Public Member Functions |
| | DtVrfOverlayObjectStateRepository (DtVrfObject *vrfObject, const DtObjectType &objectType, DtVrfObjectParameters *parameters, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) |
| | Constructor.
|
| | DtVrfOverlayObjectStateRepository (const DtVrfOverlayObjectStateRepository &orig, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) |
| | Copy Constructor.
|
const
DtVrfOverlayObjectStateRepository & | operator= (const DtVrfOverlayObjectStateRepository &orig) |
| | Assignment Operator.
|
| virtual | ~DtVrfOverlayObjectStateRepository () |
| | Destructor.
|
| virtual double | sensorSignature (const DtSymbolString &sensorDomain) const |
| | If this item is an event or something that has a sensor signature, return that sensor signate for the given domain here.
|
| virtual void | setSensorSignature (const DtSymbolString &domain, double) |
| | Adds a new sensor signature for the domain.
|
| virtual void | removeSensorSignature (const DtSymbolString &) |
| | Removes the sensor signature for the domain.
|
virtual const std::map
< DtSymbolString, double > & | sensorSignatures () const |
| | Returns sensor signatures.
|
virtual
DtSimObjectStateRepository * | clone (const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) const |
| | Clone.
|
| virtual DtString | type () const |
| | returns DtSimObjectStateRepositoryType
|
| virtual const int | vrfObjectStateRepositorySubType () const |
| | Returns DtVrfObjectStateRepositorySubTypeOverlay.
|
| virtual bool | activated () const |
| | Returns true if this object is active.
|
| virtual void | setActivated (bool) |
| virtual void | setAssumeUnknownIsHostile (bool) |
| | Whether or not, if this is an engagement area, to have this adjust unknown force to a force that is hostile to the entity.
|
| virtual bool | assumeUnknownIsHostile () const |
| virtual void | updateBasedOnActivationState () |
| virtual bool | shouldActivate () |
| | Returns true if environmental should be activated.
|
| virtual bool | shouldDeactivate () |
| | Returns true if environmental should be deactivated.
|
| virtual void | attachToParent (DtSimObjectStateRepository *parent) |
| | Since this does not have dead reckoning, slow down the publisher (if local) to prevent network flood when object is moving.
|
| virtual void | attachToParent (const DtUUID &parent) |
| | Looks up the parent state repository using the given echelon ID and puts it in a call to attachToParent.
|
| virtual void | detachFromParent () |
| virtual void | setAttachedTickRateForPublication (double) |
| | Default is 1 seconds.
|
| virtual double | attachedTickRateForPublication () const |
| virtual int | color () const |
| virtual void | setColor (int color) |
| virtual void | setColor (const DtRwColor &) |
| virtual void | setColor (DtU8 red, DtU8 green, DtU8 blue, DtU8 alpha) |
| virtual const DtString & | parentName () const |
| virtual void | setParentName (const DtString &parentName) |
| virtual void | setUserData (const char *data, int dataLen) |
| virtual const DtString & | userData () const |
| virtual double | ceiling () const |
| | Note that if the ceiling becomes lower than the floor the floor will change to match Ceiling is the floor plus the physical line height.
|
| virtual void | setCeiling (double) |
| virtual void | setPhysicalLineHeight (double) |
| virtual double | physicalLineHeight () const |
| virtual bool | ceilingSet () const |
| virtual double | floor () const |
| | The floor is taken as the altitude of the first point.
|
| virtual void | setFloor (double) |
| virtual double | physicalLineWidth () const |
| | Physical (database) width of a line.
|
| virtual void | setPhysicalLineWidth (double) |
| virtual double | intelAreaModifierForForce (int force) const |
| virtual boost::tribool | onTerrainSurface () const |
| virtual void | setExtendedDataMap (const ExtendedData &) |
| virtual void | setExtendedDataMap (const std::map< std::string, std::string > &e) |
| virtual void | setExtendedData (const DtString &key, const DtString &value) |
| virtual void | updateCollectionAreaInformation () |
| virtual void | updatePhysicalLineWidthInformation () |
| virtual void | updatePhysicalLineHeightInformation () |
| virtual void | updateCeilingInformation () |
| virtual void | getSelf (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| | Override getSelf to handle mapping of old pre-2.0 oob files.
|
| virtual bool | inside (const DtVector &point) const |
| | Override to check floor/ceiling if defined.
|
| virtual void | updateCachedStateProperties () |
| | Called to get value of Assume-Unknown-Is-Hostile.
|
| virtual bool | checkInVolume () const |
| | Return true if in the inside() call if it should also check floor/ceiling.
|
|
| virtual void | setFillStyle (int) |
| virtual int | fillStyle () const |
|
| virtual void | setPenStyle (int) |
| virtual int | penStyle () const |
|
| virtual void | setLineWidth (int) |
| virtual int | lineWidth () const |
|
| virtual void | setArrowStyle (int) |
| virtual int | arrowStyle () const |
|
| virtual void | setArrowHeadPlacement (int) |
| virtual int | arrowHeadPlacement () const |
|
| virtual void | setArrowSize (int) |
| virtual int | arrowSize () const |
|
| virtual bool | useActivationTimes () const |
| virtual void | setUseActivationTimes (bool) |
| virtual bool | activationTimesAreSimulationTime () const |
| | Whether or not the activation time is a simulation time, a date/time of day or a UTC time.
