VR-Forces 4.10 Class Documentation
|
Description: This repository holds all information that is common to all the forms of all entity/aggregate/control objects within VR-Forces. More...
Public Types | |
| typedef std::map< DtString, DtString > | ExtendedData |
| typedef std::map< int, DtString > | ExtendedLabels |
| typedef std::map< DtString, std::map< DtString, DtRwJoystickControl > > | JoystickControls |
| Controls by function group. More... | |
 Public Types inherited from DtReaderWriter | |
| typedef std::vector < DtSymbolString > | aliasContainer |
| typedef std::vector < DtSymbolString >::iterator | aliasIter |
| typedef std::vector < DtSymbolString > ::const_iterator | aliasConstIter |
| typedef std::vector< DtFilename > | SearchPaths |
| typedef std::pair < DtSymbolString, DtString > | DtVariableNameType |
| typedef DtReaderWriterFactory *(* | DtReaderWriterFactoryCreatorFcn )() |
Public Member Functions | |
| DtVrfObjectStateRepository (DtVrfObject *vrfObject, const DtObjectType &objectType, DtVrfObjectParameters *parameters, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) | |
| Constructor. More... | |
| DtVrfObjectStateRepository (const DtVrfObjectStateRepository &orig, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) | |
| Copy Constructor. More... | |
| const DtVrfObjectStateRepository & | operator= (const DtVrfObjectStateRepository &orig) |
| Assignment Operator. More... | |
| virtual | ~DtVrfObjectStateRepository () |
| Destructor. More... | |
| virtual DtSimObjectStateRepository * | clone (const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) const |
| Clone. More... | |
| virtual DtString | type () const |
| returns DtSimObjectStateRepositoryType More... | |
| virtual const int | objectStateRepositorySubType () const |
| Returns DtSimObjectStateRepositorySubTypeVrfObject. More... | |
| virtual const int | vrfObjectStateRepositorySubType () const |
| Returns DtVrfObjectStateRepositorySubTypeBase. More... | |
| virtual bool | init () |
| Our 'virtual' constructor. Calls all the create<>() methods. More... | |
| virtual bool | createParameters () |
| virtual void | initializeFromParameters () |
| virtual const DtVrfObjectParameters * | vrfParameters () const |
| virtual void | setConcealed (bool) |
| Sets weather or not this object is concealed. More... | |
| virtual void | setJoystickMovementControlled (bool) |
| If true movement is controlled by joystick so will not be able to be taskable as a subordinate. More... | |
| virtual bool | joystickMovementControlled () const |
| virtual DtVrfStateRepositoryUserExtension * | userExtension () const |
| User extension to state repository class. More... | |
| virtual void | restoreEntity () |
| Called on a setRestore command, sets destroyed to false and sets resources to initial (parameter file) levels. More... | |
| virtual void | updateCachedStateProperties () |
| Call to update any cached values that are representative of state properties. More... | |
| virtual bool | wouldBeRecursiveAttach (DtSimObjectStateRepository *parent) const |
| Return true if attaching to this parent would cause a recursive attach. More... | |
| virtual void | restoreResourcesFromParameters () |
| virtual bool | isContactHostile (DtRwSensorContactInfo *) const |
| Given the potential contacts, queries the engagement zone manager to see if that particular contact is hostile. More... | |
| virtual bool | isContactHostile (const DtVrfObject *) const |
| This call will presume the object is of force type other and is only used for the location. More... | |
| virtual bool | isContactHostile (const DtVector &location, int perceivedForce) const |
| Given the location and the perceived force, iterate over all the engagement zones this object is monitoring in order to see if any one of them says this object is hostile. More... | |
| virtual bool | inSOR (const DtVrfObject *entity) const |
| virtual bool | canFireAt (const DtVector &location) const |
| Returns true if this entity can fire upon the supplied location given the rules of engagement. More... | |
| virtual const DtString & | engagementRules () const |
| virtual void | setEngagementRules (const DtString &engagementRules) |
| virtual bool | isTasked () const |
| Returns true if entity is currently executing a task (at least one component must be tasked), false otherwise. More... | |
| virtual void | clearCurrentTaskMsg (const DtSymbolString &componentName) |
| Clear all the tasks with the specified component name. More... | |
| virtual void | clearCurrentTaskMsg (const DtSymbolString &componentName, int taskId) |
| Clear the task with specified taskId and the specified component name. More... | |
| virtual const DtTaskStatusList * | taskStatusList () const |
| virtual DtTaskStatusList * | taskStatusList () |
| virtual DtSuspendedTaskStatusList * | suspendedTaskStatusList () |
| virtual DtTaskMessage * | taskByType (const DtSimTaskMessageType &task) const |
| Get the first task that is of the particular task type, if being executed. More... | |
| virtual DtTaskMessage * | currentTaskMsg (const DtSymbolString &componentName) const |
| Get the current task message. More... | |
| virtual DtTaskMessage * | currentTaskMsg (const DtSymbolString &componentName, int taskId) const |
| Get the current task message for the specified component and task ID. More... | |
| virtual std::list < DtTaskMessage * > | allCurrentTaskMsg (const DtSymbolString &componentName) const |
| virtual void | putSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtReaderWriter::appPath()) |
| Top level call to write itself to file. More... | |
| virtual bool | placePoints (const DtAttachedTerrain &attachedTerrain, std::vector< DtGroundInteractionPt * > groundInteractionPts, bool *terrainDataAvailable=0) const |
| Positions list of ground interaction points on the terrain surface closest to the specified location. More... | |
| virtual void | updateSupportPoints (const DtVector &newPosition, const DtReal newHeading) |
| reading in a scenario, want to make sure the support points get set up properly. More... | |
| virtual const DtVrfObjectParameters * | parameters () const |
| virtual DtVrfObjectParameters * | modifiableParameters () |
| A modifiable local copy of parameters. More... | |
| virtual void | setupParameterInheritance () |
| Called by init(). More... | |
| virtual bool | createAttachments () |
| Override to create derived DtVrfAttachmentManager. More... | |
| DtArticulatedPartStateRepository * | addPart (DtArtPartType partType) |
| These will be replaced by equivalents in the attachment manager. More... | |
| void | removePart (DtArtPartType partType) |
| DtArticulatedPartStateRepository * | part (DtArtPartType partType) |
| DtArticulatedPartStateRepository * | findDescendantByType (DtArtPartType childType) |
| virtual void | setInvisible (bool) |
| Whether or not this item is invisible to sensors, line of sight, etc. More... | |
| virtual bool | invisible () const |
| virtual void | setInvulnerable (bool) |
| Whether or not this item is invulnerable. More... | |
| virtual bool | invulnerable () const |
| virtual void | setUndetectable (bool) |
| Whether or not this item is undetectable. More... | |
| virtual bool | undetectable () const |
| virtual void | setBlockParachute (bool) |
| Block parachute flag. Can be used to prevent parachute animations. More... | |
| virtual bool | blockParachute () const |
| virtual void | setInvisibleSetByUser (bool) |
| Whether or not this item was set invisible by a set command. More... | |
| virtual bool | invisibleSetByUser () const |
| bool | sensorsKilled () const |
| Indicates that the entity's sensors have been killed. More... | |
| void | setSensorsKilled (bool sensorsKilled) |
| bool | isEntity () const |
| bool | isLocal () const |
| bool | isAggregate () const |
| void | addSubordinate (const DtVrfObject *subordinateEntity) |
| Adds an entity as a subordinate. More... | |
| void | removeSubordinate (const DtVrfObject *subordinateEntity) |
| Removes entity from our list of subordinates. More... | |
| virtual DtSharedVrfObjectReference | leadEntity () const |
| virtual DtSharedVrfObjectReference | firstSubordinate () const |
| virtual DtSharedVrfObjectReference | lastSubordinate () const |
| virtual DtSharedVrfObjectReference | firstHealthySubordinate () const |
| virtual void | tick () |
| This method is called each simulation frame, and may include any processing that needs to be done on this object state each tick. More... | |
| virtual void | timedTick () |
| This version of tick checks to see if the time to tick has arrived (myNextTickTime <= exerciseClock()->approximateElapsedRealTime()). More... | |
| virtual void | setMinTickPeriod (double minTickPeriod) |
| specifies a minimum tick period (which can also be thought of as More... | |
| virtual double | minTickPeriod () const |
| access the minimum tick period More... | |
| virtual void | setMinTickPeriodVariance (double minTickPeriodVariance) |
| set the variance in the minimum tick time More... | |
| virtual double | minTickPeriodVariance () const |
| access the variance in the minimum tick period More... | |
| virtual void | setNextTickTime (double nextTickTime) |
| The next tick time is normally calculated internally. More... | |
| virtual double | nextTickTime () const |
| access the next tick time More... | |
| virtual double | calculateNextTickTime () const |
| The next tick time is equal to mySimManager->exerciseClock()-> approximateElapsedRealTime() + myMinTickPeriod + a random # between -myMinTickPeriodVariance/2. More... | |
| virtual bool | createSubordinates () |
| virtual DtVrfSubordinateManager * | vrfSubordinates () |
| virtual const DtVrfSubordinateManager * | vrfSubordinates () const |
| virtual bool | createProcessStateRepositoryManager () |
| virtual const DtTaitBryan & | localOrientationWrtDatabase () const |
| Euler angles with respect to the local (database) coordinate system, in radians. More... | |
| virtual void | setLocalOrientationWrtDatabase (const DtTaitBryan &localOrientation) |
