VR-Forces 4.6 Class Documentation
|
Dt2DEnvironmentalAreaVisualizer display a Area drawn as an overlay Area in the scene without occlusion. More...
Public Member Functions | |
| Dt2DEnvironmentalAreaVisualizer (DtBaseConnection &simulation, DtStateListener &listener, int modelSet) | |
| Constructor. | |
| virtual | ~Dt2DEnvironmentalAreaVisualizer () |
| Destructor. | |
| virtual const DtStateVisualizer::TypeInfo & | typeInfo () const |
| Get the instance's type info. | |
| virtual void | startAttached () |
| Override to use a different embarkation updater for the overlay polygon. | |
 Public Member Functions inherited from makVrv::DtEnvironmentalAreaVisualizer | |
| DtEnvironmentalAreaVisualizer (DtBaseConnection &simulation, DtStateListener &listener, int modelSet) | |
| Constructor. | |
| virtual | ~DtEnvironmentalAreaVisualizer () |
| Destructor. | |
| virtual void | setColor (float r, float g, float b, float a) |
| Sets the color for the area. | |
| virtual void | useDefaultColor () |
| Sets color to default color as defined in the visualizer definition. | |
| virtual void | getColor (float &r, float &g, float &b, float &a) const |
| Returns the color. | |
| virtual void | addPoint (int index, const DtVector &) |
| Adds a point to the Area. If index is -1, appends else places at given point. | |
| virtual void | removePoint (int index) |
| Removes point at the given index. | |
| virtual void | modifyPoint (int index, const DtVector &) |
| Modifies the point at the given index. | |
| virtual void | setPoints (const DtEnvironmentalStateListener::ControlPointsList &) |
| Sets the control points to the specified list, adding, removing and changing as needed. | |
| virtual void | setSelected (bool b) |
| Selects the entire Area. | |
| virtual void | resetSpatial () |
| Resets geometry of Area. | |
| virtual void | createModelAgents () |
| Creates the model agents associated with the Area. | |
| virtual void | setStipplePattern (unsigned short) |
| Sets the line style of the outline of the area. | |
| virtual unsigned short | lineStipple () const |
| virtual void | setScribed (bool) |
| Sets whether or not to scribe the line (and edges) | |
| virtual void | setFillStyle (vrvTacticalGraphicUtilities::FillStyle) |
| Sets the fill style of the area. | |
| virtual vrvTacticalGraphicUtilities::FillStyle | fillStyle () const |
| Returns the currently set fill style. | |
| virtual void | setPenStyle (vrvTacticalGraphicUtilities::PenStyle) |
| Takes the pen style and translates it to a stipple pattern. | |
| virtual void | setPixelLineWidth (int) |
| Sets the width of the outside line. | |
| virtual void | setOrigin (const DtVector &) |
| Sets the origin of the area. | |
| virtual void | setUseDynamicOrigin (bool) |
| Set whether or not to use dynamic origin. | |
| DtAreaFacadeBase * | areaFacade () const |
| Area facade used by this visualizer. | |
| virtual void | setAttached (DtUniqueID) |
| Sets this object to be attached to the specified object. | |
| virtual void | setPickable (bool) |
| Whether or not the area can be pickable. | |
| Public Member Functions inherited from makVrv::DtSceneObjectVisualizer | |
| DtSceneObjectVisualizer (DtBaseConnection &simulation, DtStateListener &listener, int modelSet) | |
| virtual | ~DtSceneObjectVisualizer () |
| virtual DtUniqueID | uniqueID () const |
| Return unique id of mySceneObjectAgent, if it exists, else returns 0;. | |
| virtual DtSceneObjectAgent * | sceneObjectAgent () |
| virtual void | setParent (DtStateVisualizer *p) |
| Override of base class setParent to simply set the parent without destroying/recreating model agents. | |
| virtual void | setSceneObjectAgent (DtSceneObjectAgent *) |
| virtual void | setElementID (const DtElementID &elementID) |
| DtElementID | elementID () const |
| virtual bool | show (int) |
| Override to show/hide scene object agent (if it exists) | |
| virtual bool | hide (int) |
| Will call destroyModelAgents(), if, when the context is added, it is the first context in the list. | |
| Public Member Functions inherited from makVrv::DtStateVisualizer | |
| DtStateVisualizer (DtBaseConnection &connection, DtStateListener &listener, int modelSet) | |
| CTOR. | |
