VR-Forces 4.8 Class Documentation
|
DtMissileControllerComponent is a controller that contains all of the functionality common to all missile controllers. More...
Public Member Functions | |
| DtMissileControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtMissileControllerComponent () |
| destructor More... | |
| virtual bool | init () |
| Overridden to initialze myMissileState and call calculateTargetErrorOffset. More... | |
| virtual const char * | type () const |
| Returns a string identifies the class type of component. More... | |
| virtual double | distanceToTarget () const |
| virtual double | approximateThrust (double speed) const |
| We use this to approximate the correct thrust for a given speed. More... | |
| virtual void | calculateSteering (const DtVector &relativeVelocity, const DtVector &localPosition, const DtVector &targetVelocity, const DtVector &targetPoint, double &maneuverAccelXOut, double &maneuverAccelYOut, double &maneuverAccelZOut)=0 |
| Calculates the maneuvering thrust necessary to aim at the target. More... | |
| virtual void | calculateSteeringToPoint (const DtVector &relativeVelocity, const DtVector &localPosition, const DtVector &targetPoint, double &maneuverAccelXOut, double &maneuverAccelYOut, double &maneuverAccelZOut) |
| Uses a simple algorithm to aim the missile at a static or slowly-moving target point. More... | |
| virtual void | calculateSteeringUsingPropNav (const DtVector &relativeVelocity, const DtVector &localPosition, const DtVector &targetVelocity, const DtVector &targetPoint, double &maneuverAccelXOut, double &maneuverAccelYOut, double &maneuverAccelZOut) |
| Uses proportional navigation to steer at an entity that may be moving at a high velocity. More... | |
| virtual bool | createMissileControlPortGroup () |
| These are called in init to create the ports used to communicate with the actuator. More... | |
| virtual bool | createThrustPort () |
| virtual bool | createManeuverAccelXPort () |
| virtual bool | createManeuverAccelYPort () |
| virtual bool | createManeuverAccelZPort () |
| virtual bool | createSelfDestructPort () |
| virtual DtConstrainedAnalogOutputPort * | thrustPort () |
| virtual DtConstrainedAnalogOutputPort * | maneuverAccelXPort () |
| virtual DtConstrainedAnalogOutputPort * | maneuverAccelYPort () |
| virtual DtConstrainedAnalogOutputPort * | maneuverAccelZPort () |
| virtual DtBooleanOutputPort * | selfDestructPort () |
 Public Member Functions inherited from DtSingleTaskControllerComponent | |
| DtSingleTaskControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *compDesc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtSingleTaskControllerComponent () |
| destructor More... | |
| virtual void | postTick () |
| Override to check if we're tasked and we want to give up (only performs the check if we're in play mode (dT() > 0)). More... | |
| virtual bool | beginProcessingTask (const DtTaskMessage &task, DtSimTaskStatePtr taskState) |
| Called by the task manager when this controller should start executing the specified task. More... | |
| virtual void | taskNotify (const DtSimTask &task) |
| This is called to let us know when some other component receives a task In the case of this component, we don't care what the task actually is. More... | |
| virtual void | taskComplete (bool success=true) |
| If we are currently tasked, this will cause us to notify the entity that we're done and delete the task. More... | |
| virtual void | clearTask () |
| If component is currently tasked, calls clearPendingSubtasks(), sets the tasked flag to false, and calls clearCurrentTaskMesage() to clear out the current task message. More... | |
| virtual void | suspendTask () |
| This method is called when the currently running task is being suspended. More... | |
| virtual int | sendSubtask (DtSimTask &task) |
| Sends subtask to ourself. More... | |
| virtual void | clearSubtask (int subtaskId) |
| Clears subtask with the given subtaskId (subtaskId is returned sendSubtask()). More... | |
| virtual void | addPendingSubtaskId (int subtaskId) |
| Adds given subtask Id to list of pending subtasks. More... | |
| virtual bool | findPendingSubtaskId (int subtaskId) |
| Checks to see if given subtaskId exists in our list of pending subtasks. More... | |
| virtual bool | isSubtasked () const |
| Returns true if this controller is currently subtasked. More... | |
| virtual void | removePendingSubtaskId (int subtaskId) |
| Removes pending subtask from list of subtasks for this component. More... | |
| virtual void | removeAllPendingSubtaskIds () |
| Clear all pending subtasks from our list of subtasks. More... | |
| virtual std::vector< int > | currentPendingSubstaskIds () const |
| Returns the list of all currently pending subtask ids for this controller. More... | |
| virtual void | clearCurrentTaskMessage () |
| Returns the current subtask with the specified id. More... | |
| virtual DtTaskMessage * | currentTaskMessage () const |
| Get a pointer to the message that was used to task this entity. More... | |
| virtual DtSimTaskStatePtr | currentTaskState () const |
| virtual bool | decideToGiveUpTask () const |
| This function is used to determine if the controller should give up trying to execute the current task. More... | |
| virtual void | giveUpTask () |
| Called when controller is tasked and decideToGiveUp() returns true. More... | |
| virtual bool | taskActive (int taskId) const |
| virtual bool | clearTopLevelTasks () |
| If this controller has any top level tasks (not subtasks), they are cleared. More... | |
| virtual void | clearConflictingTopLevelTasks (const DtSimTaskMessageType &conflictType) |
| Clears any top level tasks on this controller that conflict with the conflict task type. More... | |