| virtual DtVrfWeaponPSR * | firstWeaponPSR () const |
| This is provided for backward compatibility with setTarget capabilities. More... | |
| virtual void | processObjectGeometry (const DtList &vertices) |
| Processes a list of DtVectors, such as might come in a create or modify message. More... | |
| virtual void | processObjectGeometry (const DtLocalVertexList &vertices) |
| virtual void | processObjectGeometry () |
| This form allows processObjectGeometry()'s bounding volume calculations to be done on it's current geometry (by making a copy first). More... | |
| virtual const DtVrfObjectParameters * | vrfBaseParameters () const |
| virtual DtGroundInteractionPt * | groundCenter () |
| virtual const DtGroundInteractionPt * | groundCenter () const |
| virtual void | place (const DtVector &location, bool *dataAvailable=0, bool requireAllData=false) |
| Place entity at 'location', on the ground, keeping its current heading. More... | |
| virtual void | place (const DtReal heading, bool *dataAvailable=0, bool requireAllData=false) |
| Give entity the specified 'heading', but stay at its current location. More... | |
| virtual void | place (const DtVector &location, const DtReal heading, bool clampToGroundFlag=true, bool *dataAvailable=0, bool requireAllData=false) |
| Place entity at specified 'location' and 'heading' on the ground. More... | |
| virtual void | reclampToGround () |
| Will cause the object to be replaced at it's current position and clamped to the terrain. More... | |
| virtual void | updatePositionFromModelVertices () |
| Note that this is not currently ever called. More... | |
| virtual DtReal | mass () const |
| virtual void | setMass (const DtReal mass) |
| virtual const DtArticulatedPartCollection * | artPartList () const |
| Get the list of articulated parts specified in the component descriptor. More... | |
| virtual void | createParts () |
| This causes the art part tree to be created. More... | |
| virtual DtTime | lastTimeFiredUpon () const |
| virtual void | setLastTimeFiredUpon (const DtTime time) |
| virtual bool | underFire () const |
| virtual void | setUnderFire (bool underFire) |
| virtual bool | systemEnabled (const DtString &systemName) const |
| virtual void | setSystemEnabled (const DtString &systemName, bool enabled) |
| virtual const DtRwPriorityTargetListMap & | targetPriorityList () const |
| Get/set/append to target priority list. More... | |
| virtual DtRwPriorityTargetListMap & | targetPriorityList () |
| virtual void | setTargetPriorityList (const DtRwPriorityTargetListMap &targetPriorityList) |
| virtual void | appendToTargetPriorityList (const DtRwPriorityTargetListMap &targetPriorityList) |
| virtual int | targetPriorityLevel (const DtUUID &obj) const |
| Returns a positive value of priority if object is in the target priority list Returns DtPriorityLevelInvalid otherwise. More... | |
| virtual const DtString & | nonLethalDamageEffect () const |
| The current non lethal damage type. More... | |
| virtual void | setNonLethalDamageEffect (const DtString &nonLethalDamageEffect) |
| virtual DtDeadReckonTypes | deadReckoningAlgorithm () const |
| virtual void | setDeadReckoningAlgorithm (DtDeadReckonTypes deadReckoningAlgorithm) |
| virtual void | putData (std::string &fp, int indentLevel=0) |
| Override putData to set myParent using the organization manager before saving. More... | |
| virtual void | getSelf (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| Override getSelf to handle mapping of old pre-2.0 oob files. More... | |
| virtual int | nextTaskId () |
| Returns next unique task id for this entity. More... | |
| virtual int | nextSuspendId () |
| virtual DtTaskMessage * | pendingSubtask (int subtaskId, DtString &controller) const |
| Returns the current subtask with the specified id. More... | |
| virtual bool | taskedBySuperiorUponTaskComplete () const |
| Returns true if entity should automatically resume being tasked by superior upon completion of its current top-level task, false otherwise. More... | |
| virtual void | setParentWasDestroyedWhenEmbarked (bool) |
| virtual bool | parentWasDestroyedWhenEmbarked () const |
| virtual void | detachFromParent () |
| virtual void | attachToParent (DtSimObjectStateRepository *parent) |
| Adds this state repository to the given parent's list of attached state repositories and updates myAttachedToRepository and myRootSimStateRepository. More... | |
| virtual void | attachToParent (const DtUUID &parent) |
| Looks up the parent state repository using the given echelon ID and puts it in a call to attachToParent. More... | |
| virtual void | addAttachedTerrain (const DtUUID &parent) |
| Asks the sim manager to look up the object model for the requested database. More... | |
| virtual void | removeAttachedTerrain (const DtUUID &parent) |
| Decreases reference count of terrain model by name of object. More... | |
| Dt3dBoundingVolume * | boundingVolume () const |
| Convenience method for accessing entity's bounding volume, stored in myObjectGeometry. More... | |
| DtVector | localBoundingVolumeCenterPosition () const |
| Gets the local coordinates of the bounding volume center. More... | |
| DtReal | forwardSpeed () const |
| virtual double | totalMass () const |
| Returns the current total mass of the entity. More... | |
| virtual void | restoreStateProperties () |
| Restores state properties to their default settings. More... | |
| virtual void | initStatePropertiesNotToBeRestored () |
| Initializes the list of state properties which should not be restored. More... | |
| virtual bool | fuelLevelsFrozen () |
| check frozen state of fuel and munition levels More... | |
| virtual bool | munitionLevelsFrozen () |
| virtual void | addRangeItem (const DtRangeItem &) |
| Adds, removes and returns items in the range item list. More... | |
| virtual void | removeRangeItem (int index) |
| virtual void | setRangeItems (const DtRangeItems &) |
| const DtRangeItems & | rangeItems () const |
| DtRangeItems & | rangeItems () |
| virtual void | clearRangeItems () |
| DtAttachedTerrain * | terrainAttachedTo () const |
| virtual boost::tribool | onTerrainSurface () const |
| virtual double | sensorSignature (const DtSymbolString &sensorDomain) const |
| Returns the current absolute signature for this object in the specified sensor domain. More... | |
| virtual std::list< DtSymbolString > | sensorSignatureDomains () const |
| virtual DtString | stringFromExtendedData (const DtString &) const |
| Takes the extended data string, and, if xml, will pretty print and remove the quotes from the created reader/writer else just return the string. More... | |
| virtual std::map< DtString, DtString > | unarchivedData () const |
| Extended data that is not archived that is currently in the extended data list. More... | |
| virtual void | appendExtendedData (const std::map< DtString, DtString > &) |
| Append extended data to extended data map. More... | |
| virtual void | setFiredLaserMissileAtTarget (const DtUUID &) |
| If this is set, and the system component flag for blocking fire of other laser weapons when this is live is also true, other laser weapons on this system will not have permission to fire. More... | |
| virtual const DtUUID & | firedLaserMissileAtTarget () const |
| virtual DtVrfObjectStateRepository * | toVrfObjectStateRepository () |
| virtual const DtVrfObjectStateRepository * | toVrfObjectStateRepository () const |
| virtual void | addRestoredCallback (DtVrfObjectCallbackList::DtCallbackFunctionType fcn, void *usr) |
| Callback that is invoked when the entity is about to be removed from the simulation. More... | |
| virtual void | removeRestoredCallback (DtVrfObjectCallbackList::DtCallbackFunctionType fcn, void *usr) |
| virtual void | invokeRestoredCallbacks () |
| virtual void | setExtendedData (const DtString &key, const DtString &value) |
| virtual void | clearExtendedData () |
| virtual void | removeExtendedData (const DtString &key) |
| virtual DtString | extendedData (const DtString &key) const |
| const ExtendedData & | extendedDataMap () const |
| virtual void | setExtendedDataMap (const ExtendedData &) |
| virtual void | setExtendedDataMap (const std::map< std::string, std::string > &) |
| virtual void | setupExtendedDataFromParameterData () |
| If publishing parameter data also include that in the extended data map by name. More... | |
| virtual void | setExtendedLabel (int, const DtString &value) |
| virtual void | clearExtendedLabels () |
| virtual DtString | extendedLabel (int index) const |
| virtual ExtendedLabels | extendedLabels () const |
| virtual void | setExtendedLabels (const ExtendedLabels &) |
| virtual void | addJoystickControls (const DtRwJoystickControls &) |
| virtual const JoystickControls & | joystickControls () const |
| virtual void | setActivity (const DtString &) |
| virtual DtString | activity () const |
| virtual const DtObjectResourceManager * | objectResourceManager () const |
| virtual DtObjectResourceManager * | objectResourceManager () |
Legacy Resources | |
These methods access the resource manager in the way it was accessible in VR-Forces 3.10 and earlier. In VR-Forces 3.11, the prefix "old" was added to these method names, but their functionality remains the same. using the objectResourceManager() methods, or accessing the resource manager from the components is now the preferred method. | |
| virtual const DtSimResourceManager & | oldResourceManager () const |
| Returns a reference to our resource manager. More... | |
| virtual DtSimResourceManager & | oldResourceManager () |
| virtual DtSimResource * | oldLookupResource (const DtString &resourceName) |
| Gets a pointer to the resource named resourceName. More... | |
| virtual const DtSimResource * | oldLookupResource (const DtString &resourceName) const |
| virtual void | oldAddResource (DtSimResource *resource) |
| This does a clone of the resource and puts it on our main list, as well as adding the resource to the hash index. More... | |
| virtual void | oldRemoveResource (DtSimResource *resource) |
