makVrv::DtIntervisibilitySettingsInterface Class Reference

This is the interface which the intervisibility settings widget will inherit from and the logic will use to talk to the widget.

Inheritance diagram for makVrv::DtIntervisibilitySettingsInterface:

Public Member Functions
virtual	~DtIntervisibilitySettingsInterface ()
virtual void	cancel ()=0
Field value setters.
Sets the values of the widget's corresponding fields.
virtual void	setIntervisibilityEnabled (bool)=0
virtual void	setLeftClickMakesObjectsPermanent (bool)=0
virtual void	setIntervisibilityElevationDecimals (int decimals)=0
virtual void	setOriginIntervisibilityElevation (double)=0
virtual void	setOriginIntervisibilityElevationLabel (const DtUnicode &label)=0
virtual void	setEndPointIntervisibilityElevation (double)=0
virtual void	setEndPointIntervisibilityElevationLabel (const DtUnicode &label)=0
virtual void	setFanModeSamplingRate (double)=0
virtual void	setFanModeSamplingRateMin (double)=0
virtual void	setFanModeSamplingRateMax (double)=0
virtual void	setFanModeSamplingRatePrecision (int decimals)=0
virtual void	setFanModeSamplingRateUnitLabel (const DtUnicode &label)=0
virtual void	setEntityFanUpdateRate (double rate)=0
virtual void	setVisibleColor (const QColor &color)=0
virtual void	setBlockedColor (const QColor &color)=0
virtual void	setCircleColor (const QColor &color)=0
virtual void	setHatLinesEnabled (bool enabled)=0
virtual void	setHatLinesOnSelectionOnly (bool selOnly)=0
virtual void	setEntityFanUpdateRateEnabled (bool enabled)=0
virtual void	setFanModeSamplingRateEnabled (bool enabled)=0
virtual void	setCircleColorEnabled (bool enabled)=0
virtual void	setLeftClickMakesObjectsPermanentEnabled (bool enabled)=0

Public Attributes
User input signals.
Notifies the logic that the user has changed a widget's value.
boost::signalslib::signal < void(bool)>	signal_intervisibilityEnabledChanged
boost::signalslib::signal < void(bool)>	signal_leftClickMakesObjectsPermanentChanged
boost::signalslib::signal < void(double)>	signal_originIntervisibilityElevationChanged
boost::signalslib::signal < void(double)>	signal_endPointIntervisibilityElevationChanged
boost::signalslib::signal < void(double)>	signal_fanModeSamplingRateChanged
boost::signalslib::signal < void(double)>	signal_entityFanUpdateRateChanged
boost::signalslib::signal < void(QColor)>	signal_visibleColorChanged
boost::signalslib::signal < void(QColor)>	signal_blockedColorChanged
boost::signalslib::signal < void(QColor)>	signal_circleColorChanged
boost::signalslib::signal < void(bool)>	signal_hatLinesEnabledChanged
boost::signalslib::signal < void(bool)>	signal_hatLinesOnSelectionOnlyChanged

Constructor & Destructor Documentation

virtual makVrv::DtIntervisibilitySettingsInterface::~DtIntervisibilitySettingsInterface ( )

virtual

DTOR.

Member Function Documentation

virtual void makVrv::DtIntervisibilitySettingsInterface::setIntervisibilityEnabled ( bool  )

pure virtual

Globally enables or disables intervisibity elements. When disabled, exisiting elements are hidden, and no new ones may be created.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setLeftClickMakesObjectsPermanent ( bool  )

pure virtual

When left click is pressed, the object will stay, else a new one will be created at the left click spot, removing the old one.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setIntervisibilityElevationDecimals ( int  decimals )

pure virtual

Sets the precision used in the elevation fields.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setOriginIntervisibilityElevation ( double  )

pure virtual

Sets the distance above the origin to place the intervisibility line.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setOriginIntervisibilityElevationLabel ( const DtUnicode &  label )

pure virtual

Sets the label indicating the origin's elevation units.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setEndPointIntervisibilityElevation ( double  )

pure virtual

Sets the distance above the end point to place the intervisibility line.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setEndPointIntervisibilityElevationLabel ( const DtUnicode &  label )

pure virtual

Sets the label indicating the endpoint's elevation units.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRate ( double  )

pure virtual

Sets the fan mode sampling rate (in the appropriate unit).

