| | DtSphereEntryWidget (makVrv::DtDe &de, QWidget *parent, const Qt::WindowFlags &flags=0, const CreationFlags &cflags=NormalMode) |
| |
| virtual | ~DtSphereEntryWidget () |
| |
| virtual double | radius () const |
| | Returns the radius value in meters. More...
|
| |
| virtual void | setRadius (double) |
| | Sets the radius value (supplied in meters). More...
|
| |
| virtual DtReaderWriter * | createBoundVariable (const std::string &variableName) |
| | Creates the reader/writer variable that will be used as part of the task statement. More...
|
| |
| virtual void | setupFromBoundVariable (const DtReaderWriter *variableName) |
| | Sets up the widget from the given reader/writer variables. More...
|
| |
virtual
DtTaskSetVariableWidgetExtensionInterface * | parameterContents (QWidget *parent, const Qt::WindowFlags &flags=0) const |
| | Return extension that allows entry of default and range values in meters. More...
|
| |
| virtual void | setRadiusLabel (const QString &) |
| |
| virtual QString | radiusLabel () const |
| |
| virtual void | setDefaultRadius (double) |
| |
| virtual double | defaultRadius () const |
| |
| virtual void | refreshLabels () |
| |
| virtual void | setShowSphere (bool) |
| | Sets whether or not to show sphere. If true and has map focus will show the sphere. More...
|
| |
| bool | showSphere () const |
| |
| virtual void | setupSphere () |
| | Sets up sphere. If not created creates if have map focus. More...
|
| |
| virtual void | setHasMapFocus (bool) |
| | Called when takes map focus (or not). More...
|
| |
| virtual void | setMaintainCurrentAltitude (bool) |
| | Never maintain current altitude. More...
|
| |
| virtual void | setProcessMouseEvents (bool) |
| | Only process mouse events if not showing event handler. More...
|
| |
| virtual void | setHasBeenPlaced (bool b) |
| |
| bool | hasBeenPlaced () const |
| |
|
| virtual void | setRange (double bottom, double top) |
| |
| virtual void | setDefaultValue (const std::string &) |
| | Default value to set in control. Value is X;Y;Z;Radius. More...
|
| |
| virtual void | setVariableData (const QString &) |
| | Variable data that can be used by this control to initialize values (i.e. More...
|
| |
| | DtLocationEntryWidget (makVrv::DtDe &de, QWidget *parent, const Qt::WindowFlags &flags=0, const CreationFlags &cflags=NormalMode) |
| | Constructor. More...
|
| |
| virtual | ~DtLocationEntryWidget () |
| |
| virtual DtVector | location () const |
| | Returns value in meters and local. More...
|
| |
| virtual DtVector | geocentricLocation () const |
| | Returns value as geocentric. More...
|
| |
| virtual void | setUseInputValidation (bool) |
| | Sets whether or not to use input validation. Defaults to true. More...
|
| |
| virtual bool | useInputValidation () const |
| |
| virtual void | setUseHighestLOD (bool) |
| |
| virtual bool | useHighestLOD () const |
| |
| virtual void | blockSignals (bool) |
| | Block boost signals from being sent. More...
|
| |
| bool | signalsBlocked () const |
| |
| virtual void | setLocation (DtVector, bool resetAltitude=true) |
| | Expects value in meters and local. More...
|
| |
| virtual void | setGeocentricLocation (DtVector, bool resetAltitude=true) |
| |
| virtual void | setAltitude (const DtVector &localLocation, bool resetAltitude=true) |
| |
| virtual void | setCoordinateSystem (makVrv::DtCoordinateDisplay *) |
| | The coordinate system of the current values. More...
|
| |
| virtual void | setHideAltitude (bool b) |
| | Hides/shows the Z (altitude) section. More...
|
| |
| virtual void | setHideLocationZ (bool b) |
| | Hides/shows the myLocationZ line edit. More...
|
| |
| virtual void | setXYValidatorsEnabled (bool enabled) |
| | Set lat/lon validator enabled state. More...
|
| |
| virtual bool | xyValidatorsEnabled () const |
| |
| virtual void | setAdvancedKeyboardHandling (bool) |
| |
| virtual bool | advancedKeyboardHandling () const |
| |
| virtual void | setXLabel (const QString &) |
| | Sets label titles. More...