| This removes and deletes the specified resource. More... | |
| virtual void | setNavigationEnabled (bool) |
| virtual bool | navigationEnabled () const |
| virtual void | setSOR (DtReal center, DtReal size) |
| Sector of responsibility. More... | |
| virtual DtReal | SORSize () const |
| virtual DtReal | SORCenter () const |
| virtual const DtSimSector & | SOR () const |
| virtual void | setRequestTaskNeeded (bool value) |
| Set/get whether or not this needs to send a request task needed message. More... | |
| virtual bool | requestTaskNeeded () const |
| virtual void | setTasked (const DtSymbolString &componentName, bool tasked) |
| Set/get whether or not a given entity component currently executing a task. More... | |
| virtual void | setTasked (const DtSymbolString &componentName, int taskID, bool tasked) |
| virtual bool | tasked (const DtSymbolString &componentName) const |
| virtual void | setCurrentTaskMsg (const DtSymbolString &componentName, const DtTaskMessage &taskMsg) |
| Set the current task message. More... | |
| virtual void | setCurrentTaskMsg (const DtSymbolString &componentName, const DtTaskMessage &taskMsg, int taskId) |
| virtual void | setIndependentlyTasked (bool value) |
| Set/get whether or not this entity is currently independently tasked (separately from its unit). More... | |
| virtual bool | independentlyTasked () const |
| virtual const DtVrfObjectParameters * | parameterEntry () const |
| If a clone has been created, this call will return the cloned entry as a const pointer, else returns the original pointer. More... | |
| virtual void | setParameterEntry (DtVrfObjectParameters *parameterEntry) |
| virtual DtForceType | forceType () const |
| Get/Set the force type (team) of this entity. More... | |
| virtual void | setForceType (DtForceType force) |
| virtual bool | createAppearance () |
| Encapsulates all the appearance related data and methods currently in the entity state repository. More... | |
| virtual const DtAppearance * | appearance () const |
| virtual DtAppearance * | appearance () |
| virtual void | setCapabilities (int cap) |
| Gets/sets capabilities of entity This is treated as the DIS capabilities bit field, and does not necessarily change any behaviors of the object. More... | |
| virtual int | capabilities () const |
| virtual void | setDestroyed (bool isDestroyed) |
| Destroyed status of entity (whether or not appearance()->damageState() is set to DtDamageDestroyed). More... | |
| virtual bool | isDestroyed () const |
| virtual void | setOccupantsHidden (bool v) |
| Whether or not the occupants of an entity are visually hidden. More... | |
| virtual bool | occupantsHidden () const |
| DtReal | healthPct () const |
| void | setHealthPct (DtReal pct) |
| bool | firePowerKilled () const |
| Convenience methods for setting setting entity's appearance bits in DtAppearance. More... | |
| void | setFirePowerKilled (const bool firePowerKilled) |
| bool | mobilityKilled () const |
| void | setMobilityKilled (const bool mobilityKilled) |
| bool | flaming () const |
| void | setFlaming (const bool flaming) |
| bool | smoking () const |
| void | setSmoking (const bool smoking) |
| virtual DtVrfSubordinateManager * | subordinates () |
| virtual const DtVrfSubordinateManager * | subordinates () const |
| virtual DtSimManager * | simManager () |
| virtual const DtSimManager * | simManager () const |
| virtual DtPhysicalWorld * | physicalWorld () |
| virtual const DtPhysicalWorld * | physicalWorld () const |
| virtual const DtVrfProcessStateRepositoryManager * | systemProcessStateRepositoryManager () const |
| virtual DtVrfProcessStateRepositoryManager * | systemProcessStateRepositoryManager () |
| virtual const DtThresholder & | deadReckoningThresholder () const |
| Dead-reckoning threshold parameters. More... | |
| virtual void | setDeadReckoningThresholder (const DtThresholder &thresholder) |
| virtual const DtEntityIdentifier & | occupyingObjectId () const |
| We hold the id of the object we are occupying. More... | |
| virtual void | setOccupyingObjectId (const DtEntityIdentifier &objId) |
| virtual void | setEchelonId (const DtEchelonId &echelonId) |
| The echelon ID of this object, if it is an organized object. More... | |
| virtual DtEchelonId & | echelonId () |
| virtual const DtEchelonId & | echelonId () const |
| virtual void | setIsSubordinateOfForceLevel (bool yesNo) |
| Indicates if this object's direct superior is a Force level object. More... | |
| virtual bool | isSubordinateOfForceLevel () const |
| virtual int | spawningTaskId (int subtaskId) const |
| Functions for manipulating the set of pending subtask Ids for all components in the entity. More... | |
| virtual void | addPendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual void | addPendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual bool | findPendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual bool | isSubtasked (const DtSymbolString &componentName) const |
| virtual bool | findPendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual void | removePendingSubtaskId (const DtSymbolString &componentName, int subtaskId) |
| virtual void | removePendingSubtaskId (const DtSymbolString &componentName, int taskId, int subtaskId) |
| virtual void | removeAllPendingSubtaskIds (const DtSymbolString &componentName) |
| virtual void | removeAllPendingSubtaskIds (const DtSymbolString &componentName, int taskId) |
| virtual void | removeInactiveSubtaskStatus (const DtSymbolString &componentName) |
| virtual void | removeInactiveSubtaskStatus (const DtSymbolString &componentName, int taskId) |
| virtual void | printPendingSubtaskIds (const DtSymbolString &componentName) const |
| virtual std::vector< int > | currentPendingSubstaskIds (const DtSymbolString &componentName) const |
| virtual std::vector< int > | currentPendingSubstaskIds (const DtSymbolString &componentName, int taskId) const |
| virtual DtSubtaskStatusEntry * | pendingSubtaskStatus (const DtSymbolString &componentName, int subtaskId) |
| virtual DtSubtaskStatusEntry * | pendingSubtaskStatus (const DtSymbolString &componentName, int taskId, int subtaskId) |
| DtReal | currentSpeed () const |
| Returns magnitude of relative velocity in state repository. More... | |
| DtReal | currentHeading () const |
| Heading in radians. Calls down to DtVrfKinematicState for heading. More... | |
| void | setCurrentHeading (const DtReal heading) |
| virtual const DtRwNLengthUUIDVector & | engagementZones () const |
| Accessor/mutator for engagement zones. More... | |
| virtual void | setEngagementZones (const DtRwNLengthUUIDVector &) |
| virtual void | addPostInitFromParamsCallback (DtPostInitializeFromParametersCallbackFcn fcn, void *usr) |
| Add/remove callback function to be invoked immediately following execution of initializeFromParameters. More... | |
| virtual void | removePostInitFromParamsCallback (DtPostInitializeFromParametersCallbackFcn fcn, void *usr) |
| virtual DtRwProperties & | stateProperties () |
| Accesses to the properties. More... | |
| virtual const DtRwProperties & | stateProperties () const |
| virtual DtRwProperties & | parameterProperties () |
| Access to static (parameter) properties. More... | |
| virtual const DtRwProperties & | parameterProperties () const |
| virtual DtSensorContactInfoList & | objectContactList () |
| Situational awareness of this object. More... | |
| virtual const DtSensorContactInfoList & | objectContactList () const |
| Public Member Functions inherited from DtSimObjectStateRepository | |
| DtSimObjectStateRepository (DtVrfObject *simObject, const DtObjectType &objectType, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) | |
| const DtSimObjectStateRepository & | operator= (const DtSimObjectStateRepository &orig) |
| virtual | ~DtSimObjectStateRepository () |
| virtual const DtObjectType & | objectType () const |
| virtual void | setObjectType (const DtObjectType &objectType) |
| virtual bool | createKinematicState () |
| Creates a DtVrfKinematicState. More... | |
| virtual DtVrfKinematicState * | vrfKinematicState () |
| virtual const DtVrfKinematicState * | vrfKinematicState () const |
| virtual bool | createObjectGeometry () |
| virtual DtVrfObjectGeometry * | vrfObjectGeometry () |
| virtual const DtVrfObjectGeometry * | vrfObjectGeometry () const |
| virtual DtAttachmentManager * | attachments () |
| virtual const DtAttachmentManager * | attachments () const |
| virtual DtArticulatedPartManager & | articulatedParts () |
| virtual const DtArticulatedPartManager & | articulatedParts () const |
| virtual const DtSimObjectStateRepository * | parent () const |
| virtual bool | isEmbarkedOn (const DtUUID &parent) const |
| virtual const DtUUID & | attachedToRepository () const |
| virtual DtSimObjectStateRepository * | findRootSimStateRepository () |
| virtual const DtSimObjectStateRepository * | findRootSimStateRepository () const |
| virtual void | setOwnedByHostObject (bool) |
| When state repositories get added to the attachment manager, the attachment manager assumes it takes ownership of that state repository, and, when it is deleted, it will destroy any state repository that is still attached. More... | |
| virtual bool | ownedByHostObject () const |
| virtual void | ancestorObjectChanged () |
| virtual void | preGetSelf () |
| Hook function called immediately prior to getSelf(). More... | |
| virtual void | removeRepositoryAboutToBeDeletedCallback (DtSimObjectStateRepositoryAboutToBeDeletedCallbackFcn, void *usr) |
| Add/remove callback for notification that this state repository is about to be deleted. More... | |
| virtual void | addRepositoryAboutToBeDeletedCallback (DtSimObjectStateRepositoryAboutToBeDeletedCallbackFcn, void *usr) |
| virtual void | invokeRepositoryAboutToBeDeletedCallbacks () |
| virtual void | processUUIDChanged (const DtVrfObjectUUIDChangedCallbackInfo &) |
| virtual void | setCoordinateSystem (const Coordinate_System *coordinateSystem) |
| Sets the coordinate system in myObjectGeometry and myKinematicState. More... | |
| virtual const DtVrfObject * | vrfObject () const |
