VR-Forces 4.1.1 Class Documentation
|
|
VR-Forces 4.1.1 Class Documentation
|
This class provides a base class for all controllers that are capable of executing a DtSimTask, and can only execute a single DtSimTask at a time. More...
Public Member Functions | |
| DtSingleTaskControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *compDesc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| (const DtString& name, | |
| virtual | ~DtSingleTaskControllerComponent () |
| destructor | |
| virtual void | postTick () |
| Override to check if we're tasked and we want to give up (only performs the check if we're in play mode (dT() > 0)). | |
| virtual bool | beginProcessingTask (const DtTaskMessage &task, DtSimTaskStatePtr taskState) |
| Called by the task manager when this controller should start executing the specified task. | |
| virtual void | taskNotify (const DtSimTask &task) |
| This is called to let us know when some other component receives a task In the case of this component, we don't care what the task actually is. | |
| virtual void | taskComplete (bool success=true) |
| If we are currently tasked, this will cause us to notify the entity that we're done and delete the task. | |
| virtual void | clearTask () |
| If component is currently tasked, calls clearPendingSubtasks(), sets the tasked flag to false, and calls clearCurrentTaskMesage() to clear out the current task message. | |
| virtual int | sendSubtask (DtSimTask &task) |
| Sends subtask to ourself. | |
| virtual void | clearSubtask (int subtaskId) |
| Clears subtask with the given subtaskId (subtaskId is returned sendSubtask()). | |
| virtual void | addPendingSubtaskId (int subtaskId) |
| Adds given subtask Id to list of pending subtasks. | |
| virtual bool | findPendingSubtaskId (int subtaskId) |
| Checks to see if given subtaskId exists in our list of pending subtasks. | |
| virtual void | removePendingSubtaskId (int subtaskId) |
| Removes pending subtask from list of subtasks for this component. | |
| virtual void | removeAllPendingSubtaskIds () |
| Clear all pending subtasks from our list of subtasks. | |
| virtual std::vector< int > | currentPendingSubstaskIds () const |
| Returns the list of all currently pending subtask ids for this controller. | |
| virtual void | clearCurrentTaskMessage () |
| Returns the current subtask with the specified id. | |
| virtual DtTaskMessage * | currentTaskMessage () const |
| Get a pointer to the message that was used to task this entity. | |
| virtual DtSimTaskStatePtr | currentTaskState () const |
| virtual bool | decideToGiveUpTask () const |
| This function is used to determine if the controller should give up trying to execute the current task. | |
| virtual void | giveUpTask () |
| Called when controller is tasked and decideToGiveUp() returns true. | |
| virtual bool | taskActive (int taskId) const |
| | |
| virtual bool | clearTopLevelTasks () |
| If this controller has any top level tasks (not subtasks), they are cleared. | |
| virtual void | clearConflictingTopLevelTasks (const DtSimTaskMessageType &conflictType) |
| Clears any top level tasks on this controller that conflict with the conflict task type. | |
| virtual void | clearTasksByType (const DtSimTaskMessageType &taskType) |
| Clears any tasks of the specified type running in this controller. | |
| virtual void | clearTaskById (int taskId) |
| Clears any task of the specified ID running in this controller. | |
| virtual std::list < DtTaskMessage * > | currentTaskMessages () const |
| | |
| virtual DtTaskWithTaskStateListPtr | topLevelTasks () const |
| | |
 Public Member Functions inherited from DtTaskControllerComponent | |
| DtTaskControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *compDesc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| (const DtString& name, | |
| virtual | ~DtTaskControllerComponent () |
| destructor | |
| virtual DtString | type () const =0 |
| Returns a string identifies the class type of component. | |
| virtual bool | showCurrentTaskInGui () const |
| virtual void | setRadio (DtSimBaseRadio *radio) |
| Calls registerTaskMsgCallbacks. | |
| virtual void | registerTaskMsgCallbacks () |
| virtual void | addTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtTaskMessageCallbackFcn fcn, void *usr) |
| Adds a new function for processing the specified task type. | |
| virtual void | addTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtMessageCallbackFcn fcn, void *usr) |
