Public Member Functions |
| | DtElectromagneticEmissionPdu (DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER) |
| | DtElectromagneticEmissionPdu (const DtNetElectromagneticEmissionPdu *initial, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER, DtPduFactory *pduFactory=0) |
| const DtEntityIdentifier & | emittingEntityId () const |
| void | setEmittingEntityId (const DtEntityIdentifier &id) |
| const DtEventID & | eventId () const |
| void | setEventId (const DtEventID &id) |
| DtEmissionPduType | stateUpdateIndicator () const |
| void | setStateUpdateIndicator (DtEmissionPduType indicator) |
| int | numSystems () const |
| void | setNumSystems (int num) |
| int | systemDataWords (int sysNum, int *retcode=0) const |
| int | numBeams (int sysNum, int *retcode=0) const |
| void | setNumBeams (int sysNum, int numBeams, int *retcode=0) |
| DtEmitterSysName | systemName (int sysNum, int *retcode=0) const |
| void | setSystemName (int sysNum, DtEmitterSysName name, int *retcode=0) |
| DtEmissionFunc | systemFunction (int sysNum, int *retcode=0) const |
| void | setSystemFunction (int sysNum, DtEmissionFunc func, int *retcode=0) |
| int | emitterId (int sysNum, int *retcode=0) const |
| void | setEmitterId (int sysNum, int id, int *retcode=0) |
| const DtVector & | location (int sysNum, int *retcode=0) const |
| void | setLocation (int sysNum, const DtVector &loc, int *retcode=0) |
| int | beamDataWords (int sysNum, int beamNum, int *retcode=0) const |
| int | beamId (int sysNum, int beamNum, int *retcode=0) const |
| void | setBeamId (int sysNum, int beamNum, int id, int *retcode=0) |
| int | beamParameterIndex (int sysNum, int beamNum, int *retcode=0) const |
| void | setBeamParameterIndex (int sysNum, int beamNum, int bpIndex, int *retcode=0) |
| const DtFundamentalParameterData & | parameterData (int sysNum, int beamNum, int *retcode=0) const |
| void | setParameterData (int sysNum, int beamNum, const DtFundamentalParameterData &data, int *retcode=0) |
| int | beamFunction (int sysNum, int beamNum, int *retcode=0) const |
| void | setBeamFunction (int sysNum, int beamNum, int func, int *retcode=0) |
| int | numTargetsInBeam (int sysNum, int beamNum, int *retcode=0) const |
| void | setNumTargetsInBeam (int sysNum, int beamNum, int num, int *retcode=0) |
| DtTrackingJamming | trackingAllTargets (int sysNum, int beamNum, int *retcode=0) const |
| void | setTrackingAllTargets (int sysNum, int beamNum, DtTrackingJamming trackJamAll, int *retcode=0) |
| DtU8 | beamStatus (int sysNum, int beamNum, int *retcode=0) const |
| void | setBeamStatus (int sysNum, int beamNum, DtU8 seq, int *retcode=0) |
| unsigned long | jammingModeSequence (int sysNum, int beamNum, int *retcode=0) const |
| void | setJammingModeSequence (int sysNum, int beamNum, unsigned long seq, int *retcode=0) |
| const DtTrackJamTarget & | trackJamTarget (int sysNum, int beamNum, int targetNum, int *retcode=0) const |
| void | setTrackJamTarget (int sysNum, int beamNum, int targetNum, const DtTrackJamTarget &targ, int *retcode=0) |
| virtual void | printData () const |
| | Print the PDU's data (not including header).
|
| virtual void | printDataToStream (std::ostream &stream) const |
| | DtStateMsg () |
| | default constructor
|
| virtual | ~DtStateMsg () |
| | destructor
|
| | DtStateMsg (const DtStateMsg &orig) |
| | copy constructor
|
| DtStateMsg & | operator= (const DtStateMsg &orig) |
| | assignment operator
|
| | DtPduWithAttributeRecordSets () |
| | Constructor.
|
| | DtPduWithAttributeRecordSets (const DtPduWithAttributeRecordSets &orig) |
| | Constructor.
|
| DtPduWithAttributeRecordSets & | operator= (const DtPduWithAttributeRecordSets &other) |
| | Assignment operator.
|
| virtual | ~DtPduWithAttributeRecordSets () |
| | Destructor.
|
| virtual void | printToStream (std::ostream &stream) const |
| | Print the contents of the PDU. This will call DtPdu's printToStream and also call printRecordSets()
|
| virtual void | printRecordSets (bool printEntityObjectId=false) const |
| | Prints the Record Sets to DtInfo.
|
| virtual void | printRecordSetsToStream (std::ostream &stream, bool printEntityObjectId=false) const |
| | Prints the Record Sets to the specified stream.
|
| virtual void | addRecord (std::auto_ptr< DtStandardVariableRecord > record, const DtEntityIdentifier &id=DtEntityIdentifier::nullId()) |
| | Adds a Record.
|
| virtual void | removeRecord (unsigned int index, const DtEntityIdentifier &id=DtEntityIdentifier::nullId()) |
| | Removes a Record.