| virtual void | setVrfObject (DtVrfObject *vrfObject) |
| virtual DtSimKinematicState * | kinematicState () |
| virtual const DtSimKinematicState * | kinematicState () const |
| virtual DtVrfObjectGeometry * | objectGeometry () |
| virtual const DtVrfObjectGeometry * | objectGeometry () const |
| virtual const DtVector & | bodyPosition () const |
| Now superseded by kinematic state parentCS functions. More... | |
| virtual void | setBodyPosition (const DtVector &pos) |
| Formerly setMeInParent. More... | |
| virtual void | setBodyPosition (DtFloat64 x, DtFloat64 y, DtFloat64 z) |
| const DtDcm & | bodyOrientationMatrix () const |
| Formerly meToParent(). More... | |
| virtual void | embarkOnParent (const DtUUID &parent) |
| Embarks this entity on the specified parent. More... | |
| virtual bool | leftOf (const DtVector &localVector) const |
| virtual bool | inside (const DtVector &point) const |
| virtual double | distanceToLocalVector (const DtVector &localVector) const |
| Returns the distance from a position in local. More... | |
| const Coordinate_System * | coordinateSystem () const |
| virtual void | removeVertex (int iIndex) |
| These routines simply call down to the kinematic state to get/set the results. More... | |
| virtual void | addLocalVertex (const DtVector &vertex) |
| virtual void | addLocalVertex (const DtVector &vertex, DtVector &newGeometricCenter) |
| virtual void | setLocalVertices (const DtLocalVertexList &vertices, DtVector &newGeometricCenter) |
| virtual void | setLocalVertices (const DtList &vertices, DtVector &newGeometricCenter) |
| virtual const DtLocalVertexList & | localVertices () const |
| virtual const DtLocalVectorIterator & | localVertexIterator () const |
| virtual void | addWorldVertex (const DtVector &vertex, DtVector &newGeometricCenter) |
| virtual void | setWorldVertices (const DtVertexList &vertices, DtVector &newGeometricCenter) |
| virtual void | setWorldVertices (const DtList &vertices, DtVector &newGeometricCenter) |
| virtual const DtVertexList & | worldVertices () const |
| virtual const DtRwVectorIterator & | worldVertexIterator () const |
| virtual void | setRelativeVertices (const DtLocalVertexList &vertices) |
| Access/modify vertices relative to to the parent to which this object is attached. More... | |
| virtual void | setRelativeVertices (const DtList &vertices) |
| virtual const DtLocalVertexList & | relativeVertices () const |
| virtual const DtLocalVectorIterator & | relativeVertexIterator () const |
| const DtVector & | localPosition () const |
| Convenience methods for accessing corresponding methods in DtVrfKinematicState. More... | |
| void | setLocalPosition (const DtVector &pos) |
| const DtVector & | localVelocity () const |
| void | setLocalVelocity (const DtVector &vel) |
| const DtVector & | localAcceleration () const |
| void | setLocalAcceleration (const DtVector &acc) |
| const DtVector & | relativeVelocity () const |
| void | setRelativeVelocity (const DtVector &vel) |
| const DtVector & | relativeAcceleration () const |
| void | setRelativeAcceleration (const DtVector &acc) |
| const DtTaitBryan & | localOrientation () const |
| void | setLocalOrientation (const DtTaitBryan &angles) |
| const DtVector & | worldPosition () const |
| void | setWorldPosition (const DtVector &pos) |
| const DtVector & | worldVelocity () const |
| void | setWorldVelocity (const DtVector &vel) |
| const DtVector & | worldAcceleration () const |
| void | setWorldAcceleration (const DtVector &acc) |
| const DtTaitBryan & | worldOrientation () const |
| void | setWorldOrientation (const DtTaitBryan &angles) |
| const DtVector & | rotationalVelocity () const |
| void | setRotationalVelocity (const DtVector &rotationalVelocity) |
| const DtDcm & | localOrientationMatrix () const |
| void | setLocalOrientationMatrix (const DtDcm &orient) |
| void | setParentPosition (const DtVector &pos) |
| const double | lastPositionSetTime () const |
| Indicates the last time the position was set, so that a precise position at the current time may be computed. More... | |
| void | setLastPositionSetTime (const double simTime) |
| Public Member Functions inherited from DtReaderWriter | |
| DtReaderWriter () | |
| default constructor More... | |
| DtReaderWriter (const DtString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| real constructor Setting the readonly flag prevents object from writing itself to the stream. More... | |
| DtReaderWriter (const DtSymbolString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| DtReaderWriter (const DtString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| pseudo-copy constructor More... | |
| DtReaderWriter (const DtSymbolString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| DtReaderWriter (const DtReaderWriter &, DtReaderWriterRegistry *parentRegistry=NULL) | |
| copy constructor More... | |
| const DtReaderWriter & | operator= (const DtReaderWriter &orig) |
| assignment operator More... | |
| bool | operator== (const DtReaderWriter &) const |
| Equivalence operator. More... | |
| bool | operator!= (const DtReaderWriter &rhs) |
| virtual | ~DtReaderWriter () |
| destructor More... | |
| virtual void | postPutSelf () |
| Called after either version of put self (file or environment). Default is no-op. More... | |
| virtual void | prePutSelf () |
| Called before either version of put self (file or environment). Default is no-op. More... | |
| virtual void | writeSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| Called from putSelf, calls myRegistry.putSelf which in turn calls putSelf on each reader/writer in the registry. More... | |
| virtual DtSymbolString | name () const |
| Accessor for name of this readable/writable object. More... | |
| virtual void | addAlias (const DtSymbolString &alias) |
| Add an alias as an alternative name for this object. More... | |
| virtual void | addAlias (const DtString &alias) |
| virtual bool | hasAlias (const DtSymbolString &alias) |
| virtual const aliasContainer & | aliases () const |
| virtual void | setReadonly (bool flag) |
| Set read-only flag. More... | |
| bool | isReadonly () const |
| virtual void | reset () |
| For those reader/writer items that support it, resets the reader/writer value to original state Default is no-op. More... | |
| virtual int | alignment () const |
| For those items that are sent over the network via HLA, this will give the network alignment. More... | |
| virtual bool | variableIsBound () const |
| virtual void | unbindVariable () |
| Sets the myVariableIsBound flag to false. More... | |
| virtual void | setName (const DtString &) |
| Set the name of the object. More... | |
| virtual const char * | readerWriterType () const |
| Used to supply a string type that this reader writer type is. More... | |
| virtual const char * | xmlType () const |
| virtual DtString | prettyPrint () const |
| Routine to return a human readable form of the reader/writer variable. More... | |
| std::string | debugText () const |
| virtual void | bindVariables (DtVariableBindingsList variableBindings) |
| Runs a variable binding pass on this reader writer and any of its children. More... | |
| virtual std::list < DtVariableNameType > | unboundVariables () const |
| bool | invalid () const |
| virtual bool | hasChild (const DtReaderWriter *p) const |
| Returns true if this variable has a child p in it's chain. More... | |
| virtual bool | hasVariableReference () const |
| Returns true if this item or any item in the registry (recursive) is a variable reference. More... | |
| virtual void | bindLocalVariables (const DtVariableBindingsList &variableBindings) |
| Checks to see if this RW object is a variable reference that can be bound using the provided bindings. More... | |
| virtual void | recordUpdateTime () const |
| Can be implemented in subclasses to stamp the time when updated. More... | |
| virtual bool | wasUpdatedSince (DtTime t) const |
| Can be implemented in subclasses to return true if an update occurred after the specified time. More... | |
| virtual bool | changedSinceLastChecked () |
| Returns true if this objects value has changed since the last time this function was called. More... | |
| virtual bool | peekChangedSinceLastChecked () const |
| Returns the value that changedSinceLastChecked would return but does not reset the internal flag. More... | |
| virtual DtlObjPtr | getData (DtlObjPtr args, const SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| virtual void | setValueSpecified (bool specified, bool recurse=false) |
| The specified flags are used for optional values. More... | |
| virtual bool | valueSpecified () const |
| virtual bool | isVariableReference () const |
| Specifies whether or not this reader writer is really a variable that is specified elsewhere. More... | |
| virtual void | setIsVariableReference (bool value) |
| virtual void | clearAllVariableReferenceFlags () |
| Clears out all variable reference flags from all readerwriter items in registry recursively. More... | |
| virtual DtSymbolString | variableName () const |
| The variable name, if this object is a variable reference. More... | |
| virtual void | setVariableName (const DtSymbolString variableName) |
| virtual const DtReaderWriter * | defaultRWValue () const |
| The default value to use if the reader/writer object is a variable and that variable is not specified. More... | |
| virtual DtReaderWriter * | defaultRWValue () |
| virtual void | setDefaultRWValue (DtReaderWriter *) |
| Previous default value, if exists, will be removed and replaced with a clone of the supplied variable. More... | |
| virtual bool | checkAndSetDefaultRWValue (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &variableBindings=nullVariableReference()) |
| Give the stream, if the stream contains a default value then set it here. More... | |
| const DtReaderWriterRegistry & | registry () const |
| Collection of child DtReaderWriter nodes owned by this object. More... | |
| DtReaderWriterRegistry & | registry () |
| virtual DtPropertyInterface * | property () |