|
| virtual void | setActivationTimesAreSimulationTime (bool) |
| virtual bool | activationTimeIsReusable () const |
| | Whether or not the activation time is a one shot or can be reused.
|
| virtual void | setActivationTimeIsReusable (bool) |
| virtual int | activationMode () const |
| | Mode of activation. If not available will make a guess based on other settings.
|
| virtual void | setActivationMode (int) |
| virtual void | setActivatedOnce (bool) |
| | Whether or not (by activation time) this object has been activated at least once.
|
| virtual bool | activatedOnce () const |
| virtual void | setActivationTime (double) |
| virtual double | activationTime () const |
| virtual void | setDeactivationTime (double) |
| virtual double | deactivationTime () const |
| | DtVrfObjectStateRepository (DtVrfObject *vrfObject, const DtObjectType &objectType, DtVrfObjectParameters *parameters, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) |
| | Constructor.
|
| | DtVrfObjectStateRepository (const DtVrfObjectStateRepository &orig, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) |
| | Copy Constructor.
|
| const DtVrfObjectStateRepository & | operator= (const DtVrfObjectStateRepository &orig) |
| | Assignment Operator.
|
| virtual | ~DtVrfObjectStateRepository () |
| | Destructor.
|
| virtual const int | objectStateRepositorySubType () const |
| | Returns DtSimObjectStateRepositorySubTypeVrfObject.
|
| virtual bool | init () |
| | Our 'virtual' constructor. Calls all the create<>() methods.
|
| virtual bool | createParameters () |
| virtual void | initializeFromParameters () |
virtual const
DtVrfObjectParameters * | vrfParameters () const |
| virtual void | setConcealed (bool) |
| | Sets weather or not this object is concealed.
|
| virtual void | setJoystickMovementControlled (bool) |
| | If true movement is controlled by joystick so will not be able to be taskable as a subordinate.
|
| virtual bool | joystickMovementControlled () const |
virtual
DtVrfStateRepositoryUserExtension * | userExtension () const |
| | User extension to state repository class.
|
| virtual void | restoreEntity () |
| | Called on a setRestore command, sets destroyed to false and sets resources to initial (parameter file) levels.
|
| virtual bool | wouldBeRecursiveAttach (DtSimObjectStateRepository *parent) const |
| | Return true if attaching to this parent would cause a recursive attach.
|
| virtual void | restoreResourcesFromParameters () |
| virtual bool | isContactHostile (DtRwSensorContactInfo *) const |
| | Given the potential contacts, queries the engagement zone manager to see if that particular contact is hostile.
|
| virtual bool | isContactHostile (DtVrfObject *) const |
| | This call will presume the object is of force type other and is only used for the location.
|
| virtual bool | isContactHostile (const DtVector &location, int perceivedForce) const |
| | Given the location and the perceived force, iterate over all the engagement zones this object is monitoring in order to see if any one of them says this object is hostile.
|
| virtual bool | inSOR (const DtVrfObject *entity) const |
| virtual bool | canFireAt (const DtVector &location) const |
| | Returns true if this entity can fire upon the supplied location given the rules of engagement.
|
| virtual const DtString & | engagementRules () const |
| virtual void | setEngagementRules (const DtString &engagementRules) |
| virtual bool | isTasked () const |
| | Returns true if entity is currently executing a task (at least one component must be tasked), false otherwise.
|
| virtual void | clearCurrentTaskMsg (const DtSymbolString &componentName) |
| | Clear all the tasks with the specified component name.
|
| virtual void | clearCurrentTaskMsg (const DtSymbolString &componentName, int taskId) |
| | Clear the task with specified taskId and the specified component name.
|
| virtual const DtTaskStatusList * | taskStatusList () const |
| virtual DtTaskStatusList * | taskStatusList () |
| virtual DtSuspendedTaskStatusList * | suspendedTaskStatusList () |
| virtual DtTaskMessage * | currentTaskMsg (const DtSymbolString &componentName) const |
| | Get the current task message.
|
| virtual DtTaskMessage * | currentTaskMsg (const DtSymbolString &componentName, int taskId) const |
| | Get the current task message for the specified component and task ID.
|
virtual std::list
< DtTaskMessage * > | allCurrentTaskMsg (const DtSymbolString &componentName) const |
| virtual void | putSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtReaderWriter::appPath()) |
| | Top level call to write itself to file.
|
| virtual bool | placePoints (DtAttachedTerrain &attachedTerrain, std::vector< DtGroundInteractionPt * > groundInteractionPts, bool *terrainDataAvailable=0) |
| | Positions list of ground interaction points on the terrain surface closest to the specified location.
|
| virtual void | updateSupportPoints (const DtVector &newPosition, const DtReal newHeading) |
| | reading in a scenario, want to make sure the support points get set up properly.
|
virtual const
DtVrfObjectParameters * | parameters () const |
| virtual DtVrfObjectParameters * | modifiableParameters () |
| | A modifiable local copy of parameters.
|
| virtual void | setupParameterInheritance () |
| | Called by init().