| virtual void | clearTasksByType (const DtSimTaskMessageType &taskType) |
| Clears any tasks of the specified type running in this controller. More... | |
| virtual void | clearTaskById (int taskId) |
| Clears any task of the specified ID running in this controller. More... | |
| virtual DtSuspendedTaskInfo * | suspendTaskById (int taskId) |
| virtual DtSuspendedTaskInfo * | suspendSubtaskById (int taskId, int subtaskId) |
| virtual std::list < DtTaskMessage * > | currentTaskMessages () const |
| virtual DtTaskWithTaskStateListPtr | topLevelTasks () const |
| virtual void | disable () |
| Overridden to allow tasks controllers that can be disabled to call task complete. More... | |
| Public Member Functions inherited from DtTaskControllerComponent | |
| DtTaskControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *compDesc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtTaskControllerComponent () |
| destructor More... | |
| virtual bool | showCurrentTaskInGui () const |
| virtual void | setRadio (DtSimRadio *radio) |
| Calls registerTaskMsgCallbacks. More... | |
| virtual void | registerTaskMsgCallbacks () |
| virtual void | addTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtTaskMessageCallbackFcn fcn, void *usr) |
| Adds a new function for processing the specified task type. More... | |
| virtual void | addTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtMessageCallbackFcn fcn, void *usr) |
| Deprecated form of addTaskProcessorCallback. More... | |
| virtual void | removeTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtMessageCallbackFcn fcn, void *usr) |
| Undoes anything done by addTaskProcessorCallback(). More... | |
| virtual void | removeTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtTaskMessageCallbackFcn fcn, void *usr) |
| Deprecated form of removeTaskProcessorCallback. More... | |
| virtual void | enable () |
| Overridden to call registerTaskMsgCallbacks(). More... | |
| virtual void | sendTaskCanceled (DtTaskMessage *taskMsg) |
| Sends the task canceled report for the specified message. More... | |
| virtual bool | taskVisualizationsActive () const |
| Returns true if task visualizations are currently active for this component. More... | |
| virtual void | setTasked (bool tasked) |
| The current tasked state of this controller. More... | |
| virtual bool | tasked () const |
| Public Member Functions inherited from DtControllerComponent | |
| DtControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtControllerComponent () |
| destructor More... | |
| virtual DtSimRadio * | radio () |
| The radio this component is listening to. More... | |
| Public Member Functions inherited from DtSimComponent | |
| DtSimComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtSimComponent () |
| destructor More... | |
| virtual void | setParentSystem (DtComponentSystem *system) |
| Sets the parent system of this component. More... | |
| DtComponentSystem * | parentSystem () const |
| virtual void | registerAttributeFunctions () |
| Called to register functions that provide system attribute values. More... | |
| virtual void | preFirstTickInit () |
| This function can be overridden to initialize a component before it is ticked for the first time. More... | |
| virtual void | tick () |
| This gives the thread of control to the component. More... | |
| virtual void | timedTick () |
| This version of tick checks to see if the time to tick has arrived. More... | |
| virtual void | setMinTickPeriod (double minTickPeriod) |
| specifies a minimum tick period (which can also be thought of as More... | |
| virtual double | minTickPeriod () const |
| access the minimum tick period More... | |
| virtual void | setMinTickPeriodVariance (double minTickPeriodVariance) |
| set the variance in the minimum tick time More... | |
| virtual double | minTickPeriodVariance () const |
| access the variance in the minimum tick period More... | |
| virtual void | setNextTickTime (double nextTickTime) |
| The next tick time is normally calculated internally. More... | |
| virtual double | nextTickTime () const |
| access the next tick time More... | |
| virtual double | calculateNextTickTime () const |
| The next tick time is equal to mySimManager->exerciseClock()-> approximateElapsedRealTime() + myMinTickPeriod + a random # between -myMinTickPeriodVariance/2. More... | |
| virtual double | calculateFirstTickTime () const |
| Returns the first time value that the component should tick at. More... | |
| virtual void | setEntity (DtVrfObject *entity) |
| The entity's state repository is the place that actuator components make updates and other components look to see our current state. More... | |
| virtual DtSimComponent * | nextComponent () |
| List management functions. More... | |
| virtual DtSimComponent * | prevComponent () |
| virtual void | setListItem (DtListItem *item) |
| Used by DtComponentList. More... | |
| virtual DtListItem * | listItem () |
| virtual void | putData (std::string &fp, int indentLevel=0) |
| putData writes our type, which is provided by the virtual type accessor of the deriving class. More... | |
| virtual DtlObjPtr | getData (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths, const DtVariableBindingsList &variableBindings) |
| getData is just used to get us past the type in the data stream, since it's not actual stored. More... | |
| virtual void | addInputPort (DtInputPort *port) |
| Adds this input port to the components input port list so that other components can look it up and attach to it. More... | |
| virtual void | removeInputPort (DtInputPort *port) |
| virtual DtInputPort * | lookupInputPort (const DtString &portName) |