| virtual const DtPropertyInterface * | property () const |
| virtual DtString | toXml () const |
| virtual DtRwVariableBindings * | generateVariableBindings () const |
| Iterates over the registry (recursively) and returns a variable bindings object that contains all the variables that are contained in this read/writer class. More... | |
| virtual bool | toXml (const DtFilename &) const |
| Writes contents of xml result to the given filename. More... | |
| virtual bool | fromXml (const DtString &) |
| Restores object from given xml string. Returns true if valid. More... | |
| virtual bool | fromXmlFile (const DtFilename &) |
| Restores object from given xml file. More... | |
| virtual void | putSelf (DtEnvironmentSP, DtEnvValueSP parent) const |
| virtual void | putData (DtEnvironmentSP, DtEnvValueSP value) const |
| Override to add attributes of actual data. More... | |
| virtual void | putVariableReference (DtEnvironmentSP, DtEnvValueSP value) const |
| Called when the item is a variable reference. More... | |
| virtual void | getSelf (const DtEnvironmentSP, const DtEnvValueSP root, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| virtual void | getData (const DtEnvironmentSP, const DtEnvValueSP, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| Gets data from the environment value. More... | |
| virtual void | unrecognizedItem (const DtEnvironmentSP env, const DtEnvValueSP root, const SearchPaths &searchPaths, const DtVariableBindingsList &varBindings) |
| Called when the xml reader tries to parse an unknown reader/writer item. Default is a no-op. More... | |
| virtual void | getVariableReference (DtEnvironmentSP, DtEnvValueSP value) |
| Called when the item is a variable reference. More... | |
Static Public Member Functions | |
| static bool | shouldArchiveExtendedAttribute (const DtString &) |
| true if the given attribute should be archived. Use static methods to add/remove keywords More... | |
| static void | doNotArchiveAttribute (const DtString &, bool) |
| static DtVrfObjectStateRepository * | createRepository (const DtString &name, const DtString &type, DtVrfObject *simObject, const DtObjectType &objectType, DtVrfObjectParameters *parameters, DtReaderWriterRegistry *parentRegistry=0) |
| Creates a new state repository object, using the factory. More... | |
| static void | addSimObjectStateRepositoryCreatorFcn (const DtString &type, DtSimObjectStateRepositoryCreatorFcn fcn) |
| static DtVrfObjectStateRepository * | creator (const DtString &name, DtVrfObject *simObject, const DtObjectType &objectType, DtVrfObjectParameters *parameters, DtReaderWriterRegistry *parentRegistry) |
| static DtVrfObjectStateRepository * | isVrfObjectStateRepository (DtSimObjectStateRepository *repository) |
| static const DtVrfObjectStateRepository * | isVrfObjectStateRepository (const DtSimObjectStateRepository *repository) |
| static DtSimObjectStateRepositoryFactory * | factory () |
| a DtSimObjectStateRepositoryFactory is allocated by the DtSimCreator, and this pointer is set. More... | |
| static void | setFactory (DtSimObjectStateRepositoryFactory *factory) |
| Static Public Member Functions inherited from DtSimObjectStateRepository | |
| static void | completeAttachmentCallback (const DtVrfObject *simObject, void *usr) |
| These callbacks are used to set myAttachedToStateRepository when this ent gets attached/detached to/from its parent. More... | |
| static void | objectAboutToBeRemovedCallback (const DtVrfObject *simObject, void *usr) |
| static void | uuidChangedCallback (const DtVrfObjectUUIDChangedCallbackInfo &, void *usr) |
| static DtSimObjectStateRepository * | isSimObjectStateRepository (DtSimObjectStateRepository *repository) |
| static const DtSimObjectStateRepository * | isSimObjectStateRepository (const DtSimObjectStateRepository *repository) |
| Static Public Member Functions inherited from DtReaderWriter | |
| static void | putIndent (std::string &fp, int indentLevel) |
| static const DtVariableBindingsList & | nullVariableReference () |
| static void | setPostGetSelfCallback (DtGetSelfCallbackFcn fcn, void *usrData) |
| static void | setPrePutSelfCallback (DtPutSelfCallbackFcn fcn, void *usrData) |
| static void | setPutIndent (bool) |
| static bool | putIndent () |
| static const char * | theXmlType () |
| The type that is used when archiving to an XML stream. More... | |
| static const DtFilename & | appPath () |
| Gets the current working directory. More... | |
| static void | setFactoryCreatorFunction (DtReaderWriterFactoryCreatorFcn fcn) |
| Sets the function to create the DtReaderWriterFactory. More... | |
| static void | createReaderWriterFactory () |
| static void | cleanupFactory () |
| static DtReaderWriterFactory * | factory () |
| static void | setOutputStream (DtOutputStream *stream) |
| static DtOutputStream & | outputStream () |
| static DtReaderWriter * | createFromXmlFile (const DtFilename &, bool createAsProperty=false) |
| Given a filename, returns a newly created reader/writer object from the object found within. More... | |
| static DtReaderWriter * | createFromXml (const DtString &, bool createAsProperty=false) |
| Given a xml string, returns a newly created reader/writer object from the object found within. More... | |
| static DtReaderWriter * | createFromEnvironment (DtEnvironmentSP, bool createAsProperty=false) |
| Given a xml environment, returns a newly created reader/writer object from the object found within. More... | |
| static DtString | getAttribute (DtEnvironmentSP env, const DtString &name, DtEnvValueSP root) |
| Gets the named attribute from a DtEnvValueSP. More... | |
Protected Types | |
| typedef std::list < DtSignatureModifierEvaluator * > | DtSignatureModifierEvalList |
| typedef std::map < DtSymbolString, DtSignatureModifierEvalList * > | DtSignatureModifierEvalMap |
| typedef tbb::concurrent_hash_map < unsigned int, double > | DtSensorSignatureCacheMap |
| typedef std::pair < DtPostInitializeFromParametersCallbackFcn, void * > | DtPostInitializeFromParametersInfo |
| typedef std::list < DtPostInitializeFromParametersInfo > | DtPostInitializeFromParametersCallbackList |
| Protected Types inherited from DtSimObjectStateRepository | |
| typedef DtCallbackList < DtSimObjectStateRepository * > | DtAboutToBeDeletedCallbacksList |
Protected Member Functions | |
| DtVrfObjectStateRepository () | |
| Default Constructor. Do not use. More... | |
| virtual void | initializeNextTaskId () |
| Initializes myNextTaskId to the next highest integer than the highest subtask Id currently maintained in myTaskStatusList. More... | |
| virtual void | setOrientationRelativeToParent () |
| If attached to a parent, and a terrain database is present, set orientation relative to parent. More... | |
| virtual DtAttachedTerrain * | createAttachedTerrain () |
| virtual void | createPartsFromDescriptors (const std::list< DtSimArtPartDescriptor * > &partDescriptors, const std::list< DtSimArtPartDescriptor * > &partDefaultsFromActuators) |
| Creates the articulated parts for an entity from articulated part descriptors. More... | |
| virtual void | postGetSelf () |
| Hook function called immediately following getSelf(). More... | |
| virtual double | baseSensorSignature (const DtSymbolString &sensorDomain) const |
| virtual double | modifySensorSignature (const DtSymbolString &sensorDomain, double baseSignature) const |
| Modifies the supplied baseSignature using the signatureModifiers for the specified sensor domain. More... | |
| virtual bool | initSignatureEvaluators () |
| Sets up all the sensor signature evaluators in mySignatureEvalMap based on the parameter entry for this entity. More... | |
| void | clearSignatureEvaluators () |
| Removes and deletes all signature evaluators. More... | |
| virtual bool | createObjectResourceManager () |
| Creates and sets myObjectResourceManager. More... | |
| virtual void | invokePostInitFromParamsCallbacks () |
| Invokes all callbacks registered via a call to addPostInitFromParamsCallback. More... | |
| virtual void | embarkedParentDeleted () |
| Called when the embarked parent is deleted. More... | |
| Protected Member Functions inherited from DtSimObjectStateRepository | |
| DtSimObjectStateRepository (const DtSimObjectStateRepository &orig, const DtString &rwName=DtString::nullString(), DtReaderWriterRegistry *parentRegistry=0) | |
| DtSimObjectStateRepository () | |
| Default Constructor; not implemented. More... | |
| Protected Member Functions inherited from DtReaderWriter | |
| virtual void | bindToRwAsVariable (const DtReaderWriter *rw) |
| Copies values from the specified DtReaderWriter. More... | |
Static Protected Member Functions | |
| static bool | visibilityFilter (const DtVrfObject *object, void *usr) |
| Used by isVisible to determine which objects can block visibility. More... | |
Description: This repository holds all information that is common to all the forms of all entity/aggregate/control objects within VR-Forces.
| typedef std::map<DtString, DtString> DtVrfObjectStateRepository::ExtendedData |
| typedef std::map<int, DtString> DtVrfObjectStateRepository::ExtendedLabels |
| typedef std::map<DtString, std::map<DtString, DtRwJoystickControl> > DtVrfObjectStateRepository::JoystickControls |
Controls by function group.
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
Default Constructor. Do not use.
| DtVrfObjectStateRepository::DtVrfObjectStateRepository | ( | DtVrfObject * | vrfObject, |
| const DtObjectType & | objectType, | ||
| DtVrfObjectParameters * | parameters, | ||
| const DtString & | rwName = DtString::nullString(), |
||
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
Constructor.
| DtVrfObjectStateRepository::DtVrfObjectStateRepository | ( | const DtVrfObjectStateRepository & | orig, |
| const DtString & | rwName = DtString::nullString(), |
||
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
Copy Constructor.
|
virtual |
Destructor.
| const DtVrfObjectStateRepository& DtVrfObjectStateRepository::operator= | ( | const DtVrfObjectStateRepository & | orig | ) |
Assignment Operator.
|
virtual |
Clone.