|
| virtual bool | createAttachments () |
| | Override to create derived DtVrfAttachmentManager.
|
| void | addPart (DtArticulatedPartStateRepository *part) |
| | These will be replaced by equivalents in the attachment manager.
|
| void | removePart (DtArticulatedPartStateRepository *part) |
| DtArticulatedPartStateRepository * | part (DtArtPartType partType) |
| DtArticulatedPartStateRepository * | findDescendantByType (DtArtPartType childType) |
| virtual void | setInvisible (bool) |
| | Whether or not this item is invisible to sensors, line of sight, etc.
|
| virtual bool | invisible () const |
| virtual void | setInvulnerable (bool) |
| | Whether or not this item is invulnerable.
|
| virtual bool | invulnerable () const |
| virtual void | setInvisibleSetByUser (bool) |
| | Whether or not this item was set invisible by a set command.
|
| virtual bool | invisibleSetByUser () const |
| bool | sensorsKilled () const |
| | Indicates that the entity's sensors have been killed.
|
| void | setSensorsKilled (bool sensorsKilled) |
| bool | isEntity () const |
| bool | isLocal () const |
| bool | isAggregate () const |
| void | addSubordinate (DtVrfObject *subordinateEntity) |
| | Adds an entity as a subordinate.
|
| void | removeSubordinate (DtVrfObject *subordinateEntity) |
| | Removes entity from our list of subordinates.
|
| virtual DtSharedVrfObjectReference | leadEntity () const |
| virtual DtSharedVrfObjectReference | firstSubordinate () const |
| virtual DtSharedVrfObjectReference | lastSubordinate () const |
| virtual DtSharedVrfObjectReference | firstHealthySubordinate () const |
| virtual void | tick () |
| | This method is called each simulation frame, and may include any processing that needs to be done on this object state each tick.
|
| virtual void | timedTick () |
| | This version of tick checks to see if the time to tick has arrived (myNextTickTime <= exerciseClock()->approximateElapsedRealTime()).
|
| virtual void | setMinTickPeriod (double minTickPeriod) |
| | specifies a minimum tick period (which can also be thought of as
|
| virtual double | minTickPeriod () const |
| | access the minimum tick period
|
| virtual void | setMinTickPeriodVariance (double minTickPeriodVariance) |
| | set the variance in the minimum tick time
|
| virtual double | minTickPeriodVariance () const |
| | access the variance in the minimum tick period
|
| virtual void | setNextTickTime (double nextTickTime) |
| | The next tick time is normally calculated internally.
|
| virtual double | nextTickTime () const |
| | access the next tick time
|
| virtual double | calculateNextTickTime () const |
| | The next tick time is equal to mySimManager->exerciseClock()-> approximateElapsedRealTime() + myMinTickPeriod + a random # between -myMinTickPeriodVariance/2.
|
| virtual bool | createSubordinates () |
| virtual DtVrfSubordinateManager * | vrfSubordinates () |
virtual const
DtVrfSubordinateManager * | vrfSubordinates () const |
| virtual bool | createProcessStateRepositoryManager () |
| virtual const DtTaitBryan & | localOrientationWrtDatabase () const |
| | Euler angles with respect to the local (database) coordinate system, in radians.
|
| virtual void | setLocalOrientationWrtDatabase (const DtTaitBryan &localOrientation) |
| virtual DtVrfWeaponPSR * | firstWeaponPSR () const |
| | This is provided for backward compatibility with setTarget capabilities.
|
| virtual void | processObjectGeometry (const DtList &vertices) |
| | Processes a list of DtVectors, such as might come in a create or modify message.
|
| virtual void | processObjectGeometry (const DtLocalVertexList &vertices) |
| virtual void | processObjectGeometry () |
| | This form allows processObjectGeometry()'s bounding volume calculations to be done on it's current geometry (by making a copy first).
|
virtual const
DtVrfObjectParameters * | vrfBaseParameters () const |
| virtual DtGroundInteractionPt * | groundCenter () |
virtual const
DtGroundInteractionPt * | groundCenter () const |
| virtual const DtVector & | getPartAttachPoint (const int partType) const |
| virtual void | place (const DtVector &location, bool *dataAvailable=0, bool requireAllData=false) |
| | Place entity at 'location', on the ground, keeping its current heading.
|
| virtual void | place (const DtReal heading, bool *dataAvailable=0, bool requireAllData=false) |
| | Give entity the specified 'heading', but stay at its current location.
|
| virtual void | place (const DtVector &location, const DtReal heading, bool clampToGroundFlag=true, bool *dataAvailable=0, bool requireAllData=false) |
| | Place entity at specified 'location' and 'heading' on the ground.
|
| virtual void | reclampToGround () |
| | Will cause the object to be replaced at it's current position and clamped to the terrain.
|
| virtual void | updatePositionFromModelVertices () |
| | Note that this is not currently ever called.
|
| virtual DtReal | mass () const |
| virtual void | setMass (const DtReal mass) |
virtual const
DtArticulatedPartCollection * | artPartList () const |
| | Get the list of articulated parts specified in the component descriptor.
|
| virtual void | createParts () |
| | This causes the art part tree to be created.