| Returns a pointer to the input port registered on this component with the specified name. More... | |
| virtual DtList | inputPortList () const |
| Returns the list of DtInputPorts registered on this component. More... | |
| virtual void | addOutputPort (DtOutputPort *port) |
| Adds this output port to the components output port list so that other components can look it up and attach to it. More... | |
| virtual void | removeOutputPort (DtOutputPort *port) |
| virtual DtOutputPort * | lookupOutputPort (const DtString &portName) |
| Returns a pointer to the output port registered on this component with the specified name. More... | |
| virtual DtList | outputPortList () const |
| Returns the list of DtOutputPorts registered on this component. More... | |
| virtual void | addInputPortGroup (DtInputPortGroup *group) |
| Adds this input port to the components input port list so that other components can look it up and attach to it. More... | |
| virtual void | removeInputPortGroup (DtInputPortGroup *group) |
| virtual DtInputPortGroup * | lookupInputPortGroup (const DtString &groupName) |
| Returns a pointer the input port group registered on this component with the specified name. More... | |
| virtual DtList | inputPortGroupList () const |
| Returns the list of DtInputPortGroups registered on this component. More... | |
| virtual void | addOutputPortGroup (DtOutputPortGroup *group) |
| Adds this output port group to the components output port group list so that other components can look it up and attach to it. More... | |
| virtual void | removeOutputPortGroup (DtOutputPortGroup *group) |
| virtual DtOutputPortGroup * | lookupOutputPortGroup (const DtString &groupName) |
| Returns a pointer the output port group registered on this component with the specified name. More... | |
| virtual DtList | outputPortGroupList () const |
| Returns the list of DtOutputPortGroups registered on this component. More... | |
| virtual int | priority () const |
| Return the current connection priority for this component. More... | |
| virtual void | setPriority (int priority) |
| Sets a new connection priority for this component, and changes all current outgoing connections from this component to the new value. More... | |
| double | dT () const |
| This is the delta-t for this component, which may or may not be the same as the exerciseClock dT. More... | |
| virtual void | setDT (double deltaT) |
| Note that while dT is calculated internally, this makes it possible to 'lie' to the component about dT if necessary. More... | |
| virtual void | setComponentDescriptor (DtComponentDescriptor *componentDescriptor) |
| The component descriptor specified in the order of battle file or parameter file that was used to create this component. More... | |
| virtual const DtComponentDescriptor * | componentDescriptor () const |
| virtual bool | tickWhileDestroyed () const |
| If the component returns true here, it will be ticked regardless of the destroyed state of the host entity. More... | |
| DtVrfProcessStateRepositoryManager * | psrManager () |
| virtual const DtSymbolString & | componentFullName () const |
| DtPhysicalWorld * | physicalWorld () |
| Gets the physical world that this component's entity exists in. More... | |
| const DtPhysicalWorld * | physicalWorld () const |
| DtAttachedTerrain * | terrainAttachedTo () |
| Gets the terrain that this component's entity is attached to, if any. More... | |
| const DtAttachedTerrain * | terrainAttachedTo () const |
| DtVrfObject * | entity () |
| Gets the entity. More... | |
| const DtVrfObject * | entity () const |
| const DtVrfObject * | const_entity () const |
| You would want to use this call if you could be either a const or non-const entity, and you wanted to be sure you only had const access. More... | |
| DtSimManager * | simManager () |
| Gets the sim manager. More... | |
| const DtSimManager * | simManager () const |
| const Coordinate_System * | coordinateSystem () const |
| Gets the coordinate system, as it should always exist if the physical world is in a valid state! More... | |
| DtVrfObjectStateRepository * | localStateRepository () |
| Gets the local state repository. More... | |
| const DtVrfObjectStateRepository * | localStateRepository () const |
| const DtVrfObjectStateRepository * | const_localStateRepository () const |
| You would want to use this call if you could be either a const or non-const local state repository, and you wanted to be sure you only had const access. More... | |
| virtual DtTaskVisualizationMap & | taskVisualizations () |
| Returns the list of task visualizations for this component. More... | |
| virtual bool | taskVisualizationsEnabled () const |
| Returns true if task visualizations are enabled for this component. More... | |
| virtual bool | isThreadSafe () const |
| Returns true if this component is marked as being thread safe. More... | |
| virtual void | addVRLinkDeferredJob (const boost::function< void()> &callback) |
| Adds a deferred job to the VRLink job queue in the DtParallelTickManager, but only if this component is marked at thread safe. More... | |
| virtual bool | isEnabled () |
| virtual void | setIsEnabled (bool yesNo) |
| virtual DtOutputStream & | objectConsoleDebug (const DtString &channel="") const |
| virtual DtOutputStream & | objectConsoleVerbose (const DtString &channel="") const |
| virtual DtOutputStream & | objectConsoleInfo (const DtString &channel="") const |
| virtual DtOutputStream & | objectConsoleWarn (const DtString &channel="") const |
| virtual DtOutputStream & | objectConsoleError (const DtString &channel="") const |
| virtual DtSimResourceManager & | resourceManager () |
| virtual const DtSimResourceManager & | resourceManager () const |