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfOverlayObjectStateRepository, DtVrfScenarioEventStateRepository, DtMissileStateRepository, DtGlobalEnvironmentStateRepository, DtGroundVehicleStateRepository, DtHumanStateRepository, DtBombStateRepository, DtMinefieldStateRepository, DtAirTurbulenceStateRepository, DtCloudLayerStateRepository, DtWeatherStateRepository, DtBallisticMissileStateRepository, DtCulturalFeatureStateRepository, DtWindCorridorStateRepository, DtRotaryWingEntityStateRepository, DtTacticalSmokeStateRepository, DtVrfAggregateStateRepository, and DtVrfMovingObjectStateRepository.
|
virtual |
returns DtSimObjectStateRepositoryType
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfOverlayObjectStateRepository, DtMissileStateRepository, DtVrfScenarioEventStateRepository, DtFixedWingEntityStateRepository, DtHumanStateRepository, DtSurfaceEntityStateRepository, DtVrfMovingObjectStateRepository, DtGlobalEnvironmentStateRepository, DtGroundVehicleStateRepository, DtBombStateRepository, DtMinefieldStateRepository, DtVrfAggregateStateRepository, DtCulturalFeatureStateRepository, DtSubsurfaceEntityStateRepository, DtAirTurbulenceStateRepository, DtBallisticMissileStateRepository, DtRotaryWingEntityStateRepository, DtCloudLayerStateRepository, DtWeatherStateRepository, DtWindCorridorStateRepository, and DtTacticalSmokeStateRepository.
|
virtual |
Returns DtSimObjectStateRepositorySubTypeVrfObject.
Reimplemented from DtSimObjectStateRepository.
|
virtual |
Returns DtVrfObjectStateRepositorySubTypeBase.
Reimplemented in DtVrfOverlayObjectStateRepository, and DtVrfMovingObjectStateRepository.
|
virtual |
Our 'virtual' constructor. Calls all the create<>() methods.
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtMissileStateRepository, DtSurfaceEntityStateRepository, DtFixedWingEntityStateRepository, DtGroundVehicleStateRepository, DtHumanStateRepository, DtMinefieldStateRepository, DtCulturalFeatureStateRepository, DtRotaryWingEntityStateRepository, and DtVrfAggregateStateRepository.
|
virtual |
Reimplemented in DtMissileStateRepository, DtSurfaceEntityStateRepository, DtRotaryWingEntityStateRepository, DtFixedWingEntityStateRepository, DtHumanStateRepository, DtVrfMovingObjectStateRepository, DtGroundVehicleStateRepository, DtBombStateRepository, DtMinefieldStateRepository, DtGlobalEnvironmentStateRepository, DtCulturalFeatureStateRepository, and DtTacticalSmokeStateRepository.
|
virtual |
Reimplemented in DtMissileStateRepository, DtSurfaceEntityStateRepository, DtRotaryWingEntityStateRepository, DtFixedWingEntityStateRepository, DtHumanStateRepository, DtBombStateRepository, DtVrfMovingObjectStateRepository, DtGroundVehicleStateRepository, DtMinefieldStateRepository, DtGlobalEnvironmentStateRepository, DtCulturalFeatureStateRepository, DtBallisticMissileStateRepository, and DtTacticalSmokeStateRepository.
|
virtual |
|
virtual |
Sets weather or not this object is concealed.
Call with care as not all objects support this and setting concealed could have effects of actually setting other appearance bits
Reimplemented in DtHumanStateRepository.
|
virtual |
If true movement is controlled by joystick so will not be able to be taskable as a subordinate.
|
virtual |
|
virtual |
User extension to state repository class.
Users can override the creation of this object to extend the state repository class at a base class level. Specify the kind of state repository user extension to create in the DtVrfObjectParameters object.
|
virtual |
Called on a setRestore command, sets destroyed to false and sets resources to initial (parameter file) levels.
Reimplemented in DtFixedWingEntityStateRepository, and DtRotaryWingEntityStateRepository.
|
virtual |
Callback that is invoked when the entity is about to be removed from the simulation.
|
virtual |
|
virtual |
|
virtual |
Call to update any cached values that are representative of state properties.
This is done for efficiency rather than having to look up state property values by name each time
Reimplemented in DtVrfOverlayObjectStateRepository.
|
virtual |
Extended data is a simply key/value pair of dictionary data. If there are quotes in the data, when written, they will be replaced by a marker such that they can be written/read by reader/writer
Reimplemented in DtVrfOverlayObjectStateRepository, DtMinefieldStateRepository, and DtVrfScenarioEventStateRepository.
|
virtual |
|
virtual |
Reimplemented in DtVrfScenarioEventStateRepository.
|
inline |
|
virtual |
Reimplemented in DtVrfOverlayObjectStateRepository, DtMinefieldStateRepository, and DtVrfScenarioEventStateRepository.
|
virtual |
Reimplemented in DtVrfOverlayObjectStateRepository, DtMinefieldStateRepository, and DtVrfScenarioEventStateRepository.
|
virtual |
If publishing parameter data also include that in the extended data map by name.
Sets the extended labels for a particular entity. Extended labels are an index/string pair. Index must be > 0. Any item at index 0 is ignored
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Available joystick controls
|
virtual |
|
virtual |
Get/Set the activity of the unit. Set in the extended data and in state properties (if exists)
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Returns a reference to our resource manager.
|
virtual |
|
virtual |
Gets a pointer to the resource named resourceName.
|
virtual |
|
virtual |
This does a clone of the resource and puts it on our main list, as well as adding the resource to the hash index.
|
virtual |
This removes and deletes the specified resource.
|
virtual |
Accessors for whether or not this object should use gameware navigation to move when in a navigation area. Default is true
|
virtual |
|
virtual |
Return true if attaching to this parent would cause a recursive attach.
|
virtual |
|
virtual |
Sector of responsibility.
Defined as a size in radians and a center angle in radians (with respect to the entity itself).
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Given the potential contacts, queries the engagement zone manager to see if that particular contact is hostile.
This will pass a location into the engagement zone manager and the perceived force.
|
virtual |
This call will presume the object is of force type other and is only used for the location.
|
virtual |
Given the location and the perceived force, iterate over all the engagement zones this object is monitoring in order to see if any one of them says this object is hostile.
Location is in local coordinates
|
virtual |
Returns true if this entity can fire upon the supplied location given the rules of engagement.
|
virtual |
|
virtual |
|
virtual |
Set/get whether or not this needs to send a request task needed message.
|
virtual |
|
virtual |
Set/get whether or not a given entity component currently executing a task.
|
virtual |
|
virtual |
|
virtual |
Returns true if entity is currently executing a task (at least one component must be tasked), false otherwise.
|
virtual |
Clear all the tasks with the specified component name.
|
virtual |
Clear the task with specified taskId and the specified component name.
|
virtual |
Set the current task message.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Get the first task that is of the particular task type, if being executed.
|
virtual |
Get the current task message.
If multiple task messages exist for a single component name, only the first is returned.
|
virtual |
Get the current task message for the specified component and task ID.
|
virtual |
true if the given attribute should be archived. Use static methods to add/remove keywords
|
virtual |
Top level call to write itself to file.
If write unspecified is true, will write entries that are unspecified, in the format (name <use-default>). Path is passed down to all DtReaderWriter members in its DtReaderWriterRegistry (collection of child DtReaderWriter nodes). If a given member in the registry is of type DtReaderWriterFile, and the path is specified with a non-NULL string, then the path prepended to the filename before writing the entry to file.
Reimplemented from DtReaderWriter.
|
virtual |
Positions list of ground interaction points on the terrain surface closest to the specified location.
Parent position and orientation of each ground interaction point must be set before calling this function. Returns false if there are no points to place. If there is no ground intersection, sets ground interaction point to its current position without ground, but at altitude zero. If the terrain is still being paged in at the time of this call for any of the requested points, terrainDataAvailable will be set to false and the points will artificially be placed at the object's current altitude. If it is not specified, this will be a blocking call (which should usually not be done from a tick function).
|
virtual |
reading in a scenario, want to make sure the support points get set up properly.
Base class is empty. If gravity aligned is true, does not clamp to terrain
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Set/get whether or not this entity is currently independently tasked (separately from its unit).
|
virtual |
|
virtual |
These callbacks are used to set myAttachedToStateRepository when this ent gets attached/detached to/from its parent.
Reimplemented from DtSimObjectStateRepository.
|
static |
|
virtual |
Reimplemented from DtSimObjectStateRepository.
|
static |
Creates a new state repository object, using the factory.
|
static |
|
static |
a DtSimObjectStateRepositoryFactory is allocated by the DtSimCreator, and this pointer is set.
The DtSimCreator deletes this pointer when it is deleted. This is done this way because we don't allow static initialization
|
static |
|
virtual |
If a clone has been created, this call will return the cloned entry as a const pointer, else returns the original pointer.
|
virtual |
Reimplemented in DtVrfAggregateStateRepository.
|
virtual |
|
virtual |
A modifiable local copy of parameters.
|
virtual |
Called by init().
Initializes myParameters with data from myParameterEntry.
|
virtual |
Get/Set the force type (team) of this entity.
Allows from 0 to 255. Only 1-4 are standard DIS/HLA
|
virtual |
|
virtual |
Override to create derived DtVrfAttachmentManager.
Reimplemented from DtSimObjectStateRepository.
| DtArticulatedPartStateRepository* DtVrfObjectStateRepository::addPart | ( | DtArtPartType | partType | ) |
These will be replaced by equivalents in the attachment manager.
| void DtVrfObjectStateRepository::removePart | ( | DtArtPartType | partType | ) |
| DtArticulatedPartStateRepository* DtVrfObjectStateRepository::part | ( | DtArtPartType | partType | ) |
| DtArticulatedPartStateRepository* DtVrfObjectStateRepository::findDescendantByType | ( | DtArtPartType | childType | ) |
|
virtual |
Encapsulates all the appearance related data and methods currently in the entity state repository.
The appearance bits are described in the DIS specification.