|
| virtual DtTime | lastTimeFiredUpon () const |
| virtual void | setLastTimeFiredUpon (const DtTime time) |
| virtual bool | underFire () const |
| virtual void | setUnderFire (bool underFire) |
| virtual DtDeadReckonTypes | deadReckoningAlgorithm () const |
| virtual void | setDeadReckoningAlgorithm (DtDeadReckonTypes deadReckoningAlgorithm) |
| virtual void | putData (std::string &fp, int indentLevel=0) |
| | Override putData to set myParent using the organization manager before saving.
|
| virtual int | nextTaskId () |
| | Returns next unique task id for this entity.
|
| virtual int | nextSuspendId () |
| virtual DtTaskMessage * | pendingSubtask (int subtaskId, DtString &controller) const |
| | Returns the current subtask with the specified id.
|
| virtual bool | taskedBySuperiorUponTaskComplete () const |
| | Returns true if entity should automatically resume being tasked by superior upon completion of its current top-level task, false otherwise.
|
| virtual void | setParentWasDestroyedWhenEmbarked (bool) |
| virtual bool | parentWasDestroyedWhenEmbarked () const |
| virtual void | addAttachedTerrain (const DtUUID &parent) |
| | Asks the sim manager to look up the object model for the requested database.
|
| virtual void | removeAttachedTerrain (const DtUUID &parent) |
| | Decreases reference count of terrain model by name of object.
|
| Dt3dBoundingVolume * | boundingVolume () const |
| | Convenience method for accessing entity's bounding volume, stored in myObjectGeometry.
|
| DtVector | localBoundingVolumeCenterPosition () const |
| | Gets the local coordinates of the bounding volume center.
|
| DtReal | forwardSpeed () const |
| virtual double | totalMass () const |
| | Returns the current total mass of the entity.
|
| virtual void | restoreStateProperties () |
| | Restores state properties to their default settings.
|
| virtual void | initStatePropertiesNotToBeRestored () |
| | Initializes the list of state properties which should not be restored.
|
| virtual void | addRangeItem (const DtRangeItem &) |
| | Adds, removes and returns items in the range item list.
|
| virtual void | removeRangeItem (int index) |
| virtual void | setRangeItems (const DtRangeItems &) |
| const DtRangeItems & | rangeItems () const |
| DtRangeItems & | rangeItems () |
| virtual void | clearRangeItems () |
| DtAttachedTerrain * | terrainAttachedTo () const |
| virtual std::list< DtSymbolString > | sensorSignatureDomains () const |
| virtual DtString | stringFromExtendedData (const DtString &) const |
| | Takes the extended data string, and, if xml, will pretty print and remove the quotes from the created reader/writer else just return the string.
|
virtual std::map< DtString,
DtString > | unarchivedData () const |
| | Extended data that is not archived that is currently in the extended data list.
|
| virtual void | appendExtendedData (const std::map< DtString, DtString > &) |
| | Append extended data to extended data map.
|
virtual
DtVrfObjectStateRepository * | toVrfObjectStateRepository () |
virtual const
DtVrfObjectStateRepository * | toVrfObjectStateRepository () const |
| virtual void | addRestoredCallback (DtVrfObjectCallbackList::DtCallbackFunctionType fcn, void *usr) |
| | Callback that is invoked when the entity is about to be removed from the simulation.
|
| virtual void | removeRestoredCallback (DtVrfObjectCallbackList::DtCallbackFunctionType fcn, void *usr) |
| virtual void | invokeRestoredCallbacks () |
| virtual void | clearExtendedData () |
| virtual void | removeExtendedData (const DtString &key) |
| virtual DtString | extendedData (const DtString &key) const |
| const ExtendedData & | extendedDataMap () const |
| virtual void | setupExtendedDataFromParameterData () |
| | If publishing parameter data also include that in the extended data map by name.
|
| virtual void | setExtendedLabel (int, const DtString &value) |
| virtual void | clearExtendedLabels () |
| virtual DtString | extendedLabel (int index) const |
| virtual ExtendedLabels | extendedLabels () const |
| virtual void | setExtendedLabels (const ExtendedLabels &) |
| virtual void | addJoystickControls (const DtRwJoystickControls &) |
| virtual const JoystickControls & | joystickControls () const |
| virtual void | setActivity (const DtString &) |
| virtual DtString | activity () const |
virtual const
DtObjectResourceManager * | objectResourceManager () const |
| virtual DtObjectResourceManager * | objectResourceManager () |
virtual const
DtSimResourceManager & | oldResourceManager () const |
| | Returns a reference to our resource manager.
|
| virtual DtSimResourceManager & | oldResourceManager () |
| virtual DtSimResource * | oldLookupResource (const DtString &resourceName) |
| | Gets a pointer to the resource named resourceName.
|
| virtual const DtSimResource * | oldLookupResource (const DtString &resourceName) const |
| virtual void | oldAddResource (DtSimResource *resource) |
| | This does a clone of the resource and puts it on our main list, as well as adding the resource to the hash index.
|
| virtual void | oldRemoveResource (DtSimResource *resource) |
| | This removes and deletes the specified resource.
|
| virtual void | setNavigationEnabled (bool) |
| virtual bool | navigationEnabled () const |
| virtual void | setSOR (DtReal center, DtReal size) |
| | Sector of responsibility.