| Public Member Functions inherited from DtReaderWriter | |
| DtReaderWriter () | |
| default constructor More... | |
| DtReaderWriter (const DtString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| real constructor Setting the readonly flag prevents object from writing itself to the stream. More... | |
| DtReaderWriter (const DtSymbolString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| DtReaderWriter (const DtString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| pseudo-copy constructor More... | |
| DtReaderWriter (const DtSymbolString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| DtReaderWriter (const DtReaderWriter &, DtReaderWriterRegistry *parentRegistry=NULL) | |
| copy constructor More... | |
| const DtReaderWriter & | operator= (const DtReaderWriter &orig) |
| assignment operator More... | |
| bool | operator== (const DtReaderWriter &) const |
| Equivalence operator. More... | |
| bool | operator!= (const DtReaderWriter &rhs) |
| virtual | ~DtReaderWriter () |
| destructor More... | |
| virtual void | putSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| Top level call to write itself to file. More... | |
| virtual void | postPutSelf () |
| Called after either version of put self (file or environment). Default is no-op. More... | |
| virtual void | prePutSelf () |
| Called before either version of put self (file or environment). Default is no-op. More... | |
| virtual void | getSelf (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &variableBindings=nullVariableReference()) |
| Top level to read itself from an input stream. More... | |
| virtual void | postGetSelf () |
| Called after either version of getSelf (mtl or environment). Default is no-op. More... | |
| virtual void | preGetSelf () |
| Called before either version of get self (file or environment). Default is no-op. More... | |
| virtual void | writeSelf (std::string &fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| Called from putSelf, calls myRegistry.putSelf which in turn calls putSelf on each reader/writer in the registry. More... | |
| virtual DtSymbolString | name () const |
| Accessor for name of this readable/writable object. More... | |
| virtual void | addAlias (const DtSymbolString &alias) |
| Add an alias as an alternative name for this object. More... | |
| virtual void | addAlias (const DtString &alias) |
| virtual bool | hasAlias (const DtSymbolString &alias) |
| virtual const aliasContainer & | aliases () const |
| virtual void | setReadonly (bool flag) |
| Set read-only flag. More... | |
| bool | isReadonly () const |
| virtual void | reset () |
| For those reader/writer items that support it, resets the reader/writer value to original state Default is no-op. More... | |
| virtual int | alignment () const |
| For those items that are sent over the network via HLA, this will give the network alignment. More... | |
| virtual bool | variableIsBound () const |
| virtual void | unbindVariable () |
| Sets the myVariableIsBound flag to false. More... | |
| virtual void | setName (const DtString &) |
| Set the name of the object. More... | |
| virtual const char * | readerWriterType () const |
| Used to supply a string type that this reader writer type is. More... | |
| virtual const char * | xmlType () const |
| virtual DtString | prettyPrint () const |
| Routine to return a human readable form of the reader/writer variable. More... | |
| std::string | debugText () const |
| virtual void | bindVariables (DtVariableBindingsList variableBindings) |
| Runs a variable binding pass on this reader writer and any of its children. More... | |
| virtual std::list < DtVariableNameType > | unboundVariables () const |
| bool | invalid () const |
| virtual bool | hasChild (const DtReaderWriter *p) const |
| Returns true if this variable has a child p in it's chain. More... | |
| virtual bool | hasVariableReference () const |
| Returns true if this item or any item in the registry (recursive) is a variable reference. More... | |
| virtual void | bindLocalVariables (const DtVariableBindingsList &variableBindings) |
| Checks to see if this RW object is a variable reference that can be bound using the provided bindings. More... | |
| virtual void | recordUpdateTime () const |
| Can be implemented in subclasses to stamp the time when updated. More... | |
| virtual bool | wasUpdatedSince (DtTime t) const |
| Can be implemented in subclasses to return true if an update occurred after the specified time. More... | |
| virtual bool | changedSinceLastChecked () |
| Returns true if this objects value has changed since the last time this function was called. More... | |
| virtual bool | peekChangedSinceLastChecked () const |
| Returns the value that changedSinceLastChecked would return but does not reset the internal flag. More... | |
| virtual void | setValueSpecified (bool specified, bool recurse=false) |
| The specified flags are used for optional values. More... | |
| virtual bool | valueSpecified () const |
| virtual bool | isVariableReference () const |
| Specifies whether or not this reader writer is really a variable that is specified elsewhere. More... | |
| virtual void | setIsVariableReference (bool value) |
| virtual void | clearAllVariableReferenceFlags () |
| Clears out all variable reference flags from all readerwriter items in registry recursively. More... | |
| virtual DtSymbolString | variableName () const |
| The variable name, if this object is a variable reference. More... | |
| virtual void | setVariableName (const DtSymbolString variableName) |
| virtual const DtReaderWriter * | defaultRWValue () const |
| The default value to use if the reader/writer object is a variable and that variable is not specified. More... | |