| Deprecated form of addTaskProcessorCallback. | |
| virtual void | removeTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtMessageCallbackFcn fcn, void *usr) |
| Undoes anything done by addTaskProcessorCallback(). | |
| virtual void | removeTaskProcessorCallback (const DtSimTaskMessageType &taskType, DtTaskMessageCallbackFcn fcn, void *usr) |
| Deprecated form of removeTaskProcessorCallback. | |
| virtual void | enable () |
| Overridden to call registerTaskMsgCallbacks(). | |
| virtual void | disable () |
| Overridden to 1) remove any task message callbacks registered by this controller 2) call clear task. | |
| virtual void | sendTaskCanceled (DtTaskMessage *taskMsg) |
| Sends the task canceled report for the specified message. | |
| virtual void | setTasked (bool tasked) |
| The current tasked state of this controller. | |
| virtual bool | tasked () const |
| The current tasked state of this controller. | |
| Public Member Functions inherited from DtControllerComponent | |
| DtControllerComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| (const DtString& name, | |
| virtual | ~DtControllerComponent () |
| destructor | |
| virtual bool | init () |
| Calls setRadio() | |
| virtual DtSimBaseRadio * | radio () |
| The radio this component is listening to. | |
| Public Member Functions inherited from DtSimComponent | |
| DtSimComponent (const DtString &name, DtVrfObject *owner, DtSimManager *simManager, DtComponentDescriptor *desc=0, DtReaderWriterRegistry *parentRegistry=0) | |
| virtual | ~DtSimComponent () |
| destructor | |
| void | setParentSystem (DtComponentSystem *system) |
| Sets the parent system of this component. | |
| virtual bool | postAddComponentsInit () |
| Called after all components have been created, initialized and added to the component manager. | |
| virtual void | preFirstTickInit () |
| This function can be overridden to initialize a component before it is ticked for the first time. | |
| virtual void | tick () |
| This gives the thread of control to the component. | |
| virtual void | timedTick () |
| This version of tick checks to see if the time to tick has arrived. | |
| virtual void | setMinTickPeriod (double minTickPeriod) |
| specifies a minimum tick period (which can also be thought of as | |
| virtual double | minTickPeriod () const |
| access the minimum tick period | |
| virtual void | setMinTickPeriodVariance (double minTickPeriodVariance) |
| set the variance in the minimum tick time | |
| virtual double | minTickPeriodVariance () const |
| access the variance in the minimum tick period | |
| virtual void | setNextTickTime (double nextTickTime) |
| The next tick time is normally calculated internally. | |
| virtual double | nextTickTime () const |
| access the next tick time | |
| virtual double | calculateNextTickTime () const |
| The next tick time is equal to mySimManager->exerciseClock()-> approximateElapsedRealTime() + myMinTickPeriod + a random # between -myMinTickPeriodVariance/2. | |
| virtual double | calculateFirstTickTime () const |
| Returns the first time value that the component should tick at. | |
| virtual void | setEntity (DtVrfObject *entity) |
| The entity's state repository is the place that actuator components make updates and other components look to see our current state. | |
| virtual DtSimComponent * | nextComponent () |
| List management functions. | |
| virtual DtSimComponent * | prevComponent () |
| virtual void | setListItem (DtListItem *item) |
| Used by DtComponentList. | |
| virtual DtListItem * | listItem () |
| virtual void | putData (FILE *fp, int indentLevel=0) |
| putData writes our type, which is provided by the virtual type accessor of the deriving class. | |
| virtual DtlObjPtr | getData (DtlObjPtr args, const DtFilename &searchPath, const DtVariableBindingsList &variableBindings) |
| getData is just used to get us past the type in the data stream, since it's not actual stored. | |
| virtual void | addInputPort (DtInputPort *port) |
| Adds this input port to the components input port list so that other components can look it up and attach to it. | |
| virtual void | removeInputPort (DtInputPort *port) |
| virtual DtInputPort * | lookupInputPort (const DtString &portName) |
| Returns a pointer to the input port registered on this component with the specified name. | |
| virtual DtList | inputPortList () const |
| Returns the list of DtInputPorts registered on this component. | |