|
| virtual DtReal | SORSize () const |
| virtual DtReal | SORCenter () const |
| virtual const DtSimSector & | SOR () const |
| virtual void | setRequestTaskNeeded (bool value) |
| | Set/get whether or not this needs to send a request task needed message.
|
| virtual bool | requestTaskNeeded () const |
| virtual void | setTasked (const DtSymbolString &componentName, bool tasked) |
| | Set/get whether or not a given entity component currently executing a task.
|
| virtual void | setTasked (const DtSymbolString &componentName, int taskID, bool tasked) |
| virtual bool | tasked (const DtSymbolString &componentName) const |
| virtual void | setCurrentTaskMsg (const DtSymbolString &componentName, const DtTaskMessage &taskMsg) |
| | Set the current task message.
|
| virtual void | setCurrentTaskMsg (const DtSymbolString &componentName, const DtTaskMessage &taskMsg, int taskId) |
| virtual void | setIndependentlyTasked (bool value) |
| | Set/get whether or not this entity is currently independently tasked (separately from its unit).
|
| virtual bool | independentlyTasked () const |
virtual const
DtVrfObjectParameters * | parameterEntry () const |
| | If a clone has been created, this call will return the cloned entry as a const pointer, else returns the original pointer.
|
| virtual void | setParameterEntry (DtVrfObjectParameters *parameterEntry) |
| virtual DtForceType | forceType () const |
| | Get/Set the force type (team) of this entity.
|
| virtual void | setForceType (DtForceType force) |
| virtual bool | createAppearance () |
| | Encapsulates all the appearance related data and methods currently in the entity state repository.
|
| virtual const DtAppearance * | appearance () const |
| virtual DtAppearance * | appearance () |
| virtual void | setCapabilities (int cap) |
| | Gets/sets capabilities of entity This is treated as the DIS capabilities bit field, and does not necessarily change any behaviors of the object.
|
| virtual int | capabilities () const |
| virtual void | setDestroyed (bool isDestroyed) |
| | Destroyed status of entity (whether or not appearance()->damageState() is set to DtDamageDestroyed).
|
| virtual bool | isDestroyed () const |
| virtual void | setOccupantsHidden (bool v) |
| | Whether or not the occupants of an entity are visually hidden.
|
| virtual bool | occupantsHidden () const |
| DtReal | healthPct () const |
| void | setHealthPct (DtReal pct) |
| bool | firePowerKilled () const |
| | Convenience methods for setting setting entity's appearance bits in DtAppearance.
|
| void | setFirePowerKilled (const bool firePowerKilled) |
| bool | mobilityKilled () const |
| void | setMobilityKilled (const bool mobilityKilled) |
| bool | flaming () const |
| void | setFlaming (const bool flaming) |
| bool | smoking () const |
| void | setSmoking (const bool smoking) |
| virtual DtVrfSubordinateManager * | subordinates () |
virtual const
DtVrfSubordinateManager * | subordinates () const |
| virtual DtSimManager * | simManager () |
| virtual const DtSimManager * | simManager () const |
| virtual DtPhysicalWorld * | physicalWorld () |
| virtual const DtPhysicalWorld * | physicalWorld () const |
virtual const
DtVrfProcessStateRepositoryManager * | systemProcessStateRepositoryManager () const |
virtual
DtVrfProcessStateRepositoryManager * | systemProcessStateRepositoryManager () |
| virtual const DtThresholder & | deadReckoningThresholder () const |
| | Dead-reckoning threshold parameters.
|
| virtual void | setDeadReckoningThresholder (const DtThresholder &thresholder) |
| virtual const DtEntityIdentifier & | occupyingObjectId () const |
| | We hold the id of the object we are occupying.
|
| virtual void | setOccupyingObjectId (const DtEntityIdentifier &objId) |
| virtual void | setEchelonId (const DtEchelonId &echelonId) |
| | The echelon ID of this object, if it is an organized object.
|
| virtual DtEchelonId & | echelonId () |
| virtual const DtEchelonId & | echelonId () const |
| virtual void | setIsSubordinateOfForceLevel (bool yesNo) |
| | Indicates if this object's direct superior is a Force level object.
|
| virtual bool | isSubordinateOfForceLevel () const |
| virtual int | spawningTaskId (int subtaskId) const |
| | Functions for manipulating the set of pending subtask Ids for all components in the entity.
|
| virtual void | addPendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual void | addPendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual bool | findPendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual bool | isSubtasked (const DtSymbolString &componentName) const |
| virtual bool | findPendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual void | removePendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual void | removePendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual void | removeAllPendingSubtaskIds (const DtSymbolString &componentName) |
| virtual void | removeAllPendingSubtaskIds (const DtSymbolString &componentName, int taskId) |
| virtual void | removeInactiveSubtaskStatus (const DtSymbolString &componentName) |
| virtual void | removeInactiveSubtaskStatus (const DtSymbolString &componentName, int taskId) |
| virtual void | printPendingSubtaskIds (const DtSymbolString &componentName) const |
| virtual std::vector< int > | currentPendingSubstaskIds (const DtSymbolString &componentName) const |
| virtual std::vector< int > | currentPendingSubstaskIds (const DtSymbolString &componentName, int taskId) const |
| virtual DtSubtaskStatusEntry * | pendingSubtaskStatus (const DtSymbolString &componentName, int subtaskId) |
| virtual DtSubtaskStatusEntry * | pendingSubtaskStatus (const DtSymbolString &componentName, int taskId, int subtaskId) |
| DtReal | currentSpeed () const |
| | Returns magnitude of relative velocity in state repository.