| virtual DtReaderWriter * | defaultRWValue () |
| virtual void | setDefaultRWValue (DtReaderWriter *) |
| Previous default value, if exists, will be removed and replaced with a clone of the supplied variable. More... | |
| virtual bool | checkAndSetDefaultRWValue (DtlObjPtr args, const DtReaderWriter::SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &variableBindings=nullVariableReference()) |
| Give the stream, if the stream contains a default value then set it here. More... | |
| const DtReaderWriterRegistry & | registry () const |
| Collection of child DtReaderWriter nodes owned by this object. More... | |
| DtReaderWriterRegistry & | registry () |
| virtual DtPropertyInterface * | property () |
| virtual const DtPropertyInterface * | property () const |
| virtual DtString | toXml () const |
| virtual DtRwVariableBindings * | generateVariableBindings () const |
| Iterates over the registry (recursively) and returns a variable bindings object that contains all the variables that are contained in this read/writer class. More... | |
| virtual bool | toXml (const DtFilename &) const |
| Writes contents of xml result to the given filename. More... | |
| virtual bool | fromXml (const DtString &) |
| Restores object from given xml string. Returns true if valid. More... | |
| virtual bool | fromXmlFile (const DtFilename &) |
| Restores object from given xml file. More... | |
| virtual void | putSelf (DtEnvironmentSP, DtEnvValueSP parent) const |
| virtual void | putData (DtEnvironmentSP, DtEnvValueSP value) const |
| Override to add attributes of actual data. More... | |
| virtual void | putVariableReference (DtEnvironmentSP, DtEnvValueSP value) const |
| Called when the item is a variable reference. More... | |
| virtual void | getSelf (const DtEnvironmentSP, const DtEnvValueSP root, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| virtual void | getData (const DtEnvironmentSP, const DtEnvValueSP, const SearchPaths &searchPaths=SearchPaths(), const DtVariableBindingsList &bindings=DtVariableBindingsList()) |
| Gets data from the environment value. More... | |
| virtual void | unrecognizedItem (const DtEnvironmentSP env, const DtEnvValueSP root, const SearchPaths &searchPaths, const DtVariableBindingsList &varBindings) |
| Called when the xml reader tries to parse an unknown reader/writer item. Default is a no-op. More... | |
| virtual void | getVariableReference (DtEnvironmentSP, DtEnvValueSP value) |
| Called when the item is a variable reference. More... | |
Protected Member Functions | |
| virtual bool | createPortGroups () |
| Overridden to call createMissileControlPortGroup. More... | |
| virtual bool | createPorts () |
| Overridden to create missile ports. More... | |
| virtual void | calculateTargetErrorOffset () |
| Calculate offset (in target body coordinates) to be applied when steering toward the target. More... | |
| virtual void | lookupAndCacheProcessSR () |
| This function looks up a process state repository in the process state repository manager by name, and caches a pointer to it in myProcessState. More... | |
| virtual bool | postAddComponentsInit () |
| Calls lookupAndCacheProcessSR(), to look up our process state repository after all of the components have been created and loaded. More... | |
| virtual void | addRangeItems () |
| Adds all items that have a range to the object state repository. More... | |
| DtMissileControllerComponent () | |
| default constructor; not implemented More... | |
| DtMissileControllerComponent (const DtMissileControllerComponent &orig) | |
| copy constructor; not implemented More... | |
| const DtMissileControllerComponent & | operator= (const DtMissileControllerComponent &orig) |
| assignment operator; not implemented More... | |
| Protected Member Functions inherited from DtSingleTaskControllerComponent | |
| virtual void | clearPendingSubtasks () |
| Iterates over collection of all pending subtasks for this controller, and calls clearSubtask() for each subtask type. More... | |
| virtual void | clearSubtasksByType (const DtSimTaskMessageType &taskType) |
| Clear all subtasks of a given type. More... | |
| virtual void | cleanupInactiveSubtaskStatus () |
| Clears out subtask status entries that are either completed or canceled which were started by this controller. More... | |
| Protected Member Functions inherited from DtTaskControllerComponent | |
| virtual void | suspendSubtasksOfTask (int taskId, DtSuspendedTaskInfo *suspendInfo) |
| Suspends all running subtasks of taskId, and puts the suspend info for each of them as subtasks into the provided suspendInfo. More... | |
| virtual void | suspendSubtaskOfTask (int taskId, int subtaskId, DtSuspendedTaskInfo *suspendInfo) |
| Suspends a single running subtasks of taskId, and puts the suspend info into the provided suspendInfo. More... | |
| virtual DtSimTaskMessageType | remapScriptId (const DtSimTaskMessageType &) const |
| In case this is aliased, return the actual script id. More... | |
| Protected Member Functions inherited from DtControllerComponent | |
| DtControllerComponent () | |
| default constructor More... | |
| DtControllerComponent (const DtControllerComponent &orig) | |
| copy constructor More... | |
| const DtControllerComponent & | operator= (const DtControllerComponent &orig) |
| assignment operator More... | |
| virtual void | onRestore () |
| Override to iterate over the descriptor to see if there are any targetting control tables. More... | |
| virtual void | initializeTargetingControlTableFromDescriptor (const DtReaderWriter *) |
| Protected Member Functions inherited from DtSimComponent | |
| virtual double | computeCurrentTime () |