| virtual void | addOutputPort (DtOutputPort *port) |
| Adds this output port to the components output port list so that other components can look it up and attach to it. | |
| virtual void | removeOutputPort (DtOutputPort *port) |
| virtual DtOutputPort * | lookupOutputPort (const DtString &portName) |
| Returns a pointer to the output port registered on this component with the specified name. | |
| virtual DtList | outputPortList () const |
| Returns the list of DtOutputPorts registered on this component. | |
| virtual void | addInputPortGroup (DtInputPortGroup *group) |
| Adds this input port to the components input port list so that other components can look it up and attach to it. | |
| virtual void | removeInputPortGroup (DtInputPortGroup *group) |
| virtual DtInputPortGroup * | lookupInputPortGroup (const DtString &groupName) |
| Returns a pointer the input port group registered on this component with the specified name. | |
| virtual DtList | inputPortGroupList () const |
| Returns the list of DtInputPortGroups registered on this component. | |
| virtual void | addOutputPortGroup (DtOutputPortGroup *group) |
| Adds this output port group to the components output port group list so that other components can look it up and attach to it. | |
| virtual void | removeOutputPortGroup (DtOutputPortGroup *group) |
| virtual DtOutputPortGroup * | lookupOutputPortGroup (const DtString &groupName) |
| Returns a pointer the output port group registered on this component with the specified name. | |
| virtual DtList | outputPortGroupList () const |
| Returns the list of DtOutputPortGroups registered on this component. | |
| virtual int | priority () const |
| Return the current connection priority for this component. | |
| virtual void | setPriority (int priority) |
| Sets a new connection priority for this component, and changes all current outgoing connections from this component to the new value. | |
| double | dT () const |
| This is the delta-t for this component, which may or may not be the same as the exerciseClock dT. | |
| virtual void | setDT (double deltaT) |
| Note that while dT is calculated internally, this makes it possible to 'lie' to the component about dT if necessary. | |
| virtual void | setComponentDescriptor (DtComponentDescriptor *componentDescriptor) |
| The component descriptor specified in the order of battle file or parameter file that was used to create this component. | |
| virtual const DtComponentDescriptor * | componentDescriptor () const |
| virtual bool | tickWhileDestroyed () const |
| If the component returns true here, it will be ticked regardless of the destroyed state of the host entity. | |
| DtVrfProcessStateRepositoryManager * | psrManager () |
| virtual DtString | componentFullName () const |
| virtual bool | isEnabled () |
| Is this component enabled or not. | |
| virtual void | setIsEnabled (bool yesNo) |
| Is this component enabled or not. | |
| virtual DtOutputStream & | objectConsoleDebug () const |
| virtual DtOutputStream & | objectConsoleVerbose () const |
| virtual DtOutputStream & | objectConsoleInfo () const |
| virtual DtOutputStream & | objectConsoleWarn () const |
| virtual DtOutputStream & | objectConsoleError () const |
| virtual DtSimResourceManager & | resourceManager () |
| virtual const DtSimResourceManager & | resourceManager () const |
| Public Member Functions inherited from DtReaderWriter | |
| DtReaderWriter () | |
| default constructor | |
| DtReaderWriter (const DtString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| real constructor Setting the readonly flag prevents object from writing itself to the stream. | |
| DtReaderWriter (const DtSymbolString &name, DtReaderWriterRegistry *parentRegistry=NULL, bool readonly=false) | |
| DtReaderWriter (const DtString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| copy constructor | |
| DtReaderWriter (const DtSymbolString &name, const DtReaderWriter &orig, DtReaderWriterRegistry *parentRegistry=NULL) | |
| const DtReaderWriter & | operator= (const DtReaderWriter &orig) |
| assignment operator | |
| virtual | ~DtReaderWriter () |
| destructor | |
| virtual void | putSelf (FILE *fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| Top level call to write itself to file. | |
| virtual void | getSelf (DtlObjPtr args, const DtFilename &searchPath=DtFilename::nullFilename(), const DtVariableBindingsList &variableBindings=nullVariableReference()) |