|
| DtReal | currentHeading () const |
| | Heading in radians. Calls down to DtVrfKinematicState for heading.
|
| void | setCurrentHeading (const DtReal heading) |
virtual const
DtRwNLengthUUIDVector & | engagementZones () const |
| | Accessor/mutator for engagement zones.
|
| virtual void | setEngagementZones (const DtRwNLengthUUIDVector &) |
| virtual void | addPostInitFromParamsCallback (DtPostInitializeFromParametersCallbackFcn fcn, void *usr) |
| | Add/remove callback function to be invoked immediately following execution of initializeFromParameters.
|
| virtual void | removePostInitFromParamsCallback (DtPostInitializeFromParametersCallbackFcn fcn, void *usr) |
| virtual DtRwProperties & | stateProperties () |
| | Accesses to the properties.
|
| virtual const DtRwProperties & | stateProperties () const |
| virtual DtRwProperties & | parameterProperties () |
| | Access to static (parameter) properties.
|
| virtual const DtRwProperties & | parameterProperties () const |
| virtual DtSensorContactInfoList & | objectContactList () |
| | Situational awareness of this object.
|
virtual const
DtSensorContactInfoList & | objectContactList () const |
| virtual bool | processCompleteAttachment (DtVrfObject *) |
| | These callbacks are used to set myAttachedToStateRepository when this ent gets attached/detached to/from its parent.
|
| virtual void | processObjectAboutToBeRemovedCallback (DtVrfObject *vrfObject) |
| virtual suppressionLevels | suppressionLevel () const |
| virtual void | setSuppressionLevel (const suppressionLevels l) |
| virtual bool | isSuppressed () const |
| virtual void | processTaskComplete (const DtVrfObjectMessage *msg) |
| | DtSimObjectStateRepository (DtVrfObject *simObject, const DtObjectType &objectType, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) |
| const DtSimObjectStateRepository & | operator= (const DtSimObjectStateRepository &orig) |
| virtual | ~DtSimObjectStateRepository () |
| virtual const DtObjectType & | objectType () const |
| virtual void | setObjectType (const DtObjectType &objectType) |
| virtual bool | createKinematicState () |
| | Creates a DtVrfKinematicState.
|
| virtual DtVrfKinematicState * | vrfKinematicState () |
| virtual const DtVrfKinematicState * | vrfKinematicState () const |
| virtual bool | createObjectGeometry () |
| virtual DtVrfObjectGeometry * | vrfObjectGeometry () |
| virtual const DtVrfObjectGeometry * | vrfObjectGeometry () const |
| virtual DtAttachmentManager * | attachments () |
| virtual const DtAttachmentManager * | attachments () const |
virtual
DtSimObjectStateRepository * | parent () |
virtual const
DtSimObjectStateRepository * | parent () const |
| virtual bool | isEmbarkedOn (const DtUUID &parent) const |
| virtual const DtUUID & | attachedToRepository () |
virtual
DtSimObjectStateRepository * | findRootSimStateRepository () |
virtual const
DtSimObjectStateRepository * | findRootSimStateRepository () const |
| virtual void | setOwnedByHostObject (bool) |
| | When state repositories get added to the attachment manager, the attachment manager assumes it takes ownership of that state repository, and, when it is deleted, it will destroy any state repository that is still attached.
|
| virtual bool | ownedByHostObject () const |
| virtual void | ancestorObjectChanged () |
| virtual void | preGetSelf () |
| | Hook function called immediately prior to getSelf().
|
| virtual void | postGetSelf () |
| | Hook function called immediately following getSelf().
|
| virtual void | removeRepositoryAboutToBeDeletedCallback (DtSimObjectStateRepositoryAboutToBeDeletedCallbackFcn, void *usr) |
| | Add/remove callback for notification that this state repository is about to be deleted.
|
| virtual void | addRepositoryAboutToBeDeletedCallback (DtSimObjectStateRepositoryAboutToBeDeletedCallbackFcn, void *usr) |
| virtual void | invokeRepositoryAboutToBeDeletedCallbacks () |
| virtual void | processUUIDChanged (const DtVrfObjectUUIDChangedCallbackInfo &) |
| virtual void | setCoordinateSystem (const Coordinate_System *coordinateSystem) |
| | Sets the coordinate system in myObjectGeometry and myKinematicState.
|
| virtual DtVrfObject * | vrfObject () |
| virtual const DtVrfObject * | vrfObject () const |
| virtual void | setVrfObject (DtVrfObject *vrfObject) |
| virtual DtSimKinematicState * | kinematicState () |
| virtual const DtSimKinematicState * | kinematicState () const |
| virtual DtVrfObjectGeometry * | objectGeometry () |
| virtual const DtVrfObjectGeometry * | objectGeometry () const |
| virtual const DtVector & | bodyPosition () const |
| | Now superseded by kinematic state parentCS functions.