| Compute current time and myDT. More... | |
| bool | testInvariant () const |
| DtVrfProcessStateRepository * | createComponentPsr (const DtString &defaultPsrType, const DtString &defaultPsrName, bool useDescriptorParams=true) |
| Creates a PSR for this component and registers it with the PSR manager. More... | |
| virtual void | updateTaskVisualizations () |
| Called to update task visualizations after every tick. More... | |
| virtual void | destroyTaskVisualizations () |
| Destroys all task visualizations for this component. More... | |
| virtual void | destroyTaskVisualization (const DtString &name) |
| Destroys an existing task visualization. More... | |
| virtual DtPointTaskVisualizationPtr | pointTaskVisualization (const DtString &name) |
| Finds an existing or creates a new point task visualization with the given name. More... | |
| virtual DtLineTaskVisualizationPtr | lineTaskVisualization (const DtString &name) |
| Finds an existing or creates a new line task visualization with the given name. More... | |
| virtual DtAreaTaskVisualizationPtr | areaTaskVisualization (const DtString &name) |
| Finds an existing or creates a new area task visualization with the given name. More... | |
| virtual DtTextTaskVisualizationPtr | textTaskVisualization (const DtString &name) |
| Finds an existing or creates a new text task visualization with the given name. More... | |
| double | calculateNextTaskVisTickTime () const |
| Determines the next time the task visualizations should be ticked. More... | |
| Protected Member Functions inherited from DtReaderWriter | |
| virtual void | bindToRwAsVariable (const DtReaderWriter *rw) |
| Copies values from the specified DtReaderWriter. More... | |
| Protected Member Functions inherited from DtObjectDebugger< DtSimComponent > | |
| DtObjectDebugger () | |
| DtObjectDebugger (const DtObjectDebugger &) | |
| ~DtObjectDebugger () | |
Protected Attributes | |
| DtMissileStateRepository * | myMissileState |
| double | myDistanceToTarget |
| DtVector | myTargetErrorOffset |
| DtMissileFlightPSR * | myProcessState |
| Pointer to a process state repository used to store state data associated with this component. More... | |
Ports and Port Groups | |
| DtOutputPortGroup * | myMissileControlPortGroup |
| Output Port Group Name: missile-control Output Port Group Description: More... | |
| DtConstrainedAnalogOutputPort * | myThrustPort |
| Output Port Name: thrust Output Port Description: Output Port Range: Output Port Default Value: Output Group Parent: missile-control. More... | |
| DtConstrainedAnalogOutputPort * | myManeuverAccelXPort |
| Output Port Name: maneuver-accel-x Output Port Description: Output Port Range: -100000. More... | |
| DtConstrainedAnalogOutputPort * | myManeuverAccelYPort |
| Output Port Name: maneuver-accel-y Output Port Description: Output Port Range: -100000. More... | |
| DtConstrainedAnalogOutputPort * | myManeuverAccelZPort |
| Output Port Name: maneuver-accel-z Output Port Description: Output Port Range: -100000. More... | |
| DtBooleanOutputPort * | mySelfDestructPort |
| Output Port Name: self-destruct Output Port Description: Output Port Range: Output Port Default Value: Output Group Parent: missile-control. More... | |
| Protected Attributes inherited from DtTaskControllerComponent | |
| DtTaskCallbackMap | myTaskCallbackMap |
| std::list < DtTaskProcessorCallbackInfo * > | myTaskProcessorCallbackInfoList |
| This list stores any DtTaskProcessorCallbackInfo allocated locally so that they can be deleted when the component is deleted. More... | |
| Protected Attributes inherited from DtControllerComponent | |
| DtSimRadio * | myRadio |
| Controller components can send messages. More... | |
| Protected Attributes inherited from DtSimComponent | |
| DtVrfObject * | myEntity |
| DtVrfObjectStateRepository * | myLocalStateRepository |
| DtSimManager * | mySimManager |
| DtComponentSystem * | mySystem |
| Pointer to the DtComponentSystem that this component belongs. More... | |
| DtListItem * | myListItem |
| DtInputPortMap | myInputPortList |
| DtOutputPortMap | myOutputPortList |
| DtInputPortGroupMap | myInputPortGroupList |
| DtOutputPortGroupMap | myOutputPortGroupList |
| int | myPriority |
| double | myMinTickPeriod |
| double | myMinTickPeriodVariance |
| double | myNextTickTime |
| double | myLastTickSimTime |
| double | myDT |
| bool | myIsEnabled |
| Indicates whether this component should be enabled for ticking or not. More... | |
| bool | myFirstTick |
| Initialized to true in the constructor, set to false by the first call to postTick. More... | |
| bool | myIsThreadSafe |
| Whether this component can be use the DtCriticalSection versions of the tick functions and be ticked in parallel with other components Defaults to false. More... | |
| const DtComponentDescriptor * | myComponentDescriptor |
| std::list < DtVrfProcessStateRepository * > | myComponentPsrs |
| List of PSRs made using createComponentPsr() that will be deleted by this component when it is destroyed. More... | |
| bool | myTickEveryFrame |
| Flag indicating that tickPeriod is set to 0, and the component will tick every frame. More... | |
| DtTaskVisualizationMap | myTaskVisualizations |
| The visualization objects to be drawn for this component. More... | |
| double | myNextTaskVisTickTime |
| The next tick time for updating the task visualizations. More... | |
| DtSymbolString | myFullComponentName |
| Protected Attributes inherited from DtReaderWriter | |
| const DtSymbolString | myName |
| DtReaderWriterRegistry | myRegistry |
| DtReaderWriterRegistry * | myParentRegistry |
| bool | myValueSpecified |
| bool | myReadOnlyFlag |
| bool | myIsVariableReference |
| DtSymbolString | myVariableName |