| Top level to read itself from an input stream. | |
| virtual void | writeSelf (FILE *fp, int indentLevel=0, bool writeUnspecified=false, const DtFilename &path=DtFilename::nullFilename()) |
| Called from putSelf, calls myRegistry.putSelf which in turn calls putSelf on each reader/writer in the registry. | |
| virtual DtSymbolString | name () const |
| Accessor for name of this readable/writable object. | |
| virtual void | addAlias (const DtSymbolString &alias) |
| Add an alias as an alternative name for this object. | |
| virtual bool | hasAlias (const DtSymbolString &alias) |
| virtual const aliasContainer & | aliases () const |
| virtual void | setReadonly (bool flag) |
| Set read-only flag. | |
| virtual bool | isReadonly () const |
| virtual bool | variableIsBound () const |
| virtual void | unbindVariable () |
| Sets the myVariableIsBound flag to false. | |
| virtual void | setName (const DtString &) |
| Set the name of the object. | |
| virtual const char * | readerWriterType () const |
| Used to supply a string type that this reader writer type is. | |
| virtual DtString | prettyPrint () const |
| Routine to return a human readable form of the reader/writer variable. | |
| virtual void | bindVariables (DtVariableBindingsList variableBindings) |
| Runs a variable binding pass on this reader writer and any of its children. | |
| virtual std::list < DtVariableNameType > | unboundVariables () const |
| bool | invalid () const |
| virtual bool | hasChild (const DtReaderWriter *p) const |
| Returns true if this variable has a child p in it's chain. | |
| virtual void | setValueSpecified (bool specified, bool recurse=false) |
| The specified flags are used for optional values. | |
| virtual bool | valueSpecified () const |
| The specified flags are used for optional values. | |
| virtual bool | isVariableReference () const |
| Specifies whether or not this reader writer is really a variable that is specified elsewhere. | |
| virtual void | setIsVariableReference (bool value) |
| virtual DtSymbolString | variableName () const |
| The variable name, if this object is a variable reference. | |
| virtual void | setVariableName (const DtSymbolString variableName) |
| The variable name, if this object is a variable reference. | |
| const DtReaderWriterRegistry & | registry () const |
| Collection of child DtReaderWriter nodes owned by this object. | |
| DtReaderWriterRegistry & | registry () |
| Collection of child DtReaderWriter nodes owned by this object. | |
Protected Member Functions | |
| virtual void | clearPendingSubtasks () |
| Iterates over collection of all pending subtasks for this controller, and calls clearSubtask() for each subtask type. | |
| virtual void | clearSubtasksByType (const DtSimTaskMessageType &taskType) |
| Clear all subtasks of a given type. | |
Additional Inherited Members | |
| Public Types inherited from DtReaderWriter | |
| typedef std::vector < DtSymbolString > | aliasContainer |
| typedef std::vector < DtSymbolString >::iterator | aliasIter |
| typedef std::vector < DtSymbolString > ::const_iterator | aliasConstIter |
| typedef std::pair < DtSymbolString, DtString > | DtVariableNameType |
| Static Public Member Functions inherited from DtTaskControllerComponent | |
| static void | deprecatedTaskProcessorCallbackAdapter (DtSimMessage *msg, void *usr, DtSimTaskStatePtr taskState) |
| Task processor callback function that acts as an adapter for the deprecated forms of addTaskProcessorCallback and removeTaskProcessorCallback (the deprecated form is is version that. | |
| Protected Types inherited from DtTaskControllerComponent | |
| typedef std::pair < DtTaskMessageCallbackFcn, void * > | DtTaskCallbackMapPair |
| This map stores callbacks that have been registered to processes various tasks. | |
| typedef std::map < DtSimTaskMessageType, DtTaskCallbackMapPair > | DtTaskCallbackMap |
| Protected Attributes inherited from DtTaskControllerComponent | |
| DtTaskCallbackMap | myTaskCallbackMap |
| std::list < DtTaskProcessorCallbackInfo * > | myTaskProcessorCallbackInfoList |
| This list stores any DtTaskProcessorCallbackInfo allocated locally so that they can be deleted when the component is deleted. | |
| Static Protected Attributes inherited from DtSimComponent | |
| static DtSimComponentFactory * | myFactory |
This class provides a base class for all controllers that are capable of executing a DtSimTask, and can only execute a single DtSimTask at a time.