|
| |
| QString | xLabel () const |
| |
| virtual void | setYLabel (const QString &) |
| |
| QString | yLabel () const |
| |
| virtual void | setZLabel (const QString &) |
| |
| QString | zLabel () const |
| |
| virtual void | setXValue (const QString &) |
| | Sets values. More...
|
| |
| virtual void | setYValue (const QString &) |
| |
| virtual void | setZValue (const QString &) |
| |
| virtual QString | xValue () const |
| |
| virtual QString | yValue () const |
| |
| virtual QString | zValue () const |
| |
| DtAltitudeSelectionWidget * | altitudeWidget () |
| |
| virtual void | setAltitudeAboveSeaLevelVisible (bool b) |
| |
| virtual void | setAltitudeAboveGroundLevelVisible (bool b) |
| |
| virtual void | setCreator (int, DtLocationCSEntryCreatorInterface *) |
| |
| virtual DtGeodeticCoord | geodeticLocation () const |
| |
| virtual void | setCoordinateSystem (const makArchives::DtDisplayUnitsSettingsRecord::CoordSys &coordSys) |
| | Calls down to logic to set coordinate system. More...
|
| |
const
makArchives::DtDisplayUnitsSettingsRecord::CoordSys & | coordinateSystem () const |
| |
| virtual void | setCoordinateSystemDecimals (int decimals) |
| | Sets the precision of the x, y and z line edits. More...
|
| |
| virtual void | setAltitudeSelectionEnabled (bool) |
| |
| virtual bool | altitudeSelectionEnabled () const |
| |
| virtual void | setZEnabled (bool) |
| |
| virtual void | changeAltitudeEnabledSettings (bool) |
| |
| virtual void | setCurrentAltitudeTypeSelection (const DtAltitudeClampType &type) |
| |
| virtual DtAltitudeClampType | currentAltitudeTypeSelection () const |
| |
| virtual double | altitudeAboveSeaLevel () const |
| |
| virtual double | altitudeAboveGroundLevel () const |
| |
| virtual void | setAltitudeAboveSeaLevel (double altitude) |
| | Sets the altitude location. More...
|
| |
| virtual void | setAltitudeAboveGroundLevel (double altitude) |
| | Sets the altitude location. More...
|
| |
| virtual bool | processMouseEvents () |
| |
| virtual void | setAltitudeAboveGroundLevelSelected (bool b) |
| |
| virtual void | setAltitudeAboveSeaLevelSelected (bool b) |
| |
| virtual void | setClampToNearestPolygon (bool) |
| | Sets whether or not to clamp to nearest polygon when selecting altitude. More...
|
| |
| virtual void | setIgnoreList (const std::vector< makVrv::DtElementID > &) |
| | List of objects to ignore when getting intersections. More...
|
| |
virtual const std::vector
< makVrv::DtElementID > & | ignoreList () const |
| |
| virtual void | setupFrom (const std::vector< makVrv::DtSimEntry * > &data) |
| | Sets up from initial data. More...
|
| |
| virtual bool | maintainCurrentAltitude () const |
| |
| virtual void | setupBasedOnEntityType (const DtEntityType &) |
| | Sets up whether or not to maintain current altitude on placement based on entity kind. More...
|
| |
| virtual void | setProcessAltitudeMouseClicks (bool b) |
| |
| virtual void | setSignalLocationSetOnly (bool) |
| | Sets to signal the location change by mouse set only – do not set in gui as it is expected that others will do that. More...
|
| |
| virtual bool | signalLocationSetOnly () const |
| |
| virtual bool | validateLocation (bool warn=false) |
| | Will warn if flag is true via message box and/or will send signals for valid, invalid location. More...
|
| |
| virtual void | setInvalid (bool) |
| |
| virtual bool | invalid () const |
| |
| virtual void | setUseLabelForLocationEntry (bool) |
| | Tells if we want that location entry get displayd as label instead of line edit. More...
|
| |
| virtual bool | useLabelForLocationEntry () const |
| |
| virtual void | setCanTakeMapFocus (bool) |
| |
| virtual bool | canTakeMapFocus () const |
| |
| virtual bool | hasMapFocus () const |
| |
| | DtTaskSetVariableWidget (makVrv::DtDe &de, QWidget *parent, const Qt::WindowFlags &flags=0, const CreationFlags &cflags=NormalMode) |
| |
| virtual | ~DtTaskSetVariableWidget () |
| |
| virtual void | setToolTip (const QString &) |
| | Sets the tool tip. More...