| bool | myVariableIsBound |
| DtReaderWriter * | myDefaultValue |
| aliasContainer | myAliases |
| Container for the aliases which represent alternative names for the object. More... | |
| bool | myInvalid |
| Set to true if there is a problem reading this item. More... | |
| bool | myChangedFlag |
| Set to true when value changes Set to false when value checked with changedSinceLastChecked. More... | |
Additional Inherited Members | |
| Public Types inherited from DtReaderWriter | |
| typedef std::vector < DtSymbolString > | aliasContainer |
| typedef std::vector < DtSymbolString >::iterator | aliasIter |
| typedef std::vector < DtSymbolString > ::const_iterator | aliasConstIter |
| typedef std::vector< DtFilename > | SearchPaths |
| typedef std::pair < DtSymbolString, DtString > | DtVariableNameType |
| typedef DtReaderWriterFactory *(* | DtReaderWriterFactoryCreatorFcn )() |
| Static Public Member Functions inherited from DtTaskControllerComponent | |
| static void | deprecatedTaskProcessorCallbackAdapter (DtSimMessage *msg, void *usr, DtSimTaskStatePtr taskState) |
| Task processor callback function that acts as an adapter for the deprecated forms of addTaskProcessorCallback and removeTaskProcessorCallback (the deprecated form is is version that. More... | |
| Static Public Member Functions inherited from DtSimComponent | |
| static DtSimComponent * | MarkThreadSafe (DtSimComponent *) |
| Marks an instance of a component as being thread safe. More... | |
| static DtSimComponentFactory * | factory () |
| A DtSimComponentFactory is allocated by the DtSimCreator, and this pointer is set. More... | |
| static void | setFactory (DtSimComponentFactory *factory) |
| static DtSimComponent * | createComponent (const DtString &name, const DtString &type, DtVrfObject *owner, DtSimManager *simManager, DtComponentSystem *parentSystem, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) |
| Creates a DtSimComponent using the factory, then initializes it via the MTL stream. More... | |
| static void | addSimComponentCreatorFcn (const DtString &type, DtSimComponentCreatorFcn fcn) |
| Adds a DtSimComponent creation function to the DtSimComponentFactory, using the given type as the key. More... | |
| Static Public Member Functions inherited from DtReaderWriter | |
| static void | putIndent (std::string &fp, int indentLevel) |
| static const DtVariableBindingsList & | nullVariableReference () |
| static void | setPostGetSelfCallback (DtGetSelfCallbackFcn fcn, void *usrData) |
| static void | setPrePutSelfCallback (DtPutSelfCallbackFcn fcn, void *usrData) |
| static void | setPutIndent (bool) |
| static bool | putIndent () |
| static const char * | theXmlType () |
| The type that is used when archiving to an XML stream. More... | |
| static const DtFilename & | appPath () |
| Gets the current working directory. More... | |
| static void | setFactoryCreatorFunction (DtReaderWriterFactoryCreatorFcn fcn) |
| Sets the function to create the DtReaderWriterFactory. More... | |
| static void | createReaderWriterFactory () |
| static void | cleanupFactory () |
| static DtReaderWriterFactory * | factory () |
| static void | setOutputStream (DtOutputStream *stream) |
| static DtOutputStream & | outputStream () |
| static DtReaderWriter * | createFromXmlFile (const DtFilename &, bool createAsProperty=false) |
| Given a filename, returns a newly created reader/writer object from the object found within. More... | |
| static DtReaderWriter * | createFromXml (const DtString &, bool createAsProperty=false) |
| Given a xml string, returns a newly created reader/writer object from the object found within. More... | |
| static DtReaderWriter * | createFromEnvironment (DtEnvironmentSP, bool createAsProperty=false) |
| Given a xml environment, returns a newly created reader/writer object from the object found within. More... | |
| static DtString | getAttribute (DtEnvironmentSP env, const DtString &name, DtEnvValueSP root) |
| Gets the named attribute from a DtEnvValueSP. More... | |
| Static Public Member Functions inherited from DtObjectDebugger< DtSimComponent > | |
| static DtObjectCounter::CounterType | ObjectCount () |
| static const DtObjectContainer * | ObjectContainer () |
| Protected Types inherited from DtTaskControllerComponent | |
| typedef std::pair < DtTaskMessageCallbackFcn, void * > | DtTaskCallbackMapPair |
| This map stores callbacks that have been registered to processes various tasks. More... | |
| typedef std::map < DtSimTaskMessageType, DtTaskCallbackMapPair > | DtTaskCallbackMap |
| Protected Types inherited from DtSimComponent | |
| typedef std::map< DtString, DtInputPort * > | DtInputPortMap |
| typedef std::map< DtString, DtOutputPort * > | DtOutputPortMap |
| typedef std::map< DtString, DtInputPortGroup * > | DtInputPortGroupMap |
| typedef std::map< DtString, DtOutputPortGroup * > | DtOutputPortGroupMap |
| Static Protected Attributes inherited from DtSimComponent | |
| static DtSimComponentFactory * | myFactory |
| Static Protected Attributes inherited from DtReaderWriter | |
| static DtString | theUnspecifiedValue |
| static DtGetSelfCallbackInfo | thePostGetSelfCallback |
| static DtPutSelfCallbackInfo | thePrePutSelfCallback |
| static const DtVariableBindingsList | theEmptyVariableBindingsList |
| static bool | theCreatorFcnSet |
| static DtReaderWriterFactory * | theFactory |
| static DtReaderWriterFactoryCreatorFcn | theFactoryCreatorFcn |
| static bool | thePutIndent |
| static DtOutputStream * | theOutputStream |
DtMissileControllerComponent is a controller that contains all of the functionality common to all missile controllers.
Developer Description: Creates the ports needed to control missile actuators.