|
| virtual void | setBodyPosition (const DtVector &pos) |
| | Formerly setMeInParent.
|
| virtual void | setBodyPosition (DtFloat64 x, DtFloat64 y, DtFloat64 z) |
| const DtDcm & | bodyOrientationMatrix () const |
| | Formerly meToParent().
|
| virtual void | embarkOnParent (const DtUUID &parent) |
| | Embarks this entity on the specified parent.
|
| virtual bool | leftOf (const DtVector &localVector) const |
| virtual double | distanceToLocalVector (const DtVector &localVector) const |
| | Returns the distance from a position in local.
|
| const Coordinate_System * | coordinateSystem () const |
| virtual void | removeVertex (int iIndex) |
| | These routines simply call down to the kinematic state to get/set the results.
|
| virtual void | addLocalVertex (const DtVector &vertex) |
| virtual void | addLocalVertex (const DtVector &vertex, DtVector &newGeometricCenter) |
| virtual void | setLocalVertices (const DtLocalVertexList &vertices, DtVector &newGeometricCenter) |
| virtual void | setLocalVertices (const DtList &vertices, DtVector &newGeometricCenter) |
| virtual const DtLocalVertexList & | localVertices () const |
virtual const
DtLocalVectorIterator & | localVertexIterator () const |
| virtual void | addWorldVertex (const DtVector &vertex, DtVector &newGeometricCenter) |
| virtual void | setWorldVertices (const DtVertexList &vertices, DtVector &newGeometricCenter) |
| virtual void | setWorldVertices (const DtList &vertices, DtVector &newGeometricCenter) |
| virtual const DtVertexList & | worldVertices () const |
| virtual const DtRwVectorIterator & | worldVertexIterator () const |
| virtual void | setRelativeVertices (const DtLocalVertexList &vertices) |
| | Access/modify vertices relative to to the parent to which this object is attached.
|
| virtual void | setRelativeVertices (const DtList &vertices) |
| virtual const DtLocalVertexList & | relativeVertices () const |
virtual const
DtLocalVectorIterator & | relativeVertexIterator () const |
| const DtVector & | localPosition () const |
| | Convenience methods for accessing corresponding methods in DtVrfKinematicState.
|
| void | setLocalPosition (const DtVector &pos) |
| const DtVector & | localVelocity () const |
| void | setLocalVelocity (const DtVector &vel) |
| const DtVector & | localAcceleration () const |
| void | setLocalAcceleration (const DtVector &acc) |
| const DtVector & | relativeVelocity () const |
| void | setRelativeVelocity (const DtVector &vel) |
| const DtVector & | relativeAcceleration () const |
| void | setRelativeAcceleration (const DtVector &acc) |
| const DtTaitBryan & | localOrientation () const |
| void | setLocalOrientation (const DtTaitBryan &angles) |
| const DtVector & | worldPosition () const |
| void | setWorldPosition (const DtVector &pos) |
| const DtVector & | worldVelocity () const |
| void | setWorldVelocity (const DtVector &vel) |
| const DtVector & | worldAcceleration () const |
| void | setWorldAcceleration (const DtVector &acc) |
| const DtTaitBryan & | worldOrientation () const |
| void | setWorldOrientation (const DtTaitBryan &angles) |
| const DtVector & | rotationalVelocity () const |
| void | setRotationalVelocity (const DtVector &rotationalVelocity) |
| const DtDcm & | localOrientationMatrix () const |
| void | setLocalOrientationMatrix (const DtDcm &orient) |
| void | setParentPosition (const DtVector &pos) |
| const double | lastPositionSetTime () const |
| | Indicates the last time the position was set, so that a precise position at the current time may be computed.
|
| void | setLastPositionSetTime (const double simTime) |
| | DtReaderWriter () |
| | default constructor
|
| | DtReaderWriter (const DtString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) |
| | real constructor Setting the readonly flag prevents object from writing itself to the stream.
|
| | DtReaderWriter (const DtSymbolString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) |
| | DtReaderWriter (const DtString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) |
| | pseudo-copy constructor
|
| | DtReaderWriter (const DtSymbolString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) |
| | DtReaderWriter (const DtReaderWriter &, DtReaderWriterRegistry *parentRegistry=NULL) |
| | copy constructor
|
| const DtReaderWriter & | operator= (const DtReaderWriter &orig) |
| | assignment operator
|
| bool | operator== (const DtReaderWriter &) const |
| | Equivalence operator.
|
| bool | operator!= (const DtReaderWriter &rhs) |
| virtual | ~DtReaderWriter () |
| | destructor
|
| virtual void | postPutSelf () |
| | Called after either version of put self (file or environment). Default is no-op.
|
| virtual void | prePutSelf () |
| | Called before either version of put self (file or environment). Default is no-op.
|
| virtual void | writeSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| | Called from putSelf, calls myRegistry.putSelf which in turn calls putSelf on each reader/writer in the registry.
|
| virtual DtSymbolString | name () const |
| | Accessor for name of this readable/writable object.
|
| virtual void | addAlias (const DtSymbolString &alias) |
| | Add an alias as an alternative name for this object.
