VR-Forces 4.5 Class Documentation
|
This class is similar to DtRwProperty, but allows you to specify a threshold at which the value should be considered different enough to require an update. More...
Public Member Functions | |
| DtRwPropertyWithThreshold (const DtString &name, DtReaderWriterRegistry *parentRegistry=0) | |
| DtRwPropertyWithThreshold (const DtString &name, const DtRwPropertyWithThreshold &orig, DtReaderWriterRegistry *parentRegistry=0) | |
| DtRwPropertyWithThreshold & | operator= (const DtRwPropertyWithThreshold &orig) |
| virtual | ~DtRwPropertyWithThreshold () |
| virtual char * | encode (char *) const |
| These methods are for network encoding/decoding for Hla encoding decoding reasons. | |
| virtual bool | wasUpdatedSince (DtTime t) const |
| Returns true if an update occurred since the specified time and the current value is at least _Threshold percent away from the previous encoded value. | |
| virtual void | enableThresholding (bool enable) |
| Enables or disables thresholding of this property. Enabled by default. | |
| virtual void | setThreshold (double percentage) |
| Changes the threshold for when an update should be sent. | |
| virtual void | setMaxUpdateInterval (DtTime interval) |
| Changes the maximum time between updates if data has changed but has not crossed the threshold for an update. | |
| virtual void | setMaxUnchangedUpdateInterval (DtTime interval) |
| Changes the maximum time between updates if data has changed but has not crossed the threshold for an update, but seems to have settled on a new value. | |
 Public Member Functions inherited from DtRwProperty< _RwType > | |
| DtRwProperty (const DtString &name, DtReaderWriterRegistry *parentRegistry=0) | |
| DtRwProperty (const DtString &name, const DtRwProperty &orig, DtReaderWriterRegistry *parentRegistry=0) | |
| DtRwProperty & | operator= (const DtRwProperty &orig) |
| virtual | ~DtRwProperty () |
| virtual const char * | decode (const char *) |
| Decodes the variable bindings from the specified buffer. | |
| virtual DtString | stringRep (const DtString &root="") const |
| virtual void | getSize (int &size) const |
| Returns the size of this item, iterating over all types. | |
| virtual int | hlaAlignment () const |
| Returns hlaAlignment. | |
| virtual const char * | propertyType () const |
| Typically returns reader/writer type. | |
| virtual DtlObjPtr | getData (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| Override to allow a variable to be assigned to a property of derived type. | |
| virtual bool | merge (const DtPropertyInterface &target, MergeFlags, const DtMergePath &path=DtMergePath(), const std::set< DtString > &ignore=std::set< DtString >()) |
| In this case replace does not matter – will replace value regardless. | |
| virtual void | recordUpdateTime () const |
| Stamps the time when updated. | |
| virtual void | reset () |
| Override to clear out variable value. | |
| virtual DtReaderWriter * | readerWriter () |
| virtual const DtReaderWriter * | readerWriter () const |
| virtual DtPropertyInterface * | property () |
| virtual const DtPropertyInterface * | property () const |
| Public Member Functions inherited from DtPropertyInterface | |
| virtual | ~DtPropertyInterface () |
| int | getSize () const |
| virtual bool | isSimilarProperty (const DtPropertyInterface *rhs) const |
| Returns true if the readerWriterType is the same. | |
Static Public Member Functions | |
| static void | setDefaultThreshold (double percentage) |
| Changes the default threshold for cases when setThreshold() has not been called. | |
| static void | setDefaultMaxUpdateInterval (DtTime interval) |
| Changes the default max update interval for cases when setMaxUpdateInterval() has not been called. | |
| static void | setDefaultMaxUnchangedUpdateInterval (DtTime interval) |
| Changes the default max unchanged update interval for cases when setMaxUnchangedUpdateInterval() has not been called. | |
Protected Attributes | |
| bool | myThresholdingEnabled |
| Whether thresholding is currently enabled. | |
| _RwType | myLastEncodedValue |
| The value at the last time the value was encoded. | |
| DtTime | myLastEncodeTime |
| The time the value was last encoded. | |
| double | myThreshold |
| DtTime | myMaxUpdateInterval |
| DtTime | myMaxUnchangedUpdateInterval |
| Protected Attributes inherited from DtRwProperty< _RwType > | |
| DtClock | myClock |
| DtTime | myUpdateTime |
Static Protected Attributes | |
| static double | myDefaultThreshold |
| static DtTime | myDefaultMaxUpdateInterval |
| static DtTime | myDefaultMaxUnchangedUpdateInterval |
Private Member Functions | |
| DtRwPropertyWithThreshold () | |
| Not implemented. | |
Additional Inherited Members | |
| Public Types inherited from DtPropertyInterface | |
| enum | MergeFlags { Replace = 0x00000001, MinimalSimilarityCheck = 0x00000002, RollUp = 0x00000004, AddMissing = 0x00000008 } |
This class is similar to DtRwProperty, but allows you to specify a threshold at which the value should be considered different enough to require an update.
wasUpdatedSince() will return false until the threshold is met. The threshold is defined as a percentage of the current value.
|
private |
Not implemented.
| DtRwPropertyWithThreshold< _RwType >::DtRwPropertyWithThreshold | ( | const DtString & | name, |
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
| DtRwPropertyWithThreshold< _RwType >::DtRwPropertyWithThreshold | ( | const DtString & | name, |
| const DtRwPropertyWithThreshold< _RwType > & | orig, | ||
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
|
virtual |
| DtRwPropertyWithThreshold& DtRwPropertyWithThreshold< _RwType >::operator= | ( | const DtRwPropertyWithThreshold< _RwType > & | orig | ) |
|
virtual |
These methods are for network encoding/decoding for Hla encoding decoding reasons.
Implemented at templated rw level. Encodes the variable bindings into the supplied buffer. In addition, stores the value in myLastEncodedValue for threshold testing.
Reimplemented from DtRwProperty< _RwType >.
|
virtual |
Returns true if an update occurred since the specified time and the current value is at least _Threshold percent away from the previous encoded value.
Reimplemented from DtRwProperty< _RwType >.
|
virtual |
Enables or disables thresholding of this property. Enabled by default.
|
virtual |
Changes the threshold for when an update should be sent.
If the percentage change of the value is greater than this threshold, wasUpdatedSince() will return true.
|
static |
Changes the default threshold for cases when setThreshold() has not been called.
|
virtual |
Changes the maximum time between updates if data has changed but has not crossed the threshold for an update.
This ensures that periodically subscribers receive current data, even if the value has only changed a small amount.
|
static |
Changes the default max update interval for cases when setMaxUpdateInterval() has not been called.
|
virtual |
Changes the maximum time between updates if data has changed but has not crossed the threshold for an update, but seems to have settled on a new value.
For instance, if the threshold his 2%, and a value goes from 99 to 100 where it caps out, it will never hit the 2% mark, and therefore an update would otherwise not be sent for a full minute. This setting indicates how long a value should stabilize, remaining unchanged, before we send it. Should be greater than the tick rate but less than the max update interval.
|
static |
Changes the default max unchanged update interval for cases when setMaxUnchangedUpdateInterval() has not been called.
|
protected |
Whether thresholding is currently enabled.
|
mutableprotected |
The value at the last time the value was encoded.
|
mutableprotected |
The time the value was last encoded.
|
staticprotected |
|
protected |
|
staticprotected |
|
protected |
|
staticprotected |
|
protected |