|
| virtual void | clearRecordSet (const DtEntityIdentifier &id=DtEntityIdentifier::nullId()) |
| | Removes all Records and deletes the recordSet for the given Entity/Object Identifier.
|
| virtual void | clearAllRecordSets () |
| | Removes all RecordSets.
|
virtual std::vector
< DtEntityIdentifier > | recordSetIdentifiers () const |
| | Returns a vector of Entity/Object Identifiers. These are the Identifiers for the Record Sets.
|
| virtual void | getRecordSetIdentifiers (std::vector< DtEntityIdentifier > &entityIdVector) const |
| | Returns by reference the vector of Entity/Object Identifiers.
|
virtual const std::vector
< DtStandardVariableRecord * > & | records (const DtEntityIdentifier &id=DtEntityIdentifier::nullId()) const |
| | This will return the Records for a given Entity/Object Identifier.
|
virtual const
DtAttributeRecordSet & | recordSet (const DtEntityIdentifier &id) const |
| | This will return the Record Set for a given Entity/Object Identifier.
|
virtual const std::vector
< DtStandardVariableRecord * > | allRecords () const |
| | This will return the Records of all Record Sets.
|
| virtual unsigned int | numberOfRecords () const |
| | Returns the number of records for all Record Sets.
|
| virtual unsigned int | numberOfRecords (const DtEntityIdentifier &id) const |
| | Returns the number of records in the Record Set for the given Entity/Object Identifier.
|
| virtual bool | containsStandardRecordSets () const |
| | Returns if this PDU contains Standard Record Sets. (This is only applicable to DIS 7 and higher).
|
| virtual const DtSimulationAddress & | attributePduSimulationAddress () const |
| | Returns the Simulation address if an attribute PDU was coupled. Used internally in VR-Link in Reflected Lists.
|
| virtual void | setAttributePduSimulationAddress (const DtSimulationAddress &addr) |
| | Sets the Simulation address if an attribute PDU was coupled. Used internally in VR-Link in Reflected Lists.
|
| virtual void | encode () |
| | Encode method.
|
| virtual void | decode (DtPduFactory *pduFactory=0) |
| | Decode method.
|
| virtual unsigned int | attributeRecordSetsNetSize () const |
| | Network Size of the all Attribute Record Sets.
|
| virtual unsigned int | recordSetsNetSize () const |
| | Network Size of the all Record Sets.
|
| virtual void | setStandardVariableRecordFactory (DtStandardVariableRecordFactory *factory) |
| | Sets/gets the Standard Variable Record Factory used for decoding.
|
virtual
DtStandardVariableRecordFactory * | standardVariableRecordFactory () const |
| virtual unsigned int | numberOfRecordSets () const |
| | Gets the number of Attribute Record Sets.
|
virtual const
DtAttributeRecordSetMap & | attributeRecordSetMap () const |
| | Get the AttributeRecordSet Map.
|
| virtual int | computeMasterAttributeRecordType () const |
| | Get the Master Attribute Record Type (if applicable, this will return MULTIPLES_PRESENT if not)
|
| virtual | ~DtPdu () |
| | Destructor.
|
| | DtPdu (const DtPdu &pdu, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER) |
| | Copy constructor.
|
| DtPdu & | operator= (const DtPdu &pdu) |
| | Assignment operator.
|
| virtual void * | packet () const |
| | Older function that returns a pointer to the network representation.
|
| virtual int | status () const |
| | Get PDU status.
|
| virtual void | setVersion (int vers) |
| | Set/Get protocol version from PDU header.
|
| virtual int | protocolVersion () const |
| virtual void | setExerciseId (int id) |
| | Set/Get exerciseID in PDU header.
|
| virtual int | exerciseId () const |
| virtual DtPduKind | kind () const |
| | Returns PDU kind from PDU header.
|
| virtual DtProtocolFamily | protocolFamily () const |
| | Returns protocol family from PDU header.
|
| virtual void | setTimeStamp (DtTime time, DtTimeStampType type=DtTimeStampRelative) |
| | Set the PDU header's time stamp to reflect time and type.
|
| virtual DtTime | timeStamp () const |
| | Return the time (in seconds past an hour) encoded in the PDU header's time stamp.
|
| virtual DtTimeStampType | timeStampType () const |
| | Return the type of the time stamp, as indicated in PDU header.
|
| virtual void | setPduLength (unsigned int length) |
| | Set the PDU header's length.
|
| virtual unsigned int | pduLength () const |
| | Return the length of the PDU, as indicated in the PDU header.
|
| virtual void | setPduStatus (int) |
| | Set the PDU Status in the PDU header.
|
| virtual int | pduStatus () const |
| | Returns the PDU Status from the PDU header.
|
| virtual void | setTransferredEntityIndicator (bool difference) |
| | Set the Transferred Entity Indicator in the PDU header False is No Difference True is Difference.
|
| virtual bool | transferredEntityIndicator () const |
| | Returns the Transferred Entity Indicator from the PDU header False is No Difference True is Difference.
|
| virtual void | setLvcIndicator (DtPduStatusLVCIndicator lvcIndicator) |
| | Set the LVC Indicator in the PDU header.
