) const |
| virtual DtString | keyFrom (const TableItem &) const |
| virtual QWidget * | createKey (const DtString &) |
| virtual QWidget * | createValue () |
| virtual void | addItem (const TableItem &) |
| Protected Member Functions inherited from makVrf::DtTaskSetVariableWidget | |
| virtual void | selectionChanged (const std::set< makVrv::DtUniqueID > &oldSelection) |
| Called when the selection has changed via setSelection. More... | |
Additional Inherited Members | |
| Signals inherited from makVrf::DtTaskSetVariableWidget | |
| void | validityUpdated () |
| Signal which can be emitted to indicate the validity of the current widget selection has changed. More... | |
| Static Public Member Functions inherited from makVrf::DtTaskSetVariableWidget | |
| static bool | includeInQtDesigner () |
| Static Public Member Functions inherited from makVrf::DtTaskSetVariableWidgetInterface | |
| static bool | canBeUsedAsWidget () |
| Whether or not this shows up as a usable variable widget. More... | |
| static void | initializeForQtDesignerExtension (makVrv::DtDe &de, QDesignerFormEditorInterface *core) |
| Implement at class level to perform Qt Designer custom widget initialization. Please refer to Qt documentation for designer modifications. More... | |
| static bool | includeInQtDesigner () |
| Protected Attributes inherited from makVrf::DtTaskSetVariableWidget | |
| makVrv::DtDe & | myDe |
| makVrv::DtSignalConnectionManager | myConnections |
| bool | myTopLabelIsCheckable |
| DtRange | myRange |
| bool | myIsInternal |
| CreationFlags | myCreationFlags |
| QString | myVariableData |
| std::set< makVrv::DtUniqueID > | mySelection |
| Properties inherited from makVrf::DtTaskSetVariableWidget | |
| QString | label |
| bool | isInternal |
| int | indent |
| QString | variableData |
These classes will define simple map data entry.
The subclasses will create the right type of RW classes based on their type and validate the values as need be
| typedef std::vector<TableItem> makVrf::DtSimpleMapDataWidget::Table |
| makVrf::DtSimpleMapDataWidget::DtSimpleMapDataWidget | ( | makVrv::DtDe & | de, |
| QWidget * | parent, | ||
| const Qt::WindowFlags & | flags = 0, |
||
| const CreationFlags & | cflags = NormalMode |
||
| ) |
|
virtual |
|
virtual |
Display label.
Reimplemented from makVrf::DtTaskSetVariableWidget.
|
virtual |
Default value to set in control.
Implements makVrf::DtTaskSetVariableWidgetInterface.
|
virtual |
QString version for property.
Reimplemented from makVrf::DtTaskSetVariableWidget.
|
virtual |
Reimplemented from makVrf::DtTaskSetVariableWidget.
|
virtual |
Reimplemented in makVrf::DtSimpleAircraftMapWidget.
|
virtual |
Reimplemented in makVrf::DtSimpleAircraftMapWidget.
|
protectedpure virtualslot |
|
protectedvirtualslot |
|
protectedvirtual |
|
protectedvirtual |
Reimplemented in makVrf::DtSimpleAircraftMapWidget.
|
protectedvirtual |
Reimplemented in makVrf::DtSimpleAircraftMapWidget.
|
protectedvirtual |
|
protectedvirtual |
| QLabel* makVrf::DtSimpleMapDataWidget::myLabel |
| QScrollArea* makVrf::DtSimpleMapDataWidget::myScrollArea |
| QWidget* makVrf::DtSimpleMapDataWidget::myScrollAreaCanvas |
| QGridLayout* makVrf::DtSimpleMapDataWidget::myGridLayout |
| QPushButton* makVrf::DtSimpleMapDataWidget::myAdd |
| QHBoxLayout* makVrf::DtSimpleMapDataWidget::myButtonLayout |
| Table makVrf::DtSimpleMapDataWidget::myTable |