Uses Descriptor Type: DtComponentDescriptor
| DtMissileControllerComponent::DtMissileControllerComponent | ( | const DtString & | name, |
| DtVrfObject * | owner, | ||
| DtSimManager * | simManager, | ||
| DtComponentDescriptor * | desc = 0, |
||
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
| name | Reader writer name of this component. |
| owner | The DtVrfObject that owns this component |
| simManager | The simulation manager (provides access to terrain, message interface, simulation clock). |
| desc | The component descriptor used to initialize this component. |
| parentRegistry | Pointer to the parent reader writer registry (the containing object that reads/writes this object). |
|
virtual |
destructor
|
protected |
default constructor; not implemented
|
protected |
copy constructor; not implemented
|
virtual |
Overridden to initialze myMissileState and call calculateTargetErrorOffset.
Reimplemented from DtControllerComponent.
Reimplemented in DtLasingMissileTrackController.
|
virtual |
Returns a string identifies the class type of component.
Type values are defined in compTypes.h. DtSimComponent creation functions are registered with the DtSimComponentFactory using the type values as the key. Warning: this function should always return the same pointer and it should be valid forever. This means the data should be static.
Implements DtTaskControllerComponent.
Reimplemented in DtMissileMoveToControllerComponent, DtMissileTrackEntityController, and DtLasingMissileTrackController.
|
virtual |
We use this to approximate the correct thrust for a given speed.
Takes speed as an argument and returns a thrust value (a value between 0.0 and 1.0, with 1 corresponding to maximum thrust).
|
pure virtual |
Calculates the maneuvering thrust necessary to aim at the target.
Usually calls either calculateSteeringToPoint or calculateSteeringWithPropNav. Takes the local velocity and local position of the missile, along with the target point, and generates a vector of maneuver acceleration inputs needed to maneuver the missile toward the target. The output maneuver acceleration vector is perpendicular to the missile’s velocity vector, scaled to put the missile on a course with the target point. The acceleration vector is limited by the max maneuver Gs (a parameter of the missile entity). To calculate the steering: Start with two vectors in database coordinates: myVelocity and the target point. Change the target point vector into a vector from myPosition to the target. Let velocity vector be V, and the position-to-target vector P. P × V gives a perpendicular vector. If the result has no length, the missile is already heading in the right direction, so return zeros for maneuvering. If V is crossed with the above result, the result is a vector in the direction of our maneuver acceleration (V × (P × V)). With the direction set, normalize the new acceleration vector. To set the acceleration size, scale the normalized vector by the sine of the angle between the vectors. The resulting equation is V × (P × V) / (|V|^2 |P|). Scale the vector by the maximum maneuver Gs to get the missile turned as quickly as possible.
Implemented in DtMissileMoveToControllerComponent, and DtMissileTrackEntityController.
|
virtual |
Uses a simple algorithm to aim the missile at a static or slowly-moving target point.
This algorithm will still work even if the target is way off the velocity vector, however it will not work well for fast-moving target points.
|
virtual |
Uses proportional navigation to steer at an entity that may be moving at a high velocity.
This algorithm does not work well for targets 80 degrees or more away from the relativeVelocity vector. In fact, if the missile misses the target, this algorithm will aim the missile directly AWAY from the target, which is usually the desired behavior anyway.
|
virtual |
These are called in init to create the ports used to communicate with the actuator.
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
virtual |
|
protectedvirtual |
Overridden to call createMissileControlPortGroup.
Reimplemented from DtSimComponent.
|
protectedvirtual |
Overridden to create missile ports.
Reimplemented from DtSimComponent.
|
protectedvirtual |
Calculate offset (in target body coordinates) to be applied when steering toward the target.
Calculated as a function of the radius CEP. Instead of always maneuvering toward the precise location of a target, it flies to the target position modified by a constant offset. This introduces the possibility of a miss. The radius CEP is the Circular-Error-Probable radius, the radius around the target within which 50% of missiles fired will hit.
|
protectedvirtual |
This function looks up a process state repository in the process state repository manager by name, and caches a pointer to it in myProcessState.
The name (if it exists) is given in the component descriptor (DtComponentDescriptor::processStateRepositoryName). If the name does not exist, it uses the appropriate default name defined in procSRTypes.h. Another component is responsible for creating and destroying the process state repository.
|
protectedvirtual |
Calls lookupAndCacheProcessSR(), to look up our process state repository after all of the components have been created and loaded.
Reimplemented from DtSimComponent.
|
protectedvirtual |
Adds all items that have a range to the object state repository.
|
protected |
assignment operator; not implemented
|
protected |
|
protected |
|
protected |
Output Port Group Name: missile-control
Output Port Group Description:
|
protected |
Output Port Name: thrust
Output Port Description:
Output Port Range:
Output Port Default Value:
Output Group Parent: missile-control.
|
protected |
Output Port Name: maneuver-accel-x
Output Port Description:
Output Port Range: -100000.
to 100000.
Output Port Default Value:
Output Group Parent: missile-control
|
protected |
Output Port Name: maneuver-accel-y
Output Port Description:
Output Port Range: -100000.
to 100000.
Output Port Default Value:
Output Group Parent: missile-control
|
protected |
Output Port Name: maneuver-accel-z
Output Port Description:
Output Port Range: -100000.
to 100000.
Output Port Default Value:
Output Group Parent: missile-control
|
protected |
Output Port Name: self-destruct
Output Port Description:
Output Port Range:
Output Port Default Value:
Output Group Parent: missile-control.
|
protected |
|
protected |
Pointer to a process state repository used to store state data associated with this component.
This process state repository is shared with other components. Another component is responsible for creating and destroying the process state repository. This state is saved and restored as part of a scenario (or checkpoint).