This is the typical case for most task controllers, so most controllers will be derived from this class.
| DtSingleTaskControllerComponent::DtSingleTaskControllerComponent | ( | const DtString & | name, |
| DtVrfObject * | owner, | ||
| DtSimManager * | simManager, | ||
| DtComponentDescriptor * | compDesc = 0, |
||
| DtReaderWriterRegistry * | parentRegistry = 0 |
||
| ) |
(const DtString& name,
| name | Reader writer name of this component. |
| owner | The DtVrfObject that owns this component |
| simManager | The simulation manager (provides access to terrain, message interface, simulation clock). |
| desc | The component descriptor used to initialize this component. |
| parentRegistry | Pointer to the parent reader writer registry (the containing object that reads/writes this object). |
|
virtual |
destructor
|
virtual |
Override to check if we're tasked and we want to give up (only performs the check if we're in play mode (dT() > 0)).
Calls decideToGiveUpTask() to determine if we should give up. If true, calls giveUpTask().
Reimplemented from DtTaskControllerComponent.
|
virtual |
Called by the task manager when this controller should start executing the specified task.
| taskState | Used to convey at what point the task should begin execution. If taskState exists, execution of task may begin at some point other than the logical start of the task. If taskState is 0, begin processing at the logical start of the task. |
Reimplemented from DtTaskControllerComponent.
Reimplemented in DtRailPathController, DtRotaryWingFlightCommandController, and DtFixedWingFlightCommandController.
|
virtual |
This is called to let us know when some other component receives a task In the case of this component, we don't care what the task actually is.
Reimplemented from DtTaskControllerComponent.
|
virtual |
If we are currently tasked, this will cause us to notify the entity that we're done and delete the task.
To indicate that the task has failed (and is being abandoned) call this method with success set to false.
Reimplemented in DtFixedWingMoveToController, DtDIGuyController, DtTargetSelectionController, and DtLaunchExpendableResourceController.
|
virtual |
If component is currently tasked, calls clearPendingSubtasks(), sets the tasked flag to false, and calls clearCurrentTaskMesage() to clear out the current task message.
Reimplemented from DtControllerComponent.
Reimplemented in DtFixedWingMoveAlongController, DtFixedWingMoveToController, DtRailMovementController, DtAggregatedMoveToController, DtHumanMoveAlongController, DtHumanMoveToController, DtGroundMoveAlongControllerComponent, DtRailPathController, DtAggregatedMoveAlongController, DtDisaggregatedEmbarkationController, DtDIGuyController, DtHumanFollowController, BHAVE::DtKynapseController, DtDisaggregatedMoveAlongController, DtRotaryWingFlightCommandController, DtSurfaceEntityPilotController, DtTurnAndMoveController, DtFixedWingLandingController, DtFixedWingTakeoffController, DtEmbarkationController, DtFixedWingFlightCommandController, DtLasingController, DtDisaggregatedMoveIntoFormationController, DtIndirectFireController, DtFixedWingPilotController, DtSurfaceEntityMoveAlongController, DtHumanTurnToController, DtConvoyTaskController, DtDisaggregatedMoveToLocationController, DtHumanStopMovingController, DtDisaggregatedMoveToController, DtGroundAutoControllerComponent, DtRotaryWingLandingController, DtRotaryWingTaskController, and DtSurfaceEntityMoveToController.
|
virtual |
Sends subtask to ourself.