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRateMin ( double  )

pure virtual

Sets the fan mode min sampling rate (in the appropriate unit).

Implemented in makVrv::DtIntervisibilitySettingsWidget, and makVrf::DtVrfIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRateMax ( double  )

pure virtual

Sets the fan mode max sampling rate (in the appropriate unit).

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRatePrecision ( int  decimals )

pure virtual

Sets the fan mode sampling rate precision.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRateUnitLabel ( const DtUnicode &  label )

pure virtual

Sets the fan mode sampling rate unit label.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setEntityFanUpdateRate ( double  rate )

pure virtual

Sets the entity fan mode update rate. Zero (0) default means check as fast as possible.

Value is in seconds

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setVisibleColor ( const QColor &  color )

pure virtual

Sets the visible color.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setBlockedColor ( const QColor &  color )

pure virtual

Sets the blocked color.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setCircleColor ( const QColor &  color )

pure virtual

Sets the blocked color.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setHatLinesEnabled ( bool  enabled )

pure virtual

Sets height above terrain lines enabled.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setHatLinesOnSelectionOnly ( bool  selOnly )

pure virtual

Set to show height above terrain lines only when the object is selected.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setEntityFanUpdateRateEnabled ( bool  enabled )

pure virtual

Shows/hides entity fan upate rate.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setFanModeSamplingRateEnabled ( bool  enabled )

pure virtual

Shows/hides fan mode sampling rate.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setCircleColorEnabled ( bool  enabled )

pure virtual

Shows/hides circle color.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::setLeftClickMakesObjectsPermanentEnabled ( bool  enabled )

pure virtual

Shows/hides left click permanent.

Implemented in makVrv::DtIntervisibilitySettingsWidget.

virtual void makVrv::DtIntervisibilitySettingsInterface::cancel ( )

pure virtual

Cancels page.

Implemented in makVrv::DtIntervisibilitySettingsWidget, and makVrv::DtIntervisibilityPropertiesDialog.

Member Data Documentation

boost::signalslib::signal<void (bool)> makVrv::DtIntervisibilitySettingsInterface::signal_intervisibilityEnabledChanged

boost::signalslib::signal<void (bool)> makVrv::DtIntervisibilitySettingsInterface::signal_leftClickMakesObjectsPermanentChanged

boost::signalslib::signal<void (double)> makVrv::DtIntervisibilitySettingsInterface::signal_originIntervisibilityElevationChanged

boost::signalslib::signal<void (double)> makVrv::DtIntervisibilitySettingsInterface::signal_endPointIntervisibilityElevationChanged

boost::signalslib::signal<void (double)> makVrv::DtIntervisibilitySettingsInterface::signal_fanModeSamplingRateChanged

boost::signalslib::signal<void (double)> makVrv::DtIntervisibilitySettingsInterface::signal_entityFanUpdateRateChanged

boost::signalslib::signal<void (QColor)> makVrv::DtIntervisibilitySettingsInterface::signal_visibleColorChanged

boost::signalslib::signal<void (QColor)> makVrv::DtIntervisibilitySettingsInterface::signal_blockedColorChanged

boost::signalslib::signal<void (QColor)> makVrv::DtIntervisibilitySettingsInterface::signal_circleColorChanged

boost::signalslib::signal<void (bool)> makVrv::DtIntervisibilitySettingsInterface::signal_hatLinesEnabledChanged

boost::signalslib::signal<void (bool)> makVrv::DtIntervisibilitySettingsInterface::signal_hatLinesOnSelectionOnlyChanged

---

The documentation for this class was generated from the following file:

• /data/exports/nrhent7-1/nightly/docs/vrForces.vrf5-2-branch/include/vrvCoreQt/DtIntervisibilitySettingsInterface.h