| virtual | ~DtStateVisualizer () |
| DTOR. | |
| void | setModelDefinition (const std::string &definition) |
| Sets the model definition and creates agent(s) based on that definition. | |
| const std::string & | modelDefinition () const |
| Gets the current model definition. | |
| virtual bool | setVisible (bool visible, int context) |
| Returns true if this context wants to show or hide the item. | |
| virtual void | initialize () |
| Initialize the visualizer. | |
| virtual bool | isVisible () const |
| Returns true if visible. | |
| virtual bool | selected () const |
| void | setName (const std::string &) |
| Internal name of state visualizer. | |
| const std::string & | name () const |
| virtual bool | pickable () const |
| virtual void | setUniqueID (DtUniqueID id) |
| int | visualizerType () const |
| void | setShowHideContext (const std::vector< int > &s) |
| Set show/hide context without changing visibility of item. | |
| DtStateListener & | listener () |
| DtBaseConnection & | simulation () |
| Get the connection for this visualizer. | |
| void | setDistribute (bool b) |
| Whether or not to distribute over the network. | |
| bool | distribute () const |
Static Public Member Functions | |
| static const DtStateVisualizer::TypeInfo & | theTypeInfo () |
| The class's type info. | |
Protected Member Functions | |
| virtual DtAreaFacadeBase * | createAreaFacade () |
| Create the area facade. | |
| Protected Member Functions inherited from makVrv::DtEnvironmentalAreaVisualizer | |
| virtual void | destroyModelAgents () |
| Destroys any model agents currently created. | |
| virtual void | setModelDefinitionForAgents () |
| Sets model definitions for agents. | |
| virtual void | setVisualizerDefinition (const DtVisualizerDefinition &visDef) |
| Set any other additional visualizer information from the visual record. | |
| virtual DtVector | offsetAtPosition (const DtVector &position) const |
| Given the origin and the point offset, return an offset that is valid at the given position. | |
| virtual void | setSolid (bool) |
| virtual void | setupArea (DtAreaFacadeBase *) |
| Sets the newly created area up with current values. | |
| virtual void | endAttached () |
| Ends the attachment process. | |
| virtual void | setRelativeLocation (const DtVector &) |
| virtual void | setOffsetPoints (const std::vector< DtVector > &) |
| These are the relative offsets from the origin of this object that the point of this object represent. | |
| Protected Member Functions inherited from makVrv::DtSceneObjectVisualizer | |
| virtual DtSceneObjectAgent * | createObjectAgent () |
| Protected Member Functions inherited from makVrv::DtStateVisualizer | |
| virtual void | slot_mouseDown (DtMouseState &mouseState, const std::string &displayEngineName, const std::string &windowName, const std::string &channelName) |
| Called when the mouse is clicked in this visualizer. | |
| virtual void | slot_mouseUp (DtMouseState &mouseState, const std::string &displayEngineName, const std::string &windowName, const std::string &channelName) |
| virtual void | slot_mouseDblClick (DtMouseState &mouseState, const std::string &displayEngineName, const std::string &windowName, const std::string &channelName) |
| virtual bool | supportsShowHideContext (int) const |
| Default returns true. | |
| template<typename T , typename C > | |
| void | connectAndUpdate (boost::signal< void(T)> &sig, void(C::*fp)(T), T val) |
| Connect a signal and update the entity. | |
Dt2DEnvironmentalAreaVisualizer display a Area drawn as an overlay Area in the scene without occlusion.
| makVrv::Dt2DEnvironmentalAreaVisualizer::Dt2DEnvironmentalAreaVisualizer | ( | DtBaseConnection & | simulation, |
| DtStateListener & | listener, | ||
| int | modelSet | ||
| ) |
Constructor.
|
virtual |
Destructor.
|
virtual |
Get the instance's type info.
Implements makVrv::DtStateVisualizer.
|
virtual |
Override to use a different embarkation updater for the overlay polygon.
Reimplemented from makVrv::DtEnvironmentalAreaVisualizer.
Reimplemented in makVrv::DT_PROTOCOL_NAMESPACE::DtVrlink2DEnvironmentalAreaVisualizer.
|
static |
The class's type info.
|
protectedvirtual |
Create the area facade.
Implements makVrv::DtEnvironmentalAreaVisualizer.