Reimplemented in DtHumanStateRepository.
|
virtual |
|
virtual |
|
virtual |
Gets/sets capabilities of entity This is treated as the DIS capabilities bit field, and does not necessarily change any behaviors of the object.
|
virtual |
|
virtual |
Destroyed status of entity (whether or not appearance()->damageState() is set to DtDamageDestroyed).
Reimplemented in DtHumanStateRepository.
|
virtual |
|
virtual |
Whether or not this item is invisible to sensors, line of sight, etc.
This will set a flag in the extended data
|
virtual |
|
virtual |
Whether or not the occupants of an entity are visually hidden.
This applies to the non-published occupants inserted into vehicles by the visual system, not to entities that have been embarked onto a vehicle.
|
virtual |
|
virtual |
Whether or not this item is invulnerable.
|
virtual |
|
virtual |
Whether or not this item is undetectable.
|
virtual |
|
virtual |
Block parachute flag. Can be used to prevent parachute animations.
|
virtual |
|
virtual |
Whether or not this item was set invisible by a set command.
This can become important when an object is embarked and its invisibility state is changed
|
virtual |
| DtReal DtVrfObjectStateRepository::healthPct | ( | ) | const |
.9 DtDamageNone
| void DtVrfObjectStateRepository::setHealthPct | ( | DtReal | pct | ) |
| bool DtVrfObjectStateRepository::firePowerKilled | ( | ) | const |
Convenience methods for setting setting entity's appearance bits in DtAppearance.
| void DtVrfObjectStateRepository::setFirePowerKilled | ( | const bool | firePowerKilled | ) |
| bool DtVrfObjectStateRepository::mobilityKilled | ( | ) | const |
| void DtVrfObjectStateRepository::setMobilityKilled | ( | const bool | mobilityKilled | ) |
| bool DtVrfObjectStateRepository::flaming | ( | ) | const |
| void DtVrfObjectStateRepository::setFlaming | ( | const bool | flaming | ) |
| bool DtVrfObjectStateRepository::smoking | ( | ) | const |
| void DtVrfObjectStateRepository::setSmoking | ( | const bool | smoking | ) |
| bool DtVrfObjectStateRepository::sensorsKilled | ( | ) | const |
Indicates that the entity's sensors have been killed.
| void DtVrfObjectStateRepository::setSensorsKilled | ( | bool | sensorsKilled | ) |
| bool DtVrfObjectStateRepository::isEntity | ( | ) | const |
| bool DtVrfObjectStateRepository::isLocal | ( | ) | const |
| bool DtVrfObjectStateRepository::isAggregate | ( | ) | const |
|
virtual |
|
virtual |
| void DtVrfObjectStateRepository::addSubordinate | ( | const DtVrfObject * | subordinateEntity | ) |
Adds an entity as a subordinate.
Subordinate entity's superior is set to be this entity. By default, the echelon organization is updated. Set the updateEchelonOrg flag to false when you do not want the echelon organization altered as a result of the operation (such as when restoring from file).
| void DtVrfObjectStateRepository::removeSubordinate | ( | const DtVrfObject * | subordinateEntity | ) |
Removes entity from our list of subordinates.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
This method is called each simulation frame, and may include any processing that needs to be done on this object state each tick.
Reimplemented in DtMinefieldStateRepository, DtCulturalFeatureStateRepository, DtMissileStateRepository, and DtVrfMovingObjectStateRepository.
|
virtual |
This version of tick checks to see if the time to tick has arrived (myNextTickTime <= exerciseClock()->approximateElapsedRealTime()).
If it has, it will then call tick(), and recalculate the next tick time
|
virtual |
specifies a minimum tick period (which can also be thought of as
|
virtual |
access the minimum tick period
|
virtual |
set the variance in the minimum tick time
|
virtual |
access the variance in the minimum tick period
|
virtual |
The next tick time is normally calculated internally.
setNextTickTime can be used to force a tick (set nextTickTime to exerciseClock()-> approximateElapsedRealTime())
|
virtual |
access the next tick time
|
virtual |
The next tick time is equal to mySimManager->exerciseClock()-> approximateElapsedRealTime() + myMinTickPeriod + a random # between -myMinTickPeriodVariance/2.
and +myMinTickPeriodVariance/2. If the exercise clock is paused, the variance is always set to zero to insure that the extra calls to DtFRand() don't prevent repeatability.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Euler angles with respect to the local (database) coordinate system, in radians.
|
virtual |
|
virtual |
This is provided for backward compatibility with setTarget capabilities.
Since these do not specify which of (potentially) multiple weapons to use, this call will retrieve the first.
|
virtual |
Processes a list of DtVectors, such as might come in a create or modify message.
Sets the object geometry, determines the bounding area or volume, and sets local and world position at the geometric center of the geometry.
|
virtual |
|
virtual |
This form allows processObjectGeometry()'s bounding volume calculations to be done on it's current geometry (by making a copy first).
This is needed when reading from an .oob file, because the object geometry's vertex lists have not been populated with the normal setLocalVertices() (or successive addLocalVertex() calls), but rather by reading them from the file.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Place entity at 'location', on the ground, keeping its current heading.
Since no terrain intersections are made at this level, dataAvailable is always set to true.
| Output | |
| dataAvailable | prevents the call from blocking due to terrain paging and will get a true value if the terrain intersections are successful. See DtVrfMovingObjectStateRepository::clampToGround for more information. Since no terrain intersections are made at this level, this flag is always set to true and is only used by DtVrfMovingObjectStateRepository and its subclasses. |
| requireAllData | prevents the call from changing the object if any terrain data is unavailable. Since no terrain intersections are made at this level, this flag is only used by DtVrfMovingObjectStateRepository and its subclasses. |
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Give entity the specified 'heading', but stay at its current location.
Since no terrain intersections are made at this level, dataAvailable is always set to true.
| Output | |
| dataAvailable | prevents the call from blocking due to terrain paging and will get a true value if the terrain intersections are successful. See DtVrfMovingObjectStateRepository::clampToGround for more information. Since no terrain intersections are made at this level, this flag is always set to true and is only used by DtVrfMovingObjectStateRepository and its subclasses. |
| requireAllData | prevents the call from changing the object if any terrain data is unavailable. Since no terrain intersections are made at this level, this flag is only used by DtVrfMovingObjectStateRepository and its subclasses. |
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Place entity at specified 'location' and 'heading' on the ground.
| Output | |
| dataAvailable | prevents the call from blocking due to terrain paging and will get a true value if the terrain intersections are successful. See DtVrfMovingObjectStateRepository::clampToGround for more information. Since no terrain intersections are made at this level, this flag is always set to true and is only used by DtVrfMovingObjectStateRepository and its subclasses. |
| requireAllData | prevents the call from changing the object if any terrain data is unavailable. Since no terrain intersections are made at this level, this flag is only used by DtVrfMovingObjectStateRepository and its subclasses. |
Reimplemented in DtVrfMovingObjectStateRepository, DtFixedWingEntityStateRepository, DtRotaryWingEntityStateRepository, and DtSubsurfaceEntityStateRepository.
|
virtual |
Will cause the object to be replaced at it's current position and clamped to the terrain.
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Note that this is not currently ever called.
Position is determined at the same time model vertices are, so this call is unnecessary.
Reimplemented from DtSimObjectStateRepository.
|
virtual |
|
virtual |
|
virtual |
Get the list of articulated parts specified in the component descriptor.
|
virtual |
This causes the art part tree to be created.
Each DtActuatorComponentDescriptor has an DtSimArtPartDescriptorList of parts which must be created.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Get/set/append to target priority list.
|
virtual |
|
virtual |
|
virtual |
Returns a positive value of priority if object is in the target priority list Returns DtPriorityLevelInvalid otherwise.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
The current non lethal damage type.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Dead-reckoning threshold parameters.
|
virtual |
|
virtual |
We hold the id of the object we are occupying.
Set in this base class since we could place a minefield inside of a strong point.
|
virtual |
|
virtual |
The echelon ID of this object, if it is an organized object.
This describes this objects location in the organization hierarchy.
|
virtual |
|
virtual |
|
virtual |
Indicates if this object's direct superior is a Force level object.
|
virtual |
|
virtual |
Override putData to set myParent using the organization manager before saving.
Reimplemented from DtReaderWriter.
|
virtual |
Override getSelf to handle mapping of old pre-2.0 oob files.
Maps the old variables for local and world position/orientation to the new object geometry and kinematic state members. Maps old boolean destroyed flag to new appearance bits.
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfMovingObjectStateRepository, DtWeatherStateRepository, DtVrfOverlayObjectStateRepository, DtRotaryWingEntityStateRepository, DtVrfAggregateStateRepository, DtVrfScenarioEventStateRepository, and DtGlobalEnvironmentStateRepository.
|
virtual |
Returns next unique task id for this entity.
|
virtual |
Functions for manipulating the set of pending subtask Ids for all components in the entity.
Users should not call these functions directly. Access them through the DtTaskControllerComponent instead. They are here for the purposes of saving/restoring the information to the order of battle file only. Given a subtask id search all current subtasks to see who the parent of this task is. Returns -1 if parent cannot be found
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
Returns the current subtask with the specified id.
Also returns the controller that is responsible. If NULL, no task was found
|
virtual |
Returns true if entity should automatically resume being tasked by superior upon completion of its current top-level task, false otherwise.
By default, this returns true.
|
virtual |
|
virtual |
|
virtual |
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfOverlayObjectStateRepository.
|
virtual |
Adds this state repository to the given parent's list of attached state repositories and updates myAttachedToRepository and myRootSimStateRepository.