Creates task message and sends task to ourself through radio. Adds subtask Id to list of pending subtasks. Returns subtask Id.
|
virtual |
Clears subtask with the given subtaskId (subtaskId is returned sendSubtask()).
Also removed the subtask ID from the pending subtask ID list.
|
virtual |
Adds given subtask Id to list of pending subtasks.
This is done automatically by sendSubtask (user should not typically have to call this directly).
|
virtual |
Checks to see if given subtaskId exists in our list of pending subtasks.
Typically checked from within a task complete callback, to determine if given report corresponds to the specific subtask we issued.
|
virtual |
Removes pending subtask from list of subtasks for this component.
Users will typically call this from within a task complete callback, upon receipt of the specific subtasking task complete report they were waiting for.
|
virtual |
Clear all pending subtasks from our list of subtasks.
Users should not typically have to call this.
|
virtual |
Returns the list of all currently pending subtask ids for this controller.
|
virtual |
Returns the current subtask with the specified id.
Also returns the controller that is responsible. If NULL, no task was found Clear the current task message.
Reimplemented in DtFixedWingLandingController, and DtEmbarkationController.
|
virtual |
Get a pointer to the message that was used to task this entity.
|
virtual |
Reimplemented in DtAggregatedMoveAlongController, DtDisaggregatedMoveAlongController, DtWaitController, DtDisaggregatedPatrolAlongController, DtAggregatedPatrolController, and DtDisaggregatedPatrolBetweenController.
|
virtual |
This function is used to determine if the controller should give up trying to execute the current task.
Override this function to provide the test for determining if the task controller should give up. For example, a derived move-to-waypoint controller tasked to reach an unreachable waypoint might decide to give up after a certain amount of time, or after circling the point and failing to reach it. This function is called from within tick. If the controller is tasked and this function returns true, it calls giveUp(). The implementation in this class always returns false.
Reimplemented in DtFixedWingPilotController, DtRailMovementController, DtGroundMoveToDestinationControllerComponent, DtSurfaceEntityPilotController, DtGroundAutoControllerComponent, DtHumanMoveToController, DtGroundMoveAlongControllerComponent, DtHumanMoveAlongController, and DerivedMoveToController.
|
virtual |
Called when controller is tasked and decideToGiveUp() returns true.
Base class implementation calls clearTask(). Derived classes may override this function to perform some specific handling.
Reimplemented in DerivedMoveToController.
|
virtual |
Implements DtTaskControllerComponent.
|
virtual |
If this controller has any top level tasks (not subtasks), they are cleared.
Implements DtTaskControllerComponent.
|
virtual |
Clears any top level tasks on this controller that conflict with the conflict task type.
The task manager is used to determine what tasks conflict.
Implements DtTaskControllerComponent.
|
virtual |
Clears any tasks of the specified type running in this controller.
Implements DtTaskControllerComponent.
|
virtual |
Clears any task of the specified ID running in this controller.
Implements DtTaskControllerComponent.
|
virtual |
Implements DtTaskControllerComponent.
|
virtual |
Implements DtTaskControllerComponent.
|
protectedvirtual |
Iterates over collection of all pending subtasks for this controller, and calls clearSubtask() for each subtask type.
|
protectedvirtual |
Clear all subtasks of a given type.
Should not normally be called (call clearSubtask(int subtaskId) to clear a given subtask instead). Provided as a utility function as an aid to backwards compatibility.