|
| |
| virtual void | setLabel (const std::string &) |
| | Display label. More...
|
| |
| virtual void | setLabel (const QString &) |
| | QString version for property. More...
|
| |
| virtual void | setVariableData (const std::string &) |
| | Calls QString version. More...
|
| |
| virtual QString | variableData () const |
| |
| virtual QString | label () const |
| |
| virtual void | setIsInternal (bool) |
| | Whether or not value is internal. Internal values will not be shown to the user on the scripted task dialog. More...
|
| |
| virtual bool | isInternal () const |
| |
| virtual void | setTopLineVisible (bool) |
| | Hides top line. More...
|
| |
| virtual bool | topLineVisible () const |
| |
| virtual void | createTopLine () |
| | Creates top line. More...
|
| |
| virtual void | setIndent (int) |
| | Sets the indent level for the contents of this widget, except for the title line. More...
|
| |
| virtual int | indent () const |
| |
| virtual bool | isValid () const |
| | Indicates the current selection is valid. More...
|
| |
| virtual void | setTopLabelChecked (bool) |
| | Sets the top label to be checked/unchecked and calls topLabelChecked if the check box is visible. More...
|
| |
| virtual bool | topLabelChecked () const |
| |
| virtual void | setRange (const DtRange &) |
| |
| virtual void | setRangeTop (double) |
| |
| virtual void | setRangeTop (int) |
| |
| virtual double | rangeTop () const |
| |
| virtual void | setRangeBottom (double) |
| |
| virtual void | setRangeBottom (int) |
| |
| virtual double | rangeBottom () const |
| |
| virtual const DtRange & | getRange () const |
| |
| virtual void | setTopLabelIsCheckable (bool) |
| | Sets whether or not the top label is checkable. More...
|
| |
| virtual bool | topLabelIsCheckable () const |
| |
| virtual void | getDefaultSpecificTitles (QString &defaultTitle, QString &specificTitle) const |
| |
| virtual void | setDefaultSpecificTitles (const QString &defaultTitle, const QString &specificTitle) |
| |
| virtual void | setupDefaultSpecificFromVariableData (const DtString &var) |
| | Format is allowdefault=[defaultTitle],[specificTitle]. More...
|
| |
| virtual std::string | scriptedTaskVariableName () const |
| | In most cases this is the objectName of the object, however, in some cases (as in radio button) this could be a name that is shared amongst like objects, so, that is returned instead. More...
|
| |
| virtual void | setSelection (const std::set< makVrv::DtUniqueID > &selection) |
| | The selection set can be used to determine the diplay units to show. More...
|
| |
| virtual void | setSelection (const std::vector< makVrv::DtSimEntry * > &data) |
| |
virtual const std::set
< makVrv::DtUniqueID > & | selection () const |
| |
| | DtTaskSetVariableWidgetInterface () |
| |
| virtual | ~DtTaskSetVariableWidgetInterface () |
| |
| virtual void | widgetInitializedForDialog (DtScriptedTaskDialog *, const std::vector< makVrv::DtSimEntry * > &data) |
| | Called when the widget is initialized from a scripted task dialog. Default implementation is to do nothing. More...
|
| |
| virtual bool | guiElementOnly () const |
| | Returns true if this is a GUI element only. Default is false. More...
|
| |
| virtual | ~DtLocationEntryWidgetInterface () |
| |
virtual const std::set
< makVrv::DtUniqueID > & | selection () const |
| |
 Public Member Functions inherited from makVrf::DtMapFocusHandler |
| | DtMapFocusHandler () |
| | CTOR. More...
|
| |
| virtual | ~DtMapFocusHandler () |
| | DTOR. More...
|
| |
| virtual void | clearMapFocusSelectedByUser () |
| | If mapFocusSelectedByUser is true will prevent focus from automatically changing to another control. More...
|
| |
| virtual bool | mapFocusSelectedByUser () const |
| |
Widget that will allow the user to enter a sphere (center and radius).
If enabled (which is true, but default) when this widget has focus (either map focus or window focus) a sphere will be placed on the map that the user can manipulate