The parent coordinate system is zeroed out, making this object relative to the parent instead of relative to the world.
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfOverlayObjectStateRepository, and DtCulturalFeatureStateRepository.
|
virtual |
Looks up the parent state repository using the given echelon ID and puts it in a call to attachToParent.
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtVrfOverlayObjectStateRepository, and DtFixedWingEntityStateRepository.
|
virtual |
Asks the sim manager to look up the object model for the requested database.
If there is a model then it adds it to our internal list. If the model already exists in the internal list, then it adds one to the reference count
This version will find the object in the object manager, and see what it's object type is to ask the object model manager in the sim manager for the object model
|
virtual |
Decreases reference count of terrain model by name of object.
If reference count is 0, it is removed from the list
| Dt3dBoundingVolume* DtVrfObjectStateRepository::boundingVolume | ( | ) | const |
Convenience method for accessing entity's bounding volume, stored in myObjectGeometry.
| DtVector DtVrfObjectStateRepository::localBoundingVolumeCenterPosition | ( | ) | const |
Gets the local coordinates of the bounding volume center.
Rotates the bounding volume offset from origin according to the entity's orientation, and adds the local position.
| DtReal DtVrfObjectStateRepository::currentSpeed | ( | ) | const |
Returns magnitude of relative velocity in state repository.
Previous to VRF 3.11, currentSpeed() returned only the forward/reverse component of the speed for some models. This is now returned by forwardSpeed().
| DtReal DtVrfObjectStateRepository::forwardSpeed | ( | ) | const |
|
virtual |
Returns the current total mass of the entity.
Reimplemented in DtVrfAggregateStateRepository.
| DtReal DtVrfObjectStateRepository::currentHeading | ( | ) | const |
Heading in radians. Calls down to DtVrfKinematicState for heading.
| void DtVrfObjectStateRepository::setCurrentHeading | ( | const DtReal | heading | ) |
|
virtual |
Accessor/mutator for engagement zones.
|
virtual |
|
virtual |
Add/remove callback function to be invoked immediately following execution of initializeFromParameters.
|
virtual |
|
virtual |
Restores state properties to their default settings.
|
virtual |
Initializes the list of state properties which should not be restored.
Reimplemented in DtVrfAggregateStateRepository.
|
virtual |
Accesses to the properties.
|
virtual |
|
virtual |
Access to static (parameter) properties.
|
virtual |
|
virtual |
check frozen state of fuel and munition levels
|
virtual |
|
protectedvirtual |
Initializes myNextTaskId to the next highest integer than the highest subtask Id currently maintained in myTaskStatusList.
|
protectedvirtual |
If attached to a parent, and a terrain database is present, set orientation relative to parent.
Reimplemented from DtSimObjectStateRepository.
|
protectedvirtual |
|
protectedvirtual |
Creates the articulated parts for an entity from articulated part descriptors.
|
protectedvirtual |
Hook function called immediately following getSelf().
Reimplemented from DtSimObjectStateRepository.
Reimplemented in DtWeatherStateRepository, DtHumanStateRepository, DtVrfAggregateStateRepository, and DtCloudLayerStateRepository.
|
virtual |
Adds, removes and returns items in the range item list.
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Reimplemented in DtVrfMovingObjectStateRepository.
|
virtual |
Reimplemented in DtVrfMovingObjectStateRepository.
| const DtRangeItems& DtVrfObjectStateRepository::rangeItems | ( | ) | const |
| DtRangeItems& DtVrfObjectStateRepository::rangeItems | ( | ) |
|
virtual |
| DtAttachedTerrain* DtVrfObjectStateRepository::terrainAttachedTo | ( | ) | const |
|
virtual |
|
virtual |
Returns the current absolute signature for this object in the specified sensor domain.
If the domain is not found, 0 is returned. Uses the myMutableSensorSignatureCache to only calculate the signature once per tick.
Reimplemented in DtVrfOverlayObjectStateRepository, and DtVrfScenarioEventStateRepository.
|
virtual |
|
virtual |
Situational awareness of this object.
If this object is aware of other objects in the scenario, this list will contain the known objects, and the properties of the objects which are known. The object must have a controller which fills in this list in order for there to be data in the object contact list.
|
virtual |
|
virtual |
Takes the extended data string, and, if xml, will pretty print and remove the quotes from the created reader/writer else just return the string.
Extended data that is not archived that is currently in the extended data list.
|
virtual |
Append extended data to extended data map.
|
virtual |
If this is set, and the system component flag for blocking fire of other laser weapons when this is live is also true, other laser weapons on this system will not have permission to fire.
|
virtual |
|
protectedvirtual |
|
protectedvirtual |
Modifies the supplied baseSignature using the signatureModifiers for the specified sensor domain.
|
protectedvirtual |
Sets up all the sensor signature evaluators in mySignatureEvalMap based on the parameter entry for this entity.
|
protected |
Removes and deletes all signature evaluators.
Non-virtual because it is called from the destructor.
|
protectedvirtual |
Creates and sets myObjectResourceManager.
|
protectedvirtual |
Invokes all callbacks registered via a call to addPostInitFromParamsCallback.
|
protectedvirtual |
Called when the embarked parent is deleted.
Reimplemented in DtHumanStateRepository.
|
static |
Handles state changes for the subtask status list.
|
virtual |
|
static |
|
static |
|
static |
|
virtual |
Reimplemented from DtSimObjectStateRepository.
|
virtual |
Reimplemented from DtSimObjectStateRepository.
|
staticprotected |
Used by isVisible to determine which objects can block visibility.
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
each of these has_a DtSubObjectManager
|
protected |
if this object is a subordinate, this is used to write out the name of the parent
|
protected |
|
protected |
Used only to read in scenarios from pre VRF 3.11.
|
protected |
|
protected |
|
protected |
Under fire parameters.
|
protected |
|
protected |
Systems which have had their default enable state changed to disabled.
|
protected |
The current enumerated level of suppression, derived from the value.
|
protected |
The current non lethal damage type (sick, faint, etc.).
Default value is empty string
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
This is created in createParts, and kept around to make setup of the network repository easier.
|
protected |
Shared list of visibility blocking objects.
|
protected |
For backward compatibility with pre-2.0 VR-Forces oob files Registered as read-only, so they do not get written out to new oob files.
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
myDesignator is used for reading and writing only and is not valid at runtime.
Check the designator of the echelonId for the current designator.
|
protected |
|
staticprotected |
|
protected |
This resource manager is used for all the top-level resource only.
Component Systems now contain resources, so most components will interact with these resource managers instead.
|
protected |
|
protected |
|
protected |
These really apply to a single weapon, and should be part of a weapon controller/actuator suite of some sort.
|
protected |
Moved here from the DtLocalTaskManager class.
|
protected |
Contains the myTasked and myCurrentTaskMsg members from the DtTaskControllerComponent class.
It is a list because there may be a number of DtTaskControllerComponents for a given entity.
|
protected |
|
protected |
The next available ID that can be assigned to a task for this entity.
|
protected |
|
protected |
Set to true when the entity is embarked on a destroyed parent so they do not become destroyed.
If the parent is then restored to a non-destroyed state while the entity is embarked, this will then be set to false
|
protected |
Whether or not this object can navigate in navigation areas. Default is true.
|
protected |
Target Priority List.
|
protected |
For performance and memory usage reasons, the copy of the parameter entry that used to be made when creating a state repository is no longer made when the state repository is initialized.
The myParameterEntry will point to the original parameter entry in the parameter database and should only be accessed by the const DtVrfObjectParameters* parameterEntry() const method.
If you wish to get a copy of the parameter entry for modification, you should not access the myParameters entry directly, as it will be NULL on access until a copy is created. This copy will be created by calling the non const parameters() method to return the myParameters entry. If a copy does not exist, one will be created by calling the createParameters() method (at which point you can set the myParameters entry to your new parameter instance – this should be the only time you access the myParameters member variable directly). The parameters will then be initialized and then setupParameterInheritance() will be called.
If you try and access the myParameters variable directly, the program might crash at runtime due to the fact that it might be NULL, so, your code should be written (or modified) to only call the member function that will return the information you want: const DtVrfObjectParameters* parameterEntry() const will return a const pointer to the original parameter entry const DtVrfObjectParameters* parameters() const will also return a const pointer to the original parameter entry. This member function is provided for backwards compatibility only and could be depreciated in future versions DtVrfObjectParamters* parameters() will return a mutable copy of the original parameter entry. Changes to this entry will not effect the original pointer This is a pointer into the parameter database, and what it points to should not be modified. If you need to modify the entry, call the non-const accessor which will return a clone of the parameter entry that can be modified.
|
protected |
this is the parameter entry that this repository created.
It starts with values inherited from myParametersEntry
|
protected |
For variable tick rate support.
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
Map which holds a set of lists of signature modifier evaluators indexed by sensor domain.
Initialized by init from the parameter entry, and used by sensorSignature().
|
mutableprotected |
Maintains the current sensor signature (indexed by sensor domain) for this entity.
Calculated on first request, then used from the cache. The cache is cleared out each tick.
|
protected |
The situational awareness of this object.
List of other objects that this object is currently aware of.
|
protected |
|
protected |
Range item information.
Not used from ope but rather set by controllers that have range items that want to be published on the network
|
protected |
Additional properties that are part of this state repository.
If also present in the FOM will be published on the network
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
|
protected |
The list of state properties that should not be updated by restoreStateProperties.
|
mutableprotected |
|
protected |
Map of available joystick controls for this particular entity.
|
protected |
If true movement is controlled by joystick so will not be able to be taskable as a subordinate.
|
staticprotected |
|
protected |
List of callbacks for when this entity is restores.
|
protected |