|
| virtual void | addAlias (const DtString &alias) |
| virtual bool | hasAlias (const DtSymbolString &alias) |
| virtual const aliasContainer & | aliases () const |
| virtual void | setReadonly (bool flag) |
| | Set read-only flag.
|
| bool | isReadonly () const |
| virtual void | reset () |
| | For those reader/writer items that support it, resets the reader/writer value to original state Default is no-op.
|
| virtual int | alignment () const |
| | For those items that are sent over the network via HLA, this will give the network alignment.
|
| virtual bool | variableIsBound () const |
| virtual void | unbindVariable () |
| | Sets the myVariableIsBound flag to false.
|
| virtual void | setName (const DtString &) |
| | Set the name of the object.
|
| virtual const char * | readerWriterType () const |
| | Used to supply a string type that this reader writer type is.
|
| virtual const char * | xmlType () const |
| virtual DtString | prettyPrint () const |
| | Routine to return a human readable form of the reader/writer variable.
|
| std::string | debugText () const |
| virtual void | bindVariables (DtVariableBindingsList variableBindings) |
| | Runs a variable binding pass on this reader writer and any of its children.
|
virtual std::list
< DtVariableNameType > | unboundVariables () const |
| bool | invalid () const |
| virtual bool | hasChild (const DtReaderWriter *p) const |
| | Returns true if this variable has a child p in it's chain.
|
| virtual bool | hasVariableReference () const |
| | Returns true if this item or any item in the registry (recursive) is a variable reference.
|
| virtual void | bindLocalVariables (const DtVariableBindingsList &variableBindings) |
| | Checks to see if this RW object is a variable reference that can be bound using the provided bindings.
|
| virtual void | recordUpdateTime () const |
| | Can be implemented in subclasses to stamp the time when updated.
|
| virtual bool | wasUpdatedSince (DtTime t) const |
| | Can be implemented in subclasses to return true if an update occurred after the specified time.
|
| virtual bool | changedSinceLastChecked () |
| | Returns true if this objects value has changed since the last time this function was called.
|
| virtual bool | peekChangedSinceLastChecked () const |
| | Returns the value that changedSinceLastChecked would return but does not reset the internal flag.
|
| virtual DtlObjPtr | getData (DtlObjPtr args, const SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| virtual void | setValueSpecified (bool specified, bool recurse=false) |
| | The specified flags are used for optional values.
|
| virtual bool | valueSpecified () const |
| virtual bool | isVariableReference () const |
| | Specifies whether or not this reader writer is really a variable that is specified elsewhere.
|
| virtual void | setIsVariableReference (bool value) |
| virtual void | clearAllVariableReferenceFlags () |
| | Clears out all variable reference flags from all readerwriter items in registry recursively.
|
| virtual DtSymbolString | variableName () const |
| | The variable name, if this object is a variable reference.
|
| virtual void | setVariableName (const DtSymbolString variableName) |
| virtual const DtReaderWriter * | defaultRWValue () const |
| | The default value to use if the reader/writer object is a variable and that variable is not specified.
|
| virtual DtReaderWriter * | defaultRWValue () |
| virtual void | setDefaultRWValue (DtReaderWriter *) |
| | Previous default value, if exists, will be removed and replaced with a clone of the supplied variable.
|
| virtual bool | checkAndSetDefaultRWValue (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &variableBindings=nullVariableReference()) |
| | Give the stream, if the stream contains a default value then set it here.
|
| const DtReaderWriterRegistry & | registry () const |
| | Collection of child DtReaderWriter nodes owned by this object.
|
| DtReaderWriterRegistry & | registry () |
| virtual DtPropertyInterface * | property () |
| virtual const DtPropertyInterface * | property () const |
| virtual DtString | toXml () const |
| virtual DtRwVariableBindings * | generateVariableBindings () const |
| | Iterates over the registry (recursively) and returns a variable bindings object that contains all the variables that are contained in this read/writer class.
|
| virtual bool | toXml (const DtFilename &) const |
| | Writes contents of xml result to the given filename.
|
| virtual bool | fromXml (const DtString &) |
| | Restores object from given xml string. Returns true if valid.
|
| virtual bool | fromXmlFile (const DtFilename &) |
| | Restores object from given xml file.
|
| virtual void | putSelf (DtEnvironmentSP, DtEnvValueSP parent) const |
| virtual void | putData (DtEnvironmentSP, DtEnvValueSP value) const |
| | Override to add attributes of actual data.
|
| virtual void | putVariableReference (DtEnvironmentSP, DtEnvValueSP value) const |
| | Called when the item is a variable reference.
|
| virtual void | getSelf (const DtEnvironmentSP, const DtEnvValueSP root, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| virtual void | getData (const DtEnvironmentSP, const DtEnvValueSP, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| | Gets data from the environment value.
|
| virtual void | unrecognizedItem (const DtEnvironmentSP env, const DtEnvValueSP root, const SearchPaths &searchPaths, const DtVariableBindingsList &varBindings) |
| | Called when the xml reader tries to parse an unknown reader/writer item. Default is a no-op.
|
| virtual void | getVariableReference (DtEnvironmentSP, DtEnvValueSP value) |
| | Called when the item is a variable reference.
|
Public Member Functions inherited from DtVrfObjectStateRepository