|
| virtual DtPduStatusLVCIndicator | lvcIndicator () const |
| | Returns the LVC Indicator from the PDU header.
|
| virtual void | setCoupledExtensionIndicator (bool coupled) |
| | Set the Coupled Extension Indicator in the PDU Header False is Not Coupled True is Coupled.
|
| virtual bool | coupledExtensionIndicator () const |
| | Returns the Coupled Extension Indicator from the PDU Header False is Not Coupled True is Coupled.
|
| virtual void | setFireTypeIndicator (DtPduStatusFireTypeIndicator fireTypeIndicator) |
| | Set the Fire Type Indicator in the PDU header.
|
virtual
DtPduStatusFireTypeIndicator | fireTypeIndicator () const |
| | Returns the Fire Type Indicator from the PDU header.
|
| virtual void | setDetonationTypeIndicator (DtPduStatusDetonationTypeIndicator detonationTypeIndicator) |
| | Set the Detonation Type Indicator in the PDU header.
|
virtual
DtPduStatusDetonationTypeIndicator | detonationTypeIndicator () const |
| | Returns the Detonation Type Indicator from the PDU header.
|
| virtual void | setRadioAttachedIndicator (DtPduStatusRadioAttachedIndicator radioAttachedIndicator) |
| | Set the Radio Attached Indicator in the PDU header.
|
virtual
DtPduStatusRadioAttachedIndicator | radioAttachedIndicator () const |
| | Returns the Radio Attached Indicator from the PDU header.
|
| virtual void | setIntercomAttachedIndicator (DtPduStatusIntercomAttachedIndicator intercomAttachedIndicator) |
| | Set the Intercom Attached Indicator in the PDU header.
|
virtual
DtPduStatusIntercomAttachedIndicator | intercomAttachedIndicator () const |
| | Returns the Intercom Attached Indicator from the PDU header.
|
| virtual void | setIffSimulationMode (bool interactive) |
| | Set the IFF Simulation Mode in the PDU header.
|
| virtual bool | iffSimulationMode () const |
| | Returns the IFF Simulation Mode from the PDU header.
|
| virtual void | setActiveInterrogationIndicator (bool active) |
| | Set the Active Interrogation Indicator in the PDU header.
|
| virtual bool | activeInterrogationIndicator () const |
| | Returns the Active Interrogation Indicator from the PDU header.
|
| virtual DtTime | guessTimeValid (DtTime referenceTime) const |
| | Since timestamp only represents number of seconds past the hour, guessTimeValid chooses the hour that would make the timestamp closest to reference time, and returns a time that is timestamp seconds past that hour.
|
| virtual DtNetPduHeader * | netHeader () const |
| | Returns a pointer to the PDU's header.
|
| virtual void | print () const |
| | Print the contents of the PDU by calling printToStream(DtInfo).
|
| virtual void | printHeader () const |
| | Print the PDU's header. This calls printHeaderToStream(DtInfo).
|
| virtual void | printHeaderToStream (std::ostream &stream) const |
| | Print the PDU's header to a stream.
|
| virtual void | printDataToString (DtString &str) const |
| virtual void | printPduInHexToStream (std::ostream &stream, unsigned int numberOfColumns) const |
| | Prints the entire PDU's internal buffer to the stream in Hex.
|
| virtual bool | isTransientPdu () const |
| | This method returns true if transient, false if state.
|
| virtual | ~DtBaseMsg () |
| | Destructor.
|
| | DtBaseMsg (const DtBaseMsg &msg, DtBufferPtr buffer=DtUSE_INTERNAL_BUFFER) |
| | Copy constructor.
|
| DtBaseMsg & | operator= (const DtBaseMsg &msg) |
| | Assignment.
|
| virtual const char * | netRep () const |
| | Get network representation.
|
| virtual int | length () const |
| | Get size of message.
|
| | DtBaseMsg () |
| | Constructor Object is not fully constructed until initMsg is called.
|
| void | initMsg (int size, DtBufferPtr bufferPtr) |
| void | initMsg (const void *initial, int size, DtBufferPtr bufferPtr) |
| virtual void | changeSize (int size, bool skipSizeChanged=false) |
| | Changes the size of the message.
|
| virtual void | insertBytes (int offset, int numBytes, bool skipSizeChanged=false) |
| | Inserts numBytes zeroed-out bytes at the indicated offset into the net rep.
|
| virtual void | insertBytes (void *address, int numBytes, bool skipSizeChanged=false) |
| | Inserts numBytes zeroed-out bytes at the indicated address.
|
| virtual void | deleteBytes (int offset, int numBytes, bool skipSizeChanged=false) |
| | Deletes numBytes bytes at the indicated offset in the net rep.
|
| virtual void | deleteBytes (void *address, int numBytes, bool skipSizeChanged=false) |
| | Deletes numBytes bytes starting at the indicated address.
|
| virtual void | clearAll () |
| | Zeros out all bytes in the network representation.
|
| virtual void * | newInternalBuffer (int size) |
| | Sets myInternalBuff to point to a malloc'ed buffer of size bytes.
|
Inheritance diagram for DtElectromagneticEmissionPdu:
